Yunqi Liu

Find an error

Name: 刘云圻; YunYin Liu
Organization: Institute of Chemistry, Chinese Academy of Sciences , China
Department: Institute of Chemistry
Title: Researcher/Professor(PhD)

TOPICS

Co-reporter:Zhiyuan Zhao;Zhihong Yin;Huajie Chen;Yunlong Guo;Qinxin Tang
Journal of Materials Chemistry C 2017 vol. 5(Issue 11) pp:2892-2898
Publication Date(Web):2017/03/16
DOI:10.1039/C6TC05659H
A strongly electron-withdrawing benzo[c][1,2,5]oxadiazole (BOZ) unit, as the second electron acceptor segment, is incorporated into the naphthalenediimide (NDI) based polymer backbone for the first time. Therefore, a unipolar n-type polymer semiconductor (PNBO) with a regioregular A1–D–A2–D configuration is developed successfully. It is found that BOZ-containing polymer PNBO not only has a deep-lying LUMO energy level of ca. −4.0 eV, which facilitates electron-injection from an Au electrode into the active layer, but also possesses a deep enough low HOMO energy level of −5.9 eV for blocking hole-injection. The carrier transporting performance of PNBO is characterized by solution-processable polymeric field-effect transistors (PFETs). These results demonstrate that a smooth surface morphology and a compact solid stacking endow PNBO with excellent unipolar n-type electron-transporting characteristics; a highest electron mobility of up to 2.43 cm2 V−1 and an excellent shelf storage with a negligible decay in 70 days are achieved.
Co-reporter:Lei Fu;Feng Wang;Bin Wu;Nian Wu;Wei Huang;Hanlin Wang;Chuanhong Jin;Lin Zhuang;Jun He;Lei Fu
Advanced Materials 2017 Volume 29(Issue 32) pp:
Publication Date(Web):2017/08/01
DOI:10.1002/adma.201700439
As a member of the group IVB transition metal dichalcogenides (TMDs) family, hafnium disulfide (HfS2) is recently predicted to exhibit higher carrier mobility and higher tunneling current density than group VIB (Mo and W) TMDs. However, the synthesis of high-quality HfS2 crystals, sparsely reported, has greatly hindered the development of this new field. Here, a facile strategy for controlled synthesis of high-quality atomic layered HfS2 crystals by van der Waals epitaxy is reported. Density functional theory calculations are applied to elucidate the systematic epitaxial growth process of the S-edge and Hf-edge. Impressively, the HfS2 back-gate field-effect transistors display a competitive mobility of 7.6 cm2 V−1 s−1 and an ultrahigh on/off ratio exceeding 108. Meanwhile, ultrasensitive near-infrared phototransistors based on the HfS2 crystals (indirect bandgap ≈1.45 eV) exhibit an ultrahigh responsivity exceeding 3.08 × 105 A W−1, which is 109-fold higher than 9 × 10−5 A W−1 obtained from the multilayer MoS2 in near-infrared photodetection. Moreover, an ultrahigh photogain exceeding 4.72 × 105 and an ultrahigh detectivity exceeding 4.01 × 1012 Jones, superior to the vast majority of the reported 2D-materials-based phototransistors, imply a great promise in TMD-based 2D electronic and optoelectronic applications.
Co-reporter:Hanlin Wang;Hongtao Liu;Qiang Zhao;Zhenjie Ni;Ye Zou;Jie Yang;Lifeng Wang;Yanqiu Sun;Yunlong Guo;Wenping Hu
Advanced Materials 2017 Volume 29(Issue 32) pp:
Publication Date(Web):2017/08/01
DOI:10.1002/adma.201701772
Human eyes use retina photoreceptor cells to absorb and distinguish photons from different wavelengths to construct an image. Mimicry of such a process and extension of its spectral response into the near-infrared (NIR) is indispensable for night surveillance, retinal prosthetics, and medical imaging applications. Currently, NIR organic photosensors demand optical filters to reduce visible interference, thus making filter-free and anti-visible NIR imaging a challenging task. To solve this limitation, a filter-free and conformal, retina-inspired NIR organic photosensor is presented. Featuring an integration of photosensing and floating-gate memory modules, the device possesses an acute color distinguishing capability. In general, the retina-like photosensor transduces NIR (850 nm) into nonvolatile memory and acts as a dynamic photoswitch under green light (550 nm). In doing this, a filter-free but color-distinguishing photosensor is demonstrated that selectively converts NIR optical signals into nonvolatile memory.
Co-reporter:Jie Yang;Hanlin Wang;Jinyang Chen;Jianyao Huang;Yingying Jiang;Jianqi Zhang;Longxian Shi;Yunlong Sun;Zhixiang Wei;Gui Yu;Yunlong Guo;Shuai Wang
Advanced Materials 2017 Volume 29(Issue 22) pp:
Publication Date(Web):2017/06/01
DOI:10.1002/adma.201606162
A bis-diketopyrrolopyrrole (DPP dimer, 2DPP) core is synthesized with much stronger electron deficiency than DPP by homocoupling of DPP. 2DPP-based polymers, P2DPP-BT, P2DPP-TT, P2DPP-TVT, and P2DPP-BDT, are obtained. Top-gated organic field-effect transistors on plastic substrate are fabricated. Compared with their mono-DPP-based polymers, remarkable improvement of electron mobilities of P2DPPs is achieved. Meanwhile, their p-channel performance becomes higher.
Co-reporter:Yingying Jiang;Yunlong Guo
Advanced Electronic Materials 2017 Volume 3(Issue 11) pp:
Publication Date(Web):2017/11/01
DOI:10.1002/aelm.201700157
AbstractOrganic field-effect transistors (OFETs) have received considerable attention across the world due to their potential applications in integrated circuits for large-area, flexible and low-cost electronics, and a series of breakthroughs in their research have been made in the past decade. Although numerous novel organic semiconductive materials with outstanding properties have been synthesized, the fabrication of OFETs and the investigation of amorphous polymer insulators (APIs) are attracting more and more research interest due to their significance in semiconductor growth, charge transport and device stability. In this review, an introduction to APIs and OFETs is given, and the following aspects are then successively discussed: commonly used APIs in OFETs, applications of API in high-performance OFETs, low-energy-consumption OFETs, functional OFETs, and self-healing OFETs. In the last section, a projection of some future trends for APIs in OFETs is presented.
Co-reporter:Jie Yang;Zhiyuan Zhao;Hua Geng;Changli Cheng;Jinyang Chen;Yunlong Sun;Longxian Shi;Yuanping Yi;Zhigang Shuai;Yunlong Guo;Shuai Wang
Advanced Materials 2017 Volume 29(Issue 36) pp:
Publication Date(Web):2017/09/01
DOI:10.1002/adma.201702115
So far, most of the reported high-mobility conjugated polymers are p-type semiconductors. By contrast, the advances in high-mobility ambipolar polymers fall greatly behind those of p-type counterparts. Instead of unipolar p-type and n-type materials, ambipolar polymers, especially balanced ambipolar polymers, are potentially serviceable for easy-fabrication and low-cost complementary metal-oxide-semiconductor circuits. Therefore, it is a critical issue to develop high-mobility ambipolar polymers. Here, three isoindigo-based polymers, PIID-2FBT, P1FIID-2FBT, and P2FIID-2FBT are developed for high-performance ambipolar organic field-effect transistors. After the incorporation of fluorine atoms, the polymers exhibit enhanced coplanarity, lower energy levels, higher crystallinity, and thus increased µe. P2FIID-2FBT exhibits n-type dominant performance with a µe of 9.70 cm2 V−1 s−1. Moreover, P1FIID-2FBT exhibits a highly balanced µh and µe of 6.41 and 6.76 cm2 V−1 s−1, respectively, which are among the highest values for balanced ambipolar polymers. Moreover, a concept “effective mass” is introduced to further study the reasons for the high performance of the polymers. All the polymers have small effective masses, indicating good intramolecular charge transport. The results demonstrate that high-mobility ambipolar semiconductors can be obtained by designing polymers with fine-tuned energy levels, small effective masses, and high crystallinity.
Co-reporter:Lifeng Wang;Bin Wu;Hongtao Liu;Li Huang;Yongtao Li;Wei Guo;Xin Chen;Peng Peng;Lei Fu;Yunchang Yang;PingAn Hu
Materials Chemistry Frontiers 2017 vol. 1(Issue 9) pp:1836-1840
Publication Date(Web):2017/08/23
DOI:10.1039/C7QM00100B
Growth control over the size and shape of two-dimensional hexagonal boron nitride domains is vital for its applications. Here we develop a rational water-assisted chemical vapor deposition method that allows fast growth of large-sized (more than 330 μm) single crystal domains, which are 3–5 times larger than those previously grown on solid Cu or Cu–Ni alloy. Further kinetic control results in the perfect evolution of the domain shape from negatively curved triangle, triangle, positively curved triangle, regular hexagon, polygon, to circle. This work addresses the existing major problems, paving a way for the synthesis of materials with better control.
Co-reporter:Longxian Shi;Yunlong Guo;Wenping Hu
Materials Chemistry Frontiers 2017 vol. 1(Issue 12) pp:2423-2456
Publication Date(Web):2017/11/22
DOI:10.1039/C7QM00169J
To date, versatile polymer semiconductors have been reported for field-effect transistors (FETs). And the third-generation donor–acceptor (D–A) polymers have been among the most intensively studied semiconductors. Meanwhile, there are a variety of methods adopted for the enhancement of performance. To the best of our knowledge, a p-type polymer semiconductor with a highest hole mobility of 52.7 cm2 V−1 s−1, an n-type polymer semiconductor with a highest electron mobility of 8.5 cm2 V−1 s−1 and a balanced ambipolar semiconductor with the highest both hole and electron mobility of over 4 cm2 V−1 s−1 have been achieved. This review describes building block selection, backbone halogenation, side chain engineering and random copolymerization, which are the effective synthesis approaches applied in this field, affording assistance for developing high-performance polymer semiconductors in the future.
Co-reporter:Xin Chen, Bin Wu and Yunqi Liu
Chemical Society Reviews 2016 vol. 45(Issue 8) pp:2057-2074
Publication Date(Web):05 Feb 2016
DOI:10.1039/C5CS00542F
Graphene, an amazing two-dimensional material with excellent physical properties, has attracted great attention in various disciplines. Both fundamental studies and applications require graphene samples with controlled parameters including their quality, size, crystallinity, layer number and so on. While graphene can be prepared by direct exfoliation from mother materials or growth on transition metals, the uncontrolled production or the additional complex transfer process has been challenging for graphene applications. Direct preparation on a desired dielectric substrate is an important research direction that potentially addresses these problems. Many advances have been made in the past few years, and this tutorial review provides a brief summary of ways of preparing graphene on dielectric substrates. Various methods including the annealing method, direct chemical vapor deposition graphene synthesis on conventional dielectric substrates and hexagonal boron nitride layers are systematically reviewed and discussed. The main problems and further directions in this field are also presented.
Co-reporter:Hanlin Wang;Hongtao Liu;Qiang Zhao;Cheng Cheng;Wenping Hu
Advanced Materials 2016 Volume 28( Issue 4) pp:624-630
Publication Date(Web):
DOI:10.1002/adma.201503953
Co-reporter:Shang-hui Ye, Tian-qing Hu, Zhou Zhou, Min Yang, Qun-bo Mei, Yun-qi Liu, Li-ping Liu, Bang-cheng Zhai, Zhen-hong Jia, Wei Huang
Organic Electronics 2016 Volume 33() pp:235-245
Publication Date(Web):June 2016
DOI:10.1016/j.orgel.2016.03.025
Cost-effective fabrication of white organic light-emitting diodes (WOLED) is meaningful toward commercial application of environment-friendly solid-state lighting sources. Electroluminescent efficiency and color quality are two opposite performance characteristics facing solution processed WOLEDs requiring balanced consideration. Herein, a recently synthesized molecule of 4,4’-(9,9’-(1,3-phenylene)bis(9H-fluorene-9,9-diyl))bis(N,N-diphenylaniline) (DTPAFB) is introduced as a host material for solution processed all-phosphor WOLEDs, embracing four well-known molecules which are blue iridium (III) bis(2-(4,6-difluorophenyl)pyridinato-N,C2)(picolinate) (FIrpic), green iridium (III) bis[2-(2-pyridinyl-N)phenyl-C](2,4-pentanedionato-O2,O4) [Ir(ppy)2(acac)], and orange iridium (III) bis(2-phenyl-benzothiazole-C2,N)(acetylacetonate) [Ir(bt)2(acac)] plus a home-made red phosphor of iridium (III) tris(1-(2,6-dimethylphenoxy)-4-(4-chlorophenyl)phthalazine) [Ir(MPCPPZ)3]. Illumination quality white light with high brightness, high efficiency, suitable correlated color temperature (CCT), high color-rendering index (CRI), and stable electroluminescent (EL) emission is obtained. A stable white emission with a CRI over 70, Commission Internationale de L'Eclairage (CIE) of (0.37, 0.42), and high EL efficiency of 19.6 lm W−1 at high luminance of 2000 cd m−2 for blue/orange complementary color WOLEDs is demonstrated. The optimized red/green/blue three primary color WOLEDs show improved CRI up to 81, moderate high efficiency of 25.8 cd A−1, 14.4 lm W−1, and EQE of 13.9%. Furthermore, the red/green/blue/orange four primary color WOLEDs show the optional balance between color quality and EL efficiency with high CRI of around 81–83 and medium CCT of 3755–3929 K which is warm and soft to human eyes. At an illumination relevant luminance of 1000 cd m−2, the total power efficiency reaches 33.6 lm W−1, and still remains 30.2 lm W−1 at 3000 cd m−2, approaching the efficiency of state-of-the-art fluorescent-tube (40–70 lm W−1), potentially suitable as an environment-friendly solid-state lighting source. This work indicates that developing high performance host materials and highly efficient phosphors and carefully combining them with common phosphors is an effective way toward high performance WOLEDs.Solution processed single emissive layer white OLEDs containing Red/Green/Blue/Orange four primary phosphors have been fabricated, which exhibit stable warm-white emission covering the whole visible spectrum region. High brightness of 34010.9–39627.3 cd m−2, high CRI value up to 83, and suitable CCT of around 3400, plus high efficiency of 28.9 cd A−1 have been realized.
Co-reporter:Ping Li;Hanlin Wang;Lanchao Ma;Long Xu;Fei Xiao;Zhengran Yi
Science China Chemistry 2016 Volume 59( Issue 6) pp:679-683
Publication Date(Web):2016 June
DOI:10.1007/s11426-015-0511-9
Balanced carrier transport is observed in acceptor-acceptor (A-A′) type polymer for ambipolar organic thin-film transistors (OTFTs). It is found that the incorporation of two electron-accepting moieties (BTz and IIG) into a polymer main chain to form A-A′ polymer PIIG-BTz could lower highest occupied molecular orbital (HOMO) and lowest unoccupied molecular orbital (LUMO) levels and facilitate good molecular stacking of the polymer. Ambipolar transistor behaviour for PIIG-BTz, with the balanced hole and electron mobilities of 0.030 and 0.022 cm2 V−1 s−1 was observed in OTFT devices, respectively. The study in this work reveals that the utilization of acceptor-acceptor (A-A′) structure in polymer main chain can be a feasible strategy to develop ambipolar polymer semiconductors.
Co-reporter:Daoben Zhu;Deqing Zhang
Science China Chemistry 2016 Volume 59( Issue 6) pp:651-652
Publication Date(Web):2016 June
DOI:10.1007/s11426-016-5602-3
Co-reporter:Huajie Chen, Zhaoxia Liu, Zhiyuan Zhao, Liping Zheng, Songting Tan, Zhihong Yin, Chunguang Zhu, and Yunqi Liu
ACS Applied Materials & Interfaces 2016 Volume 8(Issue 48) pp:
Publication Date(Web):November 15, 2016
DOI:10.1021/acsami.6b12540
Five-membered 1,3,4-oxadiazole (OZ) and 1,3,4-thiadiazole (TZ) heterocycle-based copolymers as active layer have long been ignored in solution-processable n-channel polymer field-effect transistors (PFETs) despite the long history of using OZ or TZ derivatives as the electron-injecting materials in organic light-emitting devices and their favorable electron affinities. Herein, we first report the synthesis and PFETs performance of two n-channel conjugated polymers bearing OZ- or TZ-based acceptor moieties, i.e., PNOZ and PNTZ, where simple thiophene units are utilized as the weak donors and additional alkylated-naphthalenediimides units are used as the second acceptors. A comparative study has been performed to reveal the effect of different heterocyclic acceptors on thermal properties, electronic properties, ordering structures, and carrier transport performance of the target polymers. It is found that both polymers possess low-lying LUMO values below −4.0 eV, indicating high electron affinity for both heterocycle-based polymers. Because of strong polarizable ability of sulfur atom in TZ heterocycle, PNTZ exhibits a red shift in maximal absorption and stronger molecular aggregation even in the diluted chlorobenzene solution as compared to the OZ-containing PNOZ. Surface morphological study reveals that a nodule-like surface with a rough surface morphology is observed clearly for PNOZ films, whereas PNTZ films display highly uniform surface morphology with well interconnected fiber-like polycrystalline grains. Investigation of PFETs performance indicates that both polymers afford air-stable n-channel transport characteristics. The uniform morphological structure and compact π–π stacking endow PNTZ with a high electron mobility of 0.36 cm2 V–1 s–1, much higher than that of PNOZ (0.026 cm2 V–1 s–1). These results manifest the feasibility in improving electron-transporting property simply by tuning heteroatom substitutes in n-channel polymers; further demostrate that TZ derivatives possess much superior potential for developing high-performance n-channel polymers compared to OZ derivatives.Keywords: 1,3,4-oxadiazole; 1,3,4-thiadiazole; air-stable; high performance; n-channel field-effect transistors;
Co-reporter:Zhengran Yi;Shuai Wang
Advanced Materials 2015 Volume 27( Issue 24) pp:3589-3606
Publication Date(Web):
DOI:10.1002/adma.201500401

Since the report of the first diketopyrrolopyrrole (DPP)-based polymer semiconductor, such polymers have received considerable attention as a promising candidate for high-performance polymer semiconductors in organic thin-film transistors (OTFTs). This Progress Report summarizes the advances in the molecular design of high-mobility DPP-based polymers reported in the last few years, especially focusing on the molecular design of these polymers in respect of tuning the backbone and side chains, and discussing the influences of structural modification of the backbone and side chains on the properties and device performance of corresponding DPP-based polymers. This provides insights for the development of new and high-mobility polymer semiconductors.

Co-reporter:Lifeng Wang;Bin Wu;Lili Jiang;Jisi Chen;Yongtao Li;Wei Guo;Pingan Hu
Advanced Materials 2015 Volume 27( Issue 33) pp:4858-4864
Publication Date(Web):
DOI:10.1002/adma.201501166
Co-reporter:Lanchao Ma, Zhengran Yi, Shuai Wang, Yunqi Liu and Xiaowei Zhan
Journal of Materials Chemistry A 2015 vol. 3(Issue 9) pp:1942-1948
Publication Date(Web):17 Dec 2014
DOI:10.1039/C4TC02462A
A new copolymer (P(DPP4T-co-BDT)) was synthesized by Stille coupling polymerization of 3,6-bis(5′-bromo-[2,2′-bithiophen]-5-yl)-2,5-bis(2-octyldodecyl)pyrrolo-[3,4-c]-pyrrole-1,4(2H,5H)-dione and 2,6-bis(trimethyltin)-4,8-dimethoxybenzo[1,2-b:3,4-b′]dithiophene. P(DPP4T-co-BDT) showed good solution processability, good thermal stability with decomposition temperature of >330 °C, and strong and broad absorption in the range of 500–900 nm. Field-effect transistors based on P(DPP4T-co-BDT) thin films exhibited a hole mobility of up to 0.047 cm2 V−1 s−1, an on/off current ratio of 106, and a threshold voltage of −5 V after thermal annealing at 200 °C. Thin film phototransistors based on P(DPP4T-co-BDT) exhibited a photoresponsivity of up to 4.0 × 103 A W−1 and a photocurrent/dark-current ratio of 6.8 × 105 under white light irradiation with a low light intensity (9.7 μW cm−2).
Co-reporter:Wei Guo, Bin Wu, Yongtao Li, Lifeng Wang, Jisi Chen, Bingyan Chen, Zhiyong Zhang, Lianmao Peng, Shuai Wang, and Yunqi Liu
ACS Nano 2015 Volume 9(Issue 6) pp:5792
Publication Date(Web):May 19, 2015
DOI:10.1021/acsnano.5b01827
Grains and grain boundaries (GBs) in graphene are vital for the control of its properties; however, engineering or controlling them by growth remains a great challenge. Here we discover that the dynamic formation of GBs within chemical vapor deposited polygonal graphene flakes is described by a geometric rule. A GB is formed to be symmetrically tilted and a continuous straight line, and the key parameters including end point, direction of GB line, and misorientation angles between adjacent graphene grains can be determined solely by the geometries of the polygonal graphene flakes. We also show the growth control over the length of straight graphene GB lines and demonstrate the capability of parallel fabrication of field-effect transistor devices across predicted GBs in a straightforward manner. This work constitutes a significant step forward in engineering grains and GBs in graphene.Keywords: anisotropic etching; chemical vapor deposition; dynamic formation; grain boundaries; graphene;
Co-reporter:Jianyi Chen;Yunlong Guo;Lili Jiang;Zhiping Xu;Liping Huang;Yunzhou Xue;Dechao Geng;Bin Wu;Wenping Hu;Gui Yu
Advanced Materials 2014 Volume 26( Issue 9) pp:1348-1353
Publication Date(Web):
DOI:10.1002/adma.201304872
Co-reporter:Lifeng Wang;Bin Wu;Jisi Chen;Hongtao Liu;Pingan Hu
Advanced Materials 2014 Volume 26( Issue 10) pp:1559-1564
Publication Date(Web):
DOI:10.1002/adma.201304937
Co-reporter:Hanlin Wang;Cheng Cheng;Lei Zhang;Hongtao Liu;Yan Zhao;Yunlong Guo;Wenping Hu;Gui Yu
Advanced Materials 2014 Volume 26( Issue 27) pp:4683-4689
Publication Date(Web):
DOI:10.1002/adma.201400697
Co-reporter:Xiaotong Liu;Yunlong Guo;Yongqiang Ma;Huajie Chen;Zupan Mao;Hanlin Wang;Gui Yu
Advanced Materials 2014 Volume 26( Issue 22) pp:3631-3636
Publication Date(Web):
DOI:10.1002/adma.201306084
Co-reporter:Zheye Zhang;Fei Xiao;Lihua Qian;Junwu Xiao;Shuai Wang
Advanced Energy Materials 2014 Volume 4( Issue 10) pp:
Publication Date(Web):
DOI:10.1002/aenm.201400064

The integration of graphene nanosheets on the macroscopic level using a self-assembly method has been recognized as one of the most effective strategies to realize the practical applications of graphene materials. Here, a facile and scalable method is developed to synthesis two types of graphene-based networks, manganese dioxide (MnO2)–graphene foam and carbon nanotube (CNT)–graphene foam, by solution casting and subsequent electrochemical methods. Their practical applications in flexible all-solid-state asymmetric supercapacitors are explored. The proposed method facilitates the structural integration of graphene foam and the electroactive material and offers several advantages including simplicity, efficiency, low-temperature, and low-cost. The as-prepared MnO2–graphene and CNT–graphene electrodes exhibit high specific capacitances and rate capability. By using polymer gel electrolytes, a flexible all-solid-state asymmetric supercapacitor was synthesized with MnO2–graphene foam as the positive electrode and CNT-graphene as the negative electrode. The asymmetric supercapacitors can be cycled reversibly in a high-voltage region of 0 to 1.8 V and exhibit high energy density, remarkable rate capability, reasonable cycling performance, and excellent flexibility.

Co-reporter:Ying Liu, Zhiyang Liu, Hao Luo, Xiaodong Xie, Ling Ai, Ziyi Ge, Gui Yu and Yunqi Liu
Journal of Materials Chemistry A 2014 vol. 2(Issue 41) pp:8804-8810
Publication Date(Web):22 Aug 2014
DOI:10.1039/C4TC01688B
An efficient synthetic approach to a series of benzothieno[2,3-b]thiophene (BTT) derivatives used as an important core with different bridge spacers is described. Thermal properties of the present compounds are stable: neither phase transition nor thermal decomposition was observed up to 300 °C. The adjacent molecule crystal stackings are shifted affording a nearly 1/3 intermolecular π-overlap. The OFETs based on BTTB exhibit excellent field-effect performances with a mobility of 0.46 cm2 V−1 s−1 and on–off current ratios larger than 107 at room temperature. All the results demonstrate these benzothieno[2,3-b]thiophene derivatives as promising materials for optoelectronic devices.
Co-reporter:Yunzhou Xue, Bin Wu, Hongtao Liu, Jiahui Tan, Wenping Hu and Yunqi Liu
Physical Chemistry Chemical Physics 2014 vol. 16(Issue 38) pp:20392-20397
Publication Date(Web):01 Aug 2014
DOI:10.1039/C4CP02935F
Large-area substitutional phosphorus–nitrogen co-doped monolayer graphene is directly synthesized on a Cu surface by chemical vapor deposition using molecules of phosphonitrilic chloride trimer as the phosphorus and nitrogen sources. The doping levels of both phosphorus and nitrogen atoms decrease as a function of the growth temperature. In contrast, the doping effect is enhanced with temperature because of the formation of more stable bond configurations for dopants at higher temperatures. Moreover, the doping amount of nitrogen atoms is always higher than that of phosphorus atoms at all used temperatures. The phosphorus and nitrogen co-doped graphene exhibits remarkable air-stable n-type characteristics. This work demonstrates the critical role of phosphorus atoms in achieving enhanced electron donation compared to nitrogen atom doping of graphene, and is important for various applications associated with the need for air-stable n-type graphene materials.
Co-reporter:Shugang Li, Lanchao Ma, Chao Hu, Ping Deng, Yibing Wu, Xiaowei Zhan, Yunqi Liu, Qing Zhang
Dyes and Pigments 2014 Volume 109() pp:200-205
Publication Date(Web):October 2014
DOI:10.1016/j.dyepig.2014.05.019
•The first N-acylated isoindigo monomer was reported.•Polymers based on the new monomer showed broad absorptions and deep LUMO levels.•The new polymers were studied as semiconductors in OTFT devices.Donor/acceptor polymers with N-acylated isoindigo as acceptor units have been synthesized. The thermal, optical, electrochemical, and charge-transport properties of the polymers have been investigated. The new polymers show broad absorption from 450 to 900 nm. Due to the strong electron accepting characteristic of N-acylated isoindigo, the new polymers exhibit narrow optical band gaps and deep LUMO energy levels compared with the polymers based on N-alkylated isoindigo. The new polymers show n-type transport behavior and balanced ambipolar transport behavior in organic thin film transistors (OTFT) device.
Co-reporter:Jing Huang;Runli Tang;Tian Zhang; Qianqian Li; Gui Yu;Shuyi Xie; Yunqi Liu;Dr. Shanghui Ye; Jingui Qin; Zhen Li
Chemistry - A European Journal 2014 Volume 20( Issue 18) pp:5317-5326
Publication Date(Web):
DOI:10.1002/chem.201303522

Abstract

Two aggregation-induced emission active luminogens (TPE–pTPA and TPE–mTPA) were successfully synthesized. For comparison, another six similar compounds were prepared. Because of the introduced hole-dominated triphenylamine (TPA), fluorene groups with high luminous efficiency, and unconjugated linkages, the π conjugation length of the obtained luminogens is effectively restricted to ensure their blue emission. The undoped organic light-emitting diodes based on TPE–pTPA and TPE–mTPA exhibited blue or deep-blue emissions, low turn-on voltages (3 V), and high electroluminescence efficiencies with Lmax, ηC,max, and ηP,max values of up to 26 697 cd m−2, 3.37 cd A−1, and 2.40 Lm W−1.

Co-reporter:Dacheng Wei, Bin Wu, Yunlong Guo, Gui Yu, and Yunqi Liu
Accounts of Chemical Research 2013 Volume 46(Issue 1) pp:106
Publication Date(Web):July 19, 2012
DOI:10.1021/ar300103f
Because of its atomic thickness, excellent properties, and widespread applications, graphene is regarded as one of the most promising candidate materials for nanoelectronics. The wider use of graphene will require processes that produce this material in a controllable manner. In this Account, we focus on our recent studies of the controllable chemical vapor deposition (CVD) growth of graphene, especially few-layer graphene (FLG), and the applications of this material in electronic devices.CVD provides various means of control over the morphologies of the produced graph ene. We studied several variables that can affect the CVD growth of graphene, including the catalyst, gas flow rate, growth time, and growth temperature and successfully achieved the controlled growth of hexagonal graphene crystals. Moreover, we developed several modified CVD methods for the controlled growth of FLGs. Patterned CVD produced FLGs with desired shapes in required areas. By introducing dopant precursor in the CVD process, we produced substitutionally doped FLGs, avoiding the typically complicated post-treatment processes for graphene doping. We developed a template CVD method to produce FLG ribbons with controllable morphologies on a large scale. An oxidation-activated surface facilitated the CVD growth of polycrystalline graphene without the use of a metal catalyst or a complicated postgrowth transfer process.In devices, CVD offers a controllable means to modulate the electronic properties of the graphene samples and to improve device performance. Using CVD-grown hexagonal graphene crystals as the channel materials in field-effect transistors (FETs), we improved carrier mobility. Substitutional doping of graphene in CVD opened a band gap for efficient FET operation and modulated the Fermi energy level for n-type or p-type features. The similarity between the chemical structure of graphene and organic semiconductors suggests potential applications of graphene in organic devices. We used patterned CVD FLGs as the bottom electrodes in pentacene FETs. The strong π–π interactions between graphene and pentacene produced an excellent interface with low contact resistance and a reduced injection barrier, which dramatically enhances the device performance. We also fabricated reversible nanoelectromechanical (NEM) switches and a logic gate using the FLG ribbons produced using our template CVD method.In summary, CVD provides a controllable means to produce graphene samples with both large area and high quality. We developed several modified CVD methods to produce FLG samples with controlled shape, location, edge, layer, dopant, and growth substrate. As a result, we can modulate the properties of FLGs, which provides materials that could be used in FETs, OFETs, and NEM devices. Despite remarkable advances in this field, further exploration is required to produce consistent, homogeneous graphene samples with single layer, single crystal, and large area for graphene-based electronics.
Co-reporter:Lili Jiang;Tianzhong Yang;Fei Liu;Jing Dong;Zhaohui Yao;Chengmin Shen;Shaozhi Deng;Ningsheng Xu;Hong-Jun Gao
Advanced Materials 2013 Volume 25( Issue 2) pp:250-255
Publication Date(Web):
DOI:10.1002/adma.201203902
Co-reporter:Lili Jiang;Tianzhong Yang;Fei Liu;Jing Dong;Zhaohui Yao;Chengmin Shen;Shaozhi Deng;Ningsheng Xu;Hong-Jun Gao
Advanced Materials 2013 Volume 25( Issue 2) pp:
Publication Date(Web):
DOI:10.1002/adma.201370010
Co-reporter:Jianyi Chen;Yunlong Guo;Yugeng Wen;Liping Huang;Yunzhou Xue;Dechao Geng;Bin Wu;Birong Luo;Gui Yu
Advanced Materials 2013 Volume 25( Issue 7) pp:992-997
Publication Date(Web):
DOI:10.1002/adma.201202973
Co-reporter:Jianyi Chen;Yunlong Guo;Yugeng Wen;Liping Huang;Yunzhou Xue;Dechao Geng;Bin Wu;Birong Luo;Gui Yu
Advanced Materials 2013 Volume 25( Issue 7) pp:
Publication Date(Web):
DOI:10.1002/adma.201370040
Co-reporter:Lili Jiang;Bin Wu;Hongtao Liu;Yuan Huang;Jianyi Chen;Dechao Geng;Hongjun Gao
Advanced Materials 2013 Volume 25( Issue 48) pp:7015-7019
Publication Date(Web):
DOI:10.1002/adma.201302941
Co-reporter:Yan Zhao;Yunlong Guo
Advanced Materials 2013 Volume 25( Issue 38) pp:5372-5391
Publication Date(Web):
DOI:10.1002/adma.201302315

Abstract

The advantages of organic field-effect transistors, such as low cost, mechanical flexibility and large-area fabrication, make them potentially useful for electronic applications such as flexible switching backplanes for video displays, radio frequency identifications and so on. A large amount of molecules were designed and synthesized for electron transporting (n-type) and ambipolar organic semiconductors with improved performance and stability. In this review, we focus on the advances in performance and molecular design of n-type and ambipolar semiconductors reported in the past few years.

Co-reporter:Lei Zhang;Hanlin Wang;Yan Zhao;Yunlong Guo;Wenping Hu;Gui Yu
Advanced Materials 2013 Volume 25( Issue 38) pp:5455-5460
Publication Date(Web):
DOI:10.1002/adma.201300675
Co-reporter:Dechao Geng ; Bin Wu ; Yunlong Guo ; Birong Luo ; Yunzhou Xue ; Jianyi Chen ; Gui Yu
Journal of the American Chemical Society 2013 Volume 135(Issue 17) pp:6431-6434
Publication Date(Web):April 16, 2013
DOI:10.1021/ja402224h
An anisotropic etching mode is commonly known for perfect crystalline materials, generally leading to simple Euclidean geometric patterns. This principle has also proved to apply to the etching of the thinnest crystalline material, graphene, resulting in hexagonal holes with zigzag edge structures. Here we demonstrate for the first time that the graphene etching mode can deviate significantly from simple anisotropic etching. Using an as-grown graphene film on a liquid copper surface as a model system, we show that the etched graphene pattern can be modulated from a simple hexagonal pattern to complex fractal geometric patterns with sixfold symmetry by varying the Ar/H2 flow rate ratio. The etched fractal patterns are formed by the repeated construction of a basic identical motif, and the physical origin of the pattern formation is consistent with a diffusion-controlled process. The fractal etching mode of graphene presents an intriguing case for the fundamental study of material etching.
Co-reporter:Huajie Chen, Yunlong Guo, Zupan Mao, Gui Yu, Jianyao Huang, Yan Zhao, and Yunqi Liu
Chemistry of Materials 2013 Volume 25(Issue 18) pp:3589
Publication Date(Web):September 5, 2013
DOI:10.1021/cm401130n
We report the synthesis of two novel donor–acceptor copolymers poly{[N, N′-bis(alkyl)-1,4,5,8-naphthalene diimide-2,6-diyl-alt-5,5′-di(thiophen-2-yl)-2,2′-(E)-2-(2-(thiophen-2-yl)vinyl)thiophene]} (PNVTs) based on naphthalenediimide (NDI) acceptor and (E)-2-(2-(thiophen-2-yl)vinyl)thiophene donor. The incorporations of vinyl linkages into polymer backbones maintain the energy levels of the lowest unoccupied molecular orbits at −3.90 eV, therefore facilitating the electron injection. Moreover, the energy levels of the highest occupied molecular orbits increase from −5.82 to −5.61 eV, successfully decreasing the hole injection barrier. Atomic force microscopy measurements indicate that PNVTs thin films exhibit larger polycrystalline grains compared with that of poly{[N, N′-bis(2-octyldodecyl)-1,4,5,8-naphthalene diimide-2,6-diyl]-alt- 5,5′-(2,2′-bithiophene)} [P(NDI2OD-T2)], consistent with the stronger π–π stacking measured by grazing incidence X-ray scatting. To optimize devices performance, field-effect transistors (FETs) with three devices configurations have been investigated. The results indicate that the electron mobility of the vinyl-containing PNVTs exhibit about 3–5 times higher than that of P(NDI2OD-T2). Additionally, the vinyl-linkages in PNVTs remarkably enhance ambipolar transport of their top-gate FETs, obtaining high hole and electron mobilities of 0.30 and 1.57 cm2 V–1 s–1, respectively, which are among the highest values reported to date for the NDI-based polymers. Most importantly, ambipolar inverters have been realized in ambient, exhibiting a high gain of 155. These results provide important progresses in solution-processed ambipolar polymeric FETs and complementary-like inverters.Keywords: ambipolar transistors; complementary-like inverters; high performance; naphthalenediimide; vinyl linkages;
Co-reporter:Zhengran Yi, Lanchao Ma, Bing Chen, Dugang Chen, Xingguo Chen, Jingui Qin, Xiaowei Zhan, Yunqi Liu, Wen Jie Ong, and Jun Li
Chemistry of Materials 2013 Volume 25(Issue 21) pp:4290
Publication Date(Web):October 15, 2013
DOI:10.1021/cm402381w
Two new diketopyrrolopyrrole-based π-conjugated copolymers (PDPP6T and PDPP7T) have been synthesized by Stille coupling polymerization of 3,6-bis(5′-bromo-[2,2′-bithiophen]-5-yl)-2,5-bis(2-octyldodecyl)pyrrolo-[3,4-c]pyrrole-1,4(2H,5H)-dione with α,α′-bis(trimethylstannyl)-bithiophene and α,α′-bis(trimethylstannyl)-terthiophene, respectively. The impressive high mobility of 3.94 cm2 V–1 s–1 for the polymer with sextetthiophene (6T) and of 2.82 cm2 V–1s–1 for polymer with septetthiophene (7T) is acquired. It is found that the introduction of longer β-unsubstituted oliogothiophene unit in DPP-based copolymers has a great influence on the molecular weight and solubility of the DPP-oligothiophene copolymers that finally affects the organic thin-film transistor (OTFT) performances, indicating that a suitable number of thiophene group in β-unsubstituted oligothiophene exists for such a kind of copolymer to exhibit the best OTFT performances. This work also reveals the significance in the design of D–A copolymers for OTFTs through regulating the balance between π–π stacking of intermolecular chains and molecular weight as well as solubility of the rigid main chain.Keywords: donor−acceptor copolymer; hole mobility; organic thin-film transistors;
Co-reporter:Bin Wu, Dechao Geng, Zhiping Xu, Yunlong Guo, Liping Huang, Yunzhou Xue, Jianyi Chen, Gui Yu and Yunqi Liu
NPG Asia Materials 2013 5(2) pp:e36
Publication Date(Web):2013-02-01
DOI:10.1038/am.2012.68
The phenomenon of ordered pattern formation is universal in nature but involves complex non-equilibrium processes that are highly important for both fundamental research and applied materials systems. Among countless pattern systems, a snowflake is possibly the most fascinating example offered by nature. Here, we report that single-layered and single-crystalline graphene flakes (GFs) with highly regular and hexagonal symmetric patterns can be grown on a liquid copper surface using a CH4 chemical vapor deposition (CVD) method. The different morphologies of these GFs can be precisely tailored by varying the composition of the inert gas/H2 carrier gas mixture used to produce the GFs, and the GF edges can be continuously tuned over the full spectrum from negative to zero to positive curvature in a controllable way. The family of GF crystal patterns is remarkably analogous to that of snowflakes, representing an ideal two-dimensional (2D) growth system. Pattern formations from compact to dendritic GFs can be explained by the continuous modulation of the competition between adatom diffusion along island edges or corners and surface diffusion processes.
Co-reporter:Xiaotong Liu, Hongyan Zhang, Yongqiang Ma, Xiaoli Wu, Lixuan Meng, Yunlong Guo, Gui Yu and Yunqi Liu
Journal of Materials Chemistry A 2013 vol. 1(Issue 5) pp:1875-1884
Publication Date(Web):20 Nov 2012
DOI:10.1039/C2TA00173J
A new form of graphene-coated silica (GCS) has been prepared by mixing exfoliated graphene oxide with acid-treated silica and reducing it with hydrazine hydrate so that it coats the silica particles. This method is simple, convenient, and robust. The GCS composite particles have been characterized using optical photographs, Raman spectroscopy, Fourier transform infrared spectroscopy (FT-IR), X-ray diffraction (XRD), thermogravimetric analysis (TGA), Brunauer–Emmett–Teller (BET) analysis, and elemental analysis. These analyses show that the reaction effectively coats silica particles with graphene. The composite particles achieve higher levels of adsorption and are more widely applicable than five other sorbents (graphite carbons, activated carbon, pure graphene, C18 silica, and silica) for the eleven pesticides assayed. We discuss the adsorption mechanism and consider it to be dependent on the electron-donating abilities of the S, P, and N atoms and the strong π-bonding network of the benzene rings. This research demonstrates that graphene-based composite materials could be used to remove pesticide residues in aqueous environments.
Co-reporter:Hongtao Liu, Lei Zhang, Yunlong Guo, Cheng Cheng, Lianjiang Yang, Lang Jiang, Gui Yu, Wenping Hu, Yunqi Liu and Daoben Zhu
Journal of Materials Chemistry A 2013 vol. 1(Issue 18) pp:3104-3109
Publication Date(Web):27 Feb 2013
DOI:10.1039/C3TC00067B
A novel reducing reagent, Lawesson's reagent (LR), is used to directly reduce graphene oxide (GO) films and single GO sheets. The as-prepared reduced graphene oxide (GOLR) is fully characterized by XPS, Raman, FTIR, 13C NMR and XRD. Most of the oxygen-containing groups are efficiently removed by LR and the conjugated graphene networks are restored. Highly conductive GOLR films and sheets are obtained. As a proof of concept, thin film field-effect transistors based on pentacene using patterned GOLR films as electrodes are fabricated and show high performances. Common cotton threads coated with GOLR can be used as flexible connecting wires to illuminate commercial light-emitting diodes. After low temperature annealing, such as 300 °C, higher conductivity and mobility of GOLR are obtained due to the removal of additional oxygen groups and better ordering of graphene sheets.
Co-reporter:Chunmeng Yu, Yunlong Guo, Hongtao Liu, Ni Yan, Zhiyan Xu, Gui Yu, Yu Fang and Yunqi Liu
Chemical Communications 2013 vol. 49(Issue 58) pp:6492-6494
Publication Date(Web):30 May 2013
DOI:10.1039/C3CC42377H
Swift fabrication of a non-covalently modified reduced graphene oxide electronic sensor has been developed. An unparalleled detection limit is demonstrated for Hg2+, down to the picomolar range.
Co-reporter:Zheye Zhang, Fei Xiao, Yunlong Guo, Shuai Wang, and Yunqi Liu
ACS Applied Materials & Interfaces 2013 Volume 5(Issue 6) pp:2227
Publication Date(Web):February 21, 2013
DOI:10.1021/am303299r
We reported the development of a new type of multifunctional titanium dioxide (TiO2)-graphene nanocomposite hydrogel (TGH) by a facile one-pot hydrothermal approach and explored its environmental and energy applications as photocatalyst, reusable adsorbents, and supercapacitor. During the hydrothermal reaction, the graphene nanosheets and TiO2 nanoparticles self-assembled into three-dimensional (3D) interconnected networks, in which the spherical nanostructured TiO2 nanoparticles with uniform size were densely anchored onto the graphene nanosheets. We have shown that the resultant TGH displayed the synergistic effects of the assembled graphene nanosheets and TiO2 nanoparticles and therefore exhibited a unique collection of physical and chemical properties such as increased adsorption capacities, enhanced photocatalytic activities, and improved electrochemical capacitive performance in comparison with pristine graphene hydrogel and TiO2 nanoparticles. These features collectively demonstrated the potential of 3D TGH as an attractive macroscopic device for versatile applications in environmental and energy storage issues.Keywords: adsorbents; graphene hydrogel; photocatalyst; self-assembly; supercapacitor; titanium dioxide nanoparticles;
Co-reporter:Cheng Cheng, Chunmeng Yu, Yunlong Guo, Huajie Chen, Yu Fang, Gui Yu and Yunqi Liu
Chemical Communications 2013 vol. 49(Issue 20) pp:1998-2000
Publication Date(Web):07 Jan 2013
DOI:10.1039/C2CC38811A
A diketopyrrolopyrrole–thiazolothiazole copolymer with a short π–π stacking distance (3.52 Å), due to the introduction of heteroaromatic rings, exhibits a high charge mobility above 3.40 cm2 V−1 s−1 at a relatively gentle annealing temperature.
Co-reporter:Ti Wu;Jianming Chen;Yunlong Guo; Gui Yu; Zhigang Shuai; Yunqi Liu
Asian Journal of Organic Chemistry 2013 Volume 2( Issue 3) pp:220-224
Publication Date(Web):
DOI:10.1002/ajoc.201200119
Co-reporter:Ti Wu;Jianming Chen;Yunlong Guo; Gui Yu; Zhigang Shuai; Yunqi Liu
Asian Journal of Organic Chemistry 2013 Volume 2( Issue 3) pp:
Publication Date(Web):
DOI:10.1002/ajoc.201390006
Co-reporter:Xinjun Xu, Gui Yu, Yongqiang Ma, Kefeng Shao, Lianming Yang, Yunqi Liu
Journal of Luminescence 2013 Volume 136() pp:208-211
Publication Date(Web):April 2013
DOI:10.1016/j.jlumin.2012.11.036
Electromer is a unique excited-state species which can only be formed under electrical excitation. Currently, a clear understanding of electromer has not been realized yet. A big obstacle is that the electromer emission can hardly be separated from the emission of molecular excitons. Obtaining a complete electromer emission is essential for photophysical investigations of this kind of excited-state species and is useful for its potential application in optoelectronic logic gates. We report that a complete electromer emission can be achieved by introduction of a weak-fluorescence layer in organic light-emitting diodes, which will quench the molecular excitons produced in the adjacent emissive layer but leave the electromers undisturbed. In addition, a possible mechanism for the electromer formation is proposed based on the analysis of the single crystal structure of the compound 9,9-bis[4-(di-p-tolyl)aminophenyl]-2,7-bis(9-carbazolyl)fluorene which can produce electromers.Highlights► A complete electromer emission in OLEDs has been achieved. ► A weak-fluorescence layer quenches molecular excitons in the adjacent emissive layer. ► Packing of triarylamines in the neighboring molecules causes electromer formation.
Co-reporter:Wen-bo Wu;Shang-hui Ye;Li-jin Huang;Gui Yu
Chinese Journal of Polymer Science 2013 Volume 31( Issue 10) pp:1432-1442
Publication Date(Web):2013 October
DOI:10.1007/s10118-013-1328-2
A new conjugated hyperbranched polymer (hb-TFO) containing tetraphenylethylene (TPE) units, a famous aggregation-induced emission (AIE) active group, as the core, was synthesized successfully with modest yield via one-pot Suzuki polymerization reaction. Thanks to the introduction of TPE moieties, hb-TFO exhibited aggregation-enhanced emission (AEE) property, and could work as explosive chemosensor with high sensitivity. The polymeric light-emitting diode (PLED) device was fabricated to investigate its electroluminescent property, and hb-TFO demonstrated a maximum luminance efficiency of 0.22 cd/A and a maximum brightness of 545 cd/m2 at 15.9 V.
Co-reporter:Xingang Zhao, Lanchao Ma, Lei Zhang, Yugeng Wen, Jianming Chen, Zhigang Shuai, Yunqi Liu, and Xiaowei Zhan
Macromolecules 2013 Volume 46(Issue 6) pp:
Publication Date(Web):March 8, 2013
DOI:10.1021/ma302428x
A new solution-processable conjugated copolymer (P1) of perylene diimide (PDI) and dithienothiophene (DTT) incorporating acetylene spacers was synthesized by palladium(0)-catalyzed Sonogashira coupling reaction. Theory calculation reveals that introduction of rod-like ethynylene spacer in the polymer main chain promotes planarity and π-conjugation of the polymer main chain. Relative to the conjugated copolymer (P2) of PDI and DTT without acetylene spacers, polymer P1 exhibits 0.1 eV down shift of LUMO level and 89 nm red shift of low-energy absorption band. Polymer P1 in top-contact bottom-gate organic field-effect transistors (OFETs) exhibits a saturation electron mobility of 0.06 cm2 V–1 s–1 in air, while P2 does not function in the same device in air. Additionally, a saturation electron mobility of 0.075 cm2 V–1 s–1 in air, and after six days storage in air, an electron mobility of 0.034 cm2 V–1 s–1 were observed for P1 in bottom-contact bottom-gate OFETs; while a saturation electron mobility of 0.038 cm2 V–1 s–1 in air, and after six days storage in air, an electron mobility of 0.013 cm2 V–1 s–1 were observed for P2 in the same device. The better air stability and higher electron mobility of P1 are attributed to densely ordered packing of the polymer chains excluding oxygen or water and the lower LUMO level of P1.
Co-reporter:Lei Zhang;Hongtao Liu;Yan Zhao;Xiangnan Sun;Yugeng Wen;Yunlong Guo;Xike Gao;Chong-an Di;Gui Yu
Advanced Materials 2012 Volume 24( Issue 3) pp:436-440
Publication Date(Web):
DOI:10.1002/adma.201103620
Co-reporter:Yugeng Wen;Jianyi Chen;Lei Zhang;Xiangnan Sun;Yan Zhao;Yunlong Guo;Gui Yu
Advanced Materials 2012 Volume 24( Issue 11) pp:1471-1475
Publication Date(Web):
DOI:10.1002/adma.201104055
Co-reporter:Yugeng Wen;Jianyi Chen;Yunlong Guo;Bin Wu;Gui Yu
Advanced Materials 2012 Volume 24( Issue 26) pp:
Publication Date(Web):
DOI:10.1002/adma.201290156
Co-reporter:Yugeng Wen;Jianyi Chen;Yunlong Guo;Bin Wu;Gui Yu
Advanced Materials 2012 Volume 24( Issue 26) pp:3482-3485
Publication Date(Web):
DOI:10.1002/adma.201200579
Co-reporter:Yali Qiao ; Yunlong Guo ; Chunmeng Yu ; Fengjiao Zhang ; Wei Xu ; Yunqi Liu ;Daoben Zhu
Journal of the American Chemical Society 2012 Volume 134(Issue 9) pp:4084-4087
Publication Date(Web):February 21, 2012
DOI:10.1021/ja3003183
We report the synthesis, characterization, and application of a novel series of diketopyrrolopyrrole (DPP)-containing quinoidal small molecules as highly efficient n-type organic semiconductors in thin film transistors (TFTs). The first two representatives of these species exhibit maximum electron mobility up to 0.55 cm2 V–1 s–1 with current on/current off (Ion/Ioff) values of 106 for 1 by vapor evaporation, and 0.35 cm2 V–1 s–1 with Ion/Ioff values of 105–106 for 2 by solution process in air, which is the first demonstration of DPP-based small molecules offering only electron transport characteristics in TFT devices. The results indicate that incorporation of a DPP moiety to construct quinoidal architecture is an effective approach to enhance the charge-transport capability.
Co-reporter:Yunzhou Xue ; Bin Wu ; Lang Jiang ; Yunlong Guo ; Liping Huang ; Jianyi Chen ; Jiahui Tan ; Dechao Geng ; Birong Luo ; Wenping Hu ; Gui Yu
Journal of the American Chemical Society 2012 Volume 134(Issue 27) pp:11060-11063
Publication Date(Web):June 22, 2012
DOI:10.1021/ja302483t
The ability to dope graphene is highly important for modulating electrical properties of graphene. However, the current route for the synthesis of N-doped graphene by chemical vapor deposition (CVD) method mainly involves high growth temperature using ammonia gas or solid reagent melamine as nitrogen sources, leading to graphene with low doping level, polycrystalline nature, high defect density and low carrier mobility. Here, we demonstrate a self-assembly approach that allows the synthesis of single-layer, single crystal and highly nitrogen-doped graphene domain arrays by self-organization of pyridine molecules on Cu surface at temperature as low as 300 °C. These N-doped graphene domains have a dominated geometric structure of tetragonal-shape, reflecting the single crystal nature confirmed by electron-diffraction measurements. The electrical measurements of these graphene domains showed their high carrier mobility, high doping level, and reliable N-doped behavior in both air and vacuum.
Co-reporter:Xinjun Xu;Bo Liu;Yingping Zou;Yunlong Guo;Lidong Li
Advanced Functional Materials 2012 Volume 22( Issue 19) pp:4139-4148
Publication Date(Web):
DOI:10.1002/adfm.201200316

Abstract

The interface between the organic semiconductor and dielectric plays an important role in determining the device performance of organic field-effect transistors (OFETs). Although self-assembled monolayers (SAMs) made from organosilanes have been widely used for dielectric modification to improve the device performance of OFETs, they suffer from incontinuous and lack uniform coverage of the dielectric layer. Here, it is reported that by introduction of a solution-processed organozinc compound as a dielectric modification layer between the dielectric and the silane SAM, improved surface morphology and reduced surface polarity can be achieved. The organozinc compound originates from the reaction between diethylzinc and the cyclohexanone solvent, which leads to formation of zinc carboxylates. Being annealed at different temperatures, organozinc compound exists in various forms in the solid films. With organozinc modification, p-type polymer FETs show a high charge carrier mobility that is about two-fold larger than a control device that does not contain the organozinc compound, both for devices with a positive threshold voltage and for those with a negative one. After organozinc compound modification, the threshold voltage of polymer FETs can either be altered to approach zero or remain unchanged depending on positive or negative threshold voltage they have.

Co-reporter:Zhengran Yi, Xiangnan Sun, Yan Zhao, Yunlong Guo, Xingguo Chen, Jingui Qin, Gui Yu, and Yunqi Liu
Chemistry of Materials 2012 Volume 24(Issue 22) pp:4350
Publication Date(Web):October 31, 2012
DOI:10.1021/cm302341m
A new diketopyrrolopyrrole-based π-conjugated copolymer (PDPP5T) with high molecular weight has been synthesized by Stille coupling polymerization of 3,6-bis(5-bromothiophen-2-yl)-2,5-bis(2-octyldodecyl)pyrrolo-[3,4-c]pyrrole-1,4(2H,5H)-dione with α,α′-bis(trimethylstannyl)-terthiophene. Its hole mobility without thermal annealing reaches 1.08 cm2 V–1 s–1, and a higher hole mobility of 3.46 cm2 V–1 s–1 is obtained annealed at 200 °C directly in an air atmosphere. This indicates that introducing a longer β-unsubstituted quinquethiophene (5T) unit into the main-chain of DPP-oligothiophene copolymer produces much pronounced p-type behavior and also reduces the steric hindrance of the bulk side-chain groups, which is favorable to enhance the molecular ordering capability at low temperatures and improve the organic thin-film transistors (OTFT) performances. This work demonstrates that PDPP5T is a promising material that can be applied to the cost-effective and large-scale production of OTFTs.Keywords: donor−acceptor copolymer; hole mobility; organic thin-film transistors;
Co-reporter:Dugang Chen, Yan Zhao, Cheng Zhong, Siqi Gao, Gui Yu, Yunqi Liu and Jingui Qin
Journal of Materials Chemistry A 2012 vol. 22(Issue 29) pp:14639-14644
Publication Date(Web):10 May 2012
DOI:10.1039/C2JM31755A
Two donor–acceptor (D–A) alternating copolymers (P1 and P2) with phthalimide or thieno[3,4-c]pyrrole-4,6-dione as the electron acceptor and bithiophene as the electron donor have been synthesized by Stille polycondensation. Both polymers showed good thermal stability and a low HOMO level. Organic field-effect transistor (OFET) devices with common architectures were fabricated to evaluate and compare the FET properties of the two polymers. Though P2 exhibits better coplanarity than P1, the FET results revealed that both the hole mobility and current on–off ratio of P1 are more than one order of magnitude higher than P2. Theoretical calculations and AFM were conducted to analyze the reason for this very interesting result, and it was found that polymer chain conformation is another important factor (in addition to coplanarity) for polymers to obtain high FET performance.
Co-reporter:Wenbo Wu, Shanghui Ye, Lijin Huang, Li Xiao, Yingjie Fu, Qi Huang, Gui Yu, Yunqi Liu, Jingui Qin, Qianqian Li and Zhen Li
Journal of Materials Chemistry A 2012 vol. 22(Issue 13) pp:6374-6382
Publication Date(Web):22 Feb 2012
DOI:10.1039/C2JM16514G
In this paper, tetraphenylethylene (TPE) units, a well-known aggregation-induced emission (AIE) active group, are utilized to construct the hyperbranched polymer HP-TPE-Cz with carbazole moieties, a good hole-transporting and electroluminescent group, through an “A2 + B4” approach by using a one-pot Suzuki polycondensation reaction. For comparison, its analog linear polymer LP-TPE-Cz, also constructed from these two moieties, was prepared. These two polymers exhibit interesting aggregation-induced emission enhanced (AIEE) behavior and act as explosive chemosensors with high sensitivity both as nanoparticles and in solid state, due to the presence of TPE units. Also, the HP-TPE-Cz PLED device exhibited a remarkably enhanced current efficiency (2.13 cd A−1) and luminescence efficiency (5914 cd m−2), compared with its analog linear polymer LP-TPE-Cz (1.04 cd A−1, 1654 cd m−2).
Co-reporter:Huajie Chen, Chang He, Gui Yu, Yan Zhao, Jianyao Huang, Minliang Zhu, Hongtao Liu, Yunlong Guo, Yongfang Li and Yunqi Liu
Journal of Materials Chemistry A 2012 vol. 22(Issue 9) pp:3696-3698
Publication Date(Web):10 Jan 2012
DOI:10.1039/C2JM16104D
A highly π-extended copolymer, PPTT, was developed based on 6H-phenanthro[1,10,9,8-cdefg]carbazole (PCZ) and thiazolo[5,4-d]thiazole derivative units, being the first PCZ-containing polymer, as well as its first applications in OTFTs and OPVs. This polymer exhibited an excellent solubility in several common organic solvents, a good film-forming ability, a reasonably high thermal stability, and a deep-lying HOMO energy level, meeting well the requirements of OTFTs and OPVs. The investigation of the field-effect and photovoltaic performances demonstrated that PPTT had a high hole mobility of 0.13 cm2 V−1 s−1 and good power conversion efficiency (PCE) of 3.20%, which were among the highest mobilities and PCEs for a single polymer material with dual transistor and OPV functions simultaneously.
Co-reporter:Li Qu, Yunlong Guo, Hao Luo, Cheng Zhong, Gui Yu, Yunqi Liu and Jingui Qin
Chemical Communications 2012 vol. 48(Issue 80) pp:9965-9967
Publication Date(Web):11 Jul 2012
DOI:10.1039/C2CC33445C
A simple nickel bis(dithiolene) complex has been developed as an excellent n-type molecular semiconductor for FETs, with an electron mobility of 0.11 cm2 V−1 s−1 and an on/off ratio of 2 × 106 despite its small π-conjugated system. Good FET stability in ambient conditions has also been observed.
Co-reporter:Li Qiu, Chunmeng Yu, Na Zhao, Weichao Chen, Yunlong Guo, Xiaobo Wan, Renqiang Yang and Yunqi Liu
Chemical Communications 2012 vol. 48(Issue 100) pp:12225-12227
Publication Date(Web):05 Nov 2012
DOI:10.1039/C2CC36689D
Two linear fused heteroacenes bearing a pyrrolo[3,2-b]pyrrole core have been synthesized via a novel reductive ring closure methodology in three steps and in good overall yield. Preliminary OFET results showed that dinaphtho[2,3-b:2′,3′-f]pyrrolo[3,2-b]pyrrole (DNPP) is a potential candidate for organic electronics.
Co-reporter:Weifeng Zhang, Xiangnan Sun, Pingfang Xia, Jianyao Huang, Gui Yu, Man Shing Wong, Yunqi Liu, and Daoben Zhu
Organic Letters 2012 Volume 14(Issue 17) pp:4382-4385
Publication Date(Web):August 21, 2012
DOI:10.1021/ol301852m
Two tetrabrominated intermediates obtained by bromination of naphthodithiophene in different solvents were used to construct novel highly π-extended butterfly-shaped heteroarenes 1–6, containing either an 8- or 10-fused ring. The solution-processed organic field-effect transistors based on compound 1 exhibited promising device performance with a hole mobility of 0.072 cm2 V–1 s–1 and a current on/off ratio of 106 under ambient atmosphere.
Co-reporter:Wenbo Wu;Shanghui Ye;Gui Yu;Jingui Qin;Zhen Li
Macromolecular Rapid Communications 2012 Volume 33( Issue 2) pp:164-171
Publication Date(Web):
DOI:10.1002/marc.201100503

Abstract

With the aim to develop new tetraphenylethylene (TPE)-based conjugated hyperbranched polymer, TPE units, one famous aggregation-induced emission (AIE) active group, are utilized to construct hyperbranched polymers with three other aromatic blocks, through an “A2+B4” approach by using one-pot Suzuki polycondensation reaction. These three hyperbranched polymers exhibit interesting AIEE behavior and act as explosive chemsensors with high sensitivity both in the nanoparticles and solid states. This is the first report of the AIE activity of the TPE-based conjugated hyperbranched polymers. Their corresponding PLED devices also demonstrate good performance.

Co-reporter:Yunlong Guo, Ji Zhang, Gui Yu, Jian Zheng, Lei Zhang, Yan Zhao, Yugeng Wen, Yunqi Liu
Organic Electronics 2012 Volume 13(Issue 10) pp:1969-1974
Publication Date(Web):October 2012
DOI:10.1016/j.orgel.2012.05.007
The authors report on low operation voltage memory cells based on heterojunction ambipolar organic transistors with polymer gate electret (PGE). The introduction of the N,N′-dioctyl perylene diimide/pentacene heterojunction into the memory OFETs with PGE successfully lowered the memory cells’ reading, writing and erasing programmed voltages (reading voltage of 2 V, writing and erasing programmed voltages of 10 V). Meanwhile, the memory devices showed reproducible and durable memory behavior in more than 500 cycles’ testing. The built-in electric field-effect at heterojunction surface should efficiently reduce operation voltage of the memory devices.Graphical abstractHighlights► The ambipolar OFET memory devices with polymer gate electrets were investigated. ► This method effectively reduced the operating voltage of the memory cells. ► The mechanism of this phenomenon was systematically studied. ► The memory devices demonstrated reproducible memory behavior.
Co-reporter:Kangli Cao;Xiangnan Sun;Qing Zhang
Macromolecular Chemistry and Physics 2012 Volume 213( Issue 9) pp:917-923
Publication Date(Web):
DOI:10.1002/macp.201100660

Abstract

2,4,6-Tri(2-thienyl)pyridine is used to synthesize the new conjugated polymer PBDTTPy for OFET applications. The concept of introducing electron-deficient pyridine repeating units and meta-linked structures into a conjugated polymer to reduce its HOMO energy level and thereby increase its ambient stability is tested. The absorption spectrum of the polymer thin film displays a large bathochromic shift compared with its solution absorption spectrum. The polymer PBDTTPy shows a typical amorphous structure in the solid state. The first OFET device based on a conjugated polymer with meta-linked trithienylpyridine units is reported. PBDTTPy exhibits p-type transport under ambient conditions in a bottom-gate, top-contact OFET device with a mobility of 2.4 × 10−4 cm2 V−1 s−1.

Co-reporter:Wenbo Wu, Shanghui Ye, Runli Tang, Lijin Huang, Qianqian Li, Gui Yu, Yunqi Liu, Jingui Qin, Zhen Li
Polymer 2012 Volume 53(Issue 15) pp:3163-3171
Publication Date(Web):6 July 2012
DOI:10.1016/j.polymer.2012.05.035
In this paper, tetraphenylethylene (TPE) units, one of the typical aggregation-induced emission (AIE) moieties, are utilized to construct a new functional polyfluorene (PF) P1, which exhibited the exciting property of the aggregation-induced emission enhancement (AIEE), instead of the aggregation-caused quenching (ACQ) of normal PFs, and could probe the explosive with high sensitivity both in the nanoparticles and solid state. Three other TPE-containing polymers, P2–P4, were also successfully prepared, and demonstrated good performance as explosive chemosensors and light-emitting materials. P3, bearing carbazole as hole-transporting units showed the best performance with a maximum luminance efficiency of 1.17 cd/A and a maximum brightness of 3609 cd/m2 at 12.9 V in its light-emitting diode device.Graphical abstract
Co-reporter:Xiaochen Wang, Yugeng Wen, Hao Luo, Gui Yu, Xiaoyu Li, Yunqi Liu, Haiqiao Wang
Polymer 2012 Volume 53(Issue 9) pp:1864-1869
Publication Date(Web):17 April 2012
DOI:10.1016/j.polymer.2012.03.015
A novel alternating D–A copolymer, PPor–BT, with dioctylporphyrin (Por) as a donor unit and 5,6-bis(octyloxy)benzo-2,1,3-thiadiazole (BT) as an acceptor unit, was designed and synthesized by Pd-catalyzed Sonogashira-coupling reaction. The copolymer showed good solubility and film-forming ability. PPor–BT exhibited a broad absorption band from 350 to 950 nm with two peaks centered at 456 and 818 nm corresponding to the Soret band and Q-bands absorption of porphyrin segments, respectively. The employment of electron deficient BT unit to construct donor-acceptor structure observably broadened the absorption spectrum and enhanced the Q-band absorption of the porphyrin-based polymer. The HOMO and LUMO energy levels of the polymer are −5.06 eV and −3.63 eV, respectively. The solution-processed organic field-effect transistors (OFETs) were fabricated with bottom gate/top-contact geometry. The mobility of PPor–BT based OFEFs reached 4.3 × 10−5 cm2 V−1 s−1 with an on/off current ratio of 104. This mobility is among the highest values for porphyrin-based polymers.
Co-reporter:Ti Wu, Chunmeng Yu, Yunlong Guo, Hongtao Liu, Gui Yu, Yu Fang, and Yunqi Liu
The Journal of Physical Chemistry C 2012 Volume 116(Issue 43) pp:22655-22662
Publication Date(Web):October 3, 2012
DOI:10.1021/jp304697r
Organic semiconductors (ITTI and IDTI) characterized of thieno[3,2-b]thiophene and dithiophene bridged isoindigo derivatives were designed and successfully synthesized. 1H–13C HMBC, 1H–1H nuclear Overhauser enhancement spectroscopy (NOESY) spectra, and 1H nuclear Overhauser enhancement (NOE) experiments were employed to determine the configurations of the synthesized molecules, indicating they belong to stable Z,Z configurations. Organic field-effect transistors based on ITTI and IDTI through a solution processed method have good air stabilities and exhibit hole mobilities of 0.045 and 0.075 cm2 V–1 s–1 after high-temperature annealing in air, respectively.
Co-reporter:Weiyi Zhou, Yugeng Wen, Lanchao Ma, Yunqi Liu, and Xiaowei Zhan
Macromolecules 2012 Volume 45(Issue 10) pp:4115-4121
Publication Date(Web):May 8, 2012
DOI:10.1021/ma3005058
A series of new n-type copolymers based on perylene diimide (PDI) or naphthalene diimide (NDI) and phenothiazine (PTZ) with different side chain length and molecular weight have been designed and synthesized by Pd-catalyzed Suzuki coupling polymerization with or without phase-transfer catalyst Aliquat 336. The effects of main chain, side chain, and molecular weight on the thermal, optical, electronic, and charge transport properties of the polymers have been investigated. Aliquat 336 improves molecular weight as well as reduces polydispersity index of the polymers. All the polymers exhibit a broad absorption extending from 300 to 900 nm. The main chain and side chain structure and molecular weight have minor effects on the HOMO (−5.8 to −5.9 eV) and LUMO (−3.7 to −3.8 eV) levels of the polymers. n-Channel field-effect transistors with bottom-gate top-contact geometry based on these copolymers exhibit electron mobilities as high as 0.05 cm2 V–1 s–1 and on/off ratios as high as 105 in nitrogen, which are among the best reported for rylene diimide-based polymers under the same test conditions.
Co-reporter:DuGang Chen;Yan Zhao;Cheng Zhong;Gui Yu
Science China Chemistry 2012 Volume 55( Issue 5) pp:760-765
Publication Date(Web):2012 May
DOI:10.1007/s11426-011-4460-2
This paper reports a new donor-acceptor copolymer semiconductor, PTBTh, comprising bithiophene and bithiazole where the regular coplanar structure and the intramolecular charge transfer are expected to increase the opportunity for π-π stacking and charge transport. The AFM image shows lamellar stacking of the polymer on the surface. The field-effect transistor (FET) properties of PTBTh have been evaluated by a bottom-contact/bottom-gate TFT configuration. The device showed a high hole mobility of 1.14×10−2 cm2 V−1 s−1 and a current on/off ratio of 3×105 with the polymer thin film annealed at a mild temperature of 120 °C when measured under ambient conditions.
Co-reporter:Bin Wu;Dechao Geng
PNAS 2012 Volume 109 (Issue 31 ) pp:E2100
Publication Date(Web):2012-07-31
DOI:10.1073/pnas.1208665109
Co-reporter:Dechao Geng;Yunzhou Xue;Gui Yu;Lang Jiang;Wenping Hu;Bin Wu;Yunlong Guo;Liping Huang;Jianyi Chen
PNAS 2012 Volume 109 (Issue 21 ) pp:7951-7952
Publication Date(Web):2012-05-22
DOI:10.1073/pnas.1200339109
Unresolved problems associated with the production of graphene materials include the need for greater control over layer number, crystallinity, size, edge structure and spatial orientation, and a better understanding of the underlying mechanisms. Here we report a chemical vapor deposition approach that allows the direct synthesis of uniform single-layered, large-size (up to 10,000 μm2), spatially self-aligned, and single-crystalline hexagonal graphene flakes (HGFs) and their continuous films on liquid Cu surfaces. Employing a liquid Cu surface completely eliminates the grain boundaries in solid polycrystalline Cu, resulting in a uniform nucleation distribution and low graphene nucleation density, but also enables self-assembly of HGFs into compact and ordered structures. These HGFs show an average two-dimensional resistivity of 609 ± 200 Ω and saturation current density of 0.96 ± 0.15 mA/μm, demonstrating their good conductivity and capability for carrying high current density.
Co-reporter:Yugeng Wen, Yunqi Liu, Yunlong Guo, Gui Yu, and Wenping Hu
Chemical Reviews 2011 Volume 111(Issue 5) pp:3358
Publication Date(Web):March 14, 2011
DOI:10.1021/cr1001904
Co-reporter:Hongliang Zhang, Bin Wu, Wenping Hu and Yunqi Liu
Chemical Society Reviews 2011 vol. 40(Issue 3) pp:1324-1336
Publication Date(Web):07 Dec 2010
DOI:10.1039/B920457C
Single-walled carbon nanotubes (SWNTs) possess unique electronic properties that make them very promising materials for use in both nano-electronics and thin film devices. However, SWNTs are always produced as a mixture of metallic and semiconducting nanotubes, which is a major roadblock to their widespread application. This tutorial review provides a brief summary of ways of separating single-walled carbon nanotubes into metallic and semiconducting fractions. Various methods including selective growth, selective removal, selective adsorption and band structure modulation—all of which aim to produce pure SWNTs with well-defined electronic properties—are systematically discussed. The main problems in this field, the outlook for separation techniques and some views of future developments are presented.
Co-reporter:Xiangnan Sun;Lei Zhang;Chong-an Di;Yugeng Wen;Yunlong Guo;Yan Zhao;Gui Yu
Advanced Materials 2011 Volume 23( Issue 28) pp:3128-3133
Publication Date(Web):
DOI:10.1002/adma.201101178
Co-reporter:Xiangnan Sun;Chong-an Di;Yugeng Wen;Yunlong Guo;Lei Zhang;Yan Zhao;Gui Yu
Advanced Materials 2011 Volume 23( Issue 8) pp:1009-1014
Publication Date(Web):
DOI:10.1002/adma.201004187
Co-reporter:Xiangnan Sun;Chong-an Di;Yugeng Wen;Yunlong Guo;Lei Zhang;Yan Zhao;Gui Yu
Advanced Materials 2011 Volume 23( Issue 8) pp:
Publication Date(Web):
DOI:10.1002/adma.201190017
Co-reporter:Jian Zheng;Hongtao Liu;Bin Wu;Yunlong Guo;Ti Wu;Gui Yu;Daoben Zhu
Advanced Materials 2011 Volume 23( Issue 21) pp:2460-2463
Publication Date(Web):
DOI:10.1002/adma.201004759
Co-reporter:Bin Wu;Dechao Geng;Yunlong Guo;Liping Huang;Yunzhou Xue;Jian Zheng;Jianyi Chen;Gui Yu;Lang Jiang ;Wenping Hu
Advanced Materials 2011 Volume 23( Issue 31) pp:3522-3525
Publication Date(Web):
DOI:10.1002/adma.201101746
Co-reporter:Jianyi Chen ; Yugeng Wen ; Yunlong Guo ; Bin Wu ; Liping Huang ; Yunzhou Xue ; Dechao Geng ; Dong Wang ; Gui Yu
Journal of the American Chemical Society 2011 Volume 133(Issue 44) pp:17548-17551
Publication Date(Web):October 11, 2011
DOI:10.1021/ja2063633
We report the metal-catalyst-free synthesis of high-quality polycrystalline graphene on dielectric substrates [silicon dioxide (SiO2) or quartz] using an oxygen-aided chemical vapor deposition (CVD) process. The growth was carried out using a CVD system at atmospheric pressure. After high-temperature activation of the growth substrates in air, high-quality polycrystalline graphene is subsequently grown on SiO2 by utilizing the oxygen-based nucleation sites. The growth mechanism is analogous to that of growth for single-walled carbon nanotubes. Graphene-modified SiO2 substrates can be directly used in transparent conducting films and field-effect devices. The carrier mobilities are about 531 cm2 V–1 s–1 in air and 472 cm2 V–1 s–1 in N2, which are close to that of metal-catalyzed polycrystalline graphene. The method avoids the need for either a metal catalyst or a complicated and skilled postgrowth transfer process and is compatible with current silicon processing techniques.
Co-reporter:Zhong'an Li, Zuoquan Jiang, Shanghui Ye, Cathy K. W. Jim, Gui Yu, Yunqi Liu, Jingui Qin, Ben Zhong Tang and Zhen Li
Journal of Materials Chemistry A 2011 vol. 21(Issue 38) pp:14663-14671
Publication Date(Web):15 Aug 2011
DOI:10.1039/C1JM11176K
In this paper, four new π-conjugated dendrimers G1 and G2-1–G2-3, constructed by triphenylamine and carbazole moieties, have been successfully prepared via a simple synthetic route. This molecular design imparts the materials with good solution-processability, high thermal and morphological stabilities, and low oxidation potential, all of which are promising properties for optoelectronic materials. The double-layer OLEDs fabricated using these materials through solution processing demonstrate that they can exhibit dual functions, hole-transporting and light-emitting. Devices using G1 or G2-1 as the hole-transporting layer present good stability during the passage of current, with a maximum efficiency of 1.70 and 1.59 cd A−1, respectively. Moreover, devices using these dendrimers as the emitting layer show moderate performance, and the device of G2-2 gives a maximum luminance and efficiency of 1190 cd m−2 and 1.67 cd A−1, respectively, thanks to three-dimensional building of the dendritic system, which might suppress the inherent reductive or aggregation-caused quenching that usually happens for triphenylamine/carbazole derivatives to some degree. Also, the photo-cross-linking property of triple bonds enables ready fabrication of highly fluorescent photoresist patterns of these dendrimers.
Co-reporter:Hongtao Liu, Yunqi Liu and Daoben Zhu
Journal of Materials Chemistry A 2011 vol. 21(Issue 10) pp:3335-3345
Publication Date(Web):24 Nov 2010
DOI:10.1039/C0JM02922J
Recently, a lot of effort has been focused on improving the performance and exploring the electric properties of graphene. This article presents a summary of chemical doping of graphene aimed at tuning the electronic properties of graphene. p-Type and n-type doping of graphene achieved through surface transfer doping or substitutional doping and their applications based on doping are reviewed. Chemical doping for band gap tuning in graphene is also presented. It will be beneficial to designing high performance electronic devices based on chemically doped graphene.
Co-reporter:Liping Huang, Bin Wu, Gui Yu and Yunqi Liu
Journal of Materials Chemistry A 2011 vol. 21(Issue 4) pp:919-929
Publication Date(Web):20 Oct 2010
DOI:10.1039/C0JM02225J
As a new member of the carbon family, graphene has many fascinating properties and potential applications with the greatest degree of similarity to its “brother” carbon nanotubes (CNTs). Research on graphene has developed rapidly in the past 6 years, partially due to its similarity to carbon nanotubes which have been extensively studied for almost two decades. The adaptation of carbon nanotube research strategies for the development of graphene preparation, functionalization and applications as well as the conversion and hybrid structures of carbon nanotubes and graphene are reviewed in this feature article.
Co-reporter:Bin Wu, Dechao Geng and Yunqi Liu
Nanoscale 2011 vol. 3(Issue 5) pp:2074-2085
Publication Date(Web):08 Mar 2011
DOI:10.1039/C0NR00958J
The nature of the mixed electronic type metallic (M-) and semiconducting (S-) single-walled carbon nanotubes (SWNTs) synthesized by current methods has posed a key challenge for the development of high performance SWNT-based electronic devices. The precise measurements of M- to S-SWNT ratio in as-grown or separated samples are of paramount importance for the controlled synthesis, separation and the realization of various applications. The objective of this review is to provide comprehensive overview of the progress achieved so far for measuring the M/S ratio both on individual and collective levels of SWNT states. We begin with a brief introduction of SWNT structures/properties and discussion of the problems and difficulties associated with precise measurement of the M/S ratio, and then introduce the principles for obtaining distinguished signals from M-and S-SWNTs. These techniques are classified into different groups based either on the single/ensemble detection of SWNT samples or on the principles of techniques themselves. We then present the M/S ratio evaluation results of these methods, with emphasis on scanning probe microscopy (SPM)-based detection techniques. Finally, the prospects of precise and large-scale measurement of M/S ratio in achieving controlled synthesis and understanding growth mechanism of SWNTs are discussed.
Co-reporter:Liping Huang, Bin Wu, Jianyi Chen, Yunzhou Xue, Yunqi Liu, Hisashi Kajiura, Yongming Li
Carbon 2011 Volume 49(Issue 14) pp:4792-4800
Publication Date(Web):November 2011
DOI:10.1016/j.carbon.2011.06.091
Single-walled carbon nanotubes (SWCNTs) with high purity and very narrow diameter distribution have been synthesized using the dc arc-discharge method with Y–Ni alloy as catalyst and selenium (Se) as promoter. The SWCNTs show a very narrow diameter distribution mainly at about 1.5 nm, and can further be readily purified up to >99% purity with traditional purification including HNO3 reflux and air oxidation. The key factor of the wetting effect of Se in the SWCNTs growth improvement process is proposed and discussed. Moreover, a new less-destructive purification method including electrolysis, air-oxidation and centrifugation has been introduced, and SWCNTs with semiconducting content up to 94% have been produced through density gradient ultracentrifugation method.
Co-reporter:Zujin Zhao, Shanghui Ye, Yanju Guo, Zhengfeng Chang, Liya Lin, Tao Jiang, Jacky W.Y. Lam, Ping Lu, Huayu Qiu, Yunqi Liu, Ben Zhong Tang
Organic Electronics 2011 Volume 12(Issue 12) pp:2236-2242
Publication Date(Web):December 2011
DOI:10.1016/j.orgel.2011.09.019
Simple molecule possesses high power: 1,3,6,8-Tetrakis[(triisopropylsilyl)ethynyl]pyrene (TTIPSEPy), a simple-structured molecule, shows strong solid-state photoluminescence with unity emission efficiency. Highly efficient non-doped organic light-emitting diodes are fabricated using TTIPSEPy as emitter, exhibiting stable yellow light (CIE = 0.41, 0.56) with high luminance and efficiency up to 26,400 cd/m2 and 9.2 cd/A, respectively.Graphical abstractA new pyrene derivative exhibits unity solid-state fluorescence efficiency and yellow electroluminescence with an efficiency of 9.2 cd/A in non-doped OLED.Highlights► A new pyrene derivative is facilely synthesised and fully characterized. ► It shows intense photoluminescence with unity emission efficiency in solid-state. ► Highly efficient non-doped organic light-emitting diodes are fabricated based on it.
Co-reporter:Yao Liu;Xiaowei Zhan
Macromolecular Chemistry and Physics 2011 Volume 212( Issue 5) pp:428-443
Publication Date(Web):
DOI:10.1002/macp.201000677
Co-reporter:Yao Liu;Xiaowei Zhan
Macromolecular Chemistry and Physics 2011 Volume 212( Issue 5) pp:
Publication Date(Web):
DOI:10.1002/macp.201190007
Co-reporter:Huajie Chen ; Qingyu Cui ; Gui Yu ; Yunlong Guo ; Jianyao Huang ; Minliang Zhu ; Xiaojun Guo
The Journal of Physical Chemistry C 2011 Volume 115(Issue 48) pp:23984-23991
Publication Date(Web):October 31, 2011
DOI:10.1021/jp2081484
The synthesis and characterization of four new organic semiconductors with thieno[3,2-b][1]benzothiophene cores and different π-bridge spacers are reported. Cyclic voltammetry measurement indicates that the materials have low energy levels of the highest occupied molecular orbitals and large band gaps. The single-crystal X-ray diffraction experiment reveals that 1,2-di(thieno[3,2-b][1]benzothiophenic-2-)ethylene (DTBTE) molecules have a nearly coplanar structure and crystallize into a herringbone arrangement with strongly intermolecular multiple S···S, S···C, and CH···π interactions. These interactions facilitate charge carrier transport. The DTBTE-based organic thin-film transistors (OTFTs) on an octyltrichlorosilane-modified SiO2/Si substrate exhibit good field-effect performance with the highest mobility of 0.50 cm2 V–1 s–1. Furthermore, the DTBTE-based OTFTs have been fabricated on a flexible polyethylene terephthalate substrate and showed a maximum mobility of up to 0.45 cm2 V–1 s–1, indicating its potential application as an organic semiconductor in the flexible OTFTs.
Co-reporter:Yunzhou Xue;Bin Wu;Yunlong Guo;Liping Huang;Lang Jiang;Jianyi Chen
Nano Research 2011 Volume 4( Issue 12) pp:1208-1214
Publication Date(Web):2011 December
DOI:10.1007/s12274-011-0171-4
We demonstrate a simple and controllable way to synthesize large-area, few-layer graphene on iron substrates by an optimized chemical vapor deposition (CVD) method using a mixture of methane and hydrogen. Based on an analysis of the Fe-C phase diagram, a suitable procedure for the successful synthesis of graphene on Fe surfaces was designed. An appropriate temperature and cooling process were found to be very important in the synthesis of highly crystalline few-layer graphene. Graphene-based field-effect transistor (FET) devices were fabricated using the resulting few-layer graphene, and showed good quality with extracted mobilities of 300–1150 cm2/(V·s). Open image in new window
Co-reporter:Jian Zheng;Hongtao Liu;Bin Wu;Yunlong Guo;Ti Wu;Gui Yu
Nano Research 2011 Volume 4( Issue 7) pp:
Publication Date(Web):2011 July
DOI:10.1007/s12274-011-0126-9
We report a simple method to produce graphene nanospheres (GNSs) by annealing graphene oxide (GO) solution at high-temperature with the assistance of sparks induced by the microwave absorption of graphite flakes dispersed in the solution. The GNSs were formed by rolling up of the annealed GO, and the diameters were mostly in the range 300–700 nm. The GNS exhibited a hollow sphere structure surrounded by graphene walls with a basal spacing of 0.34 nm. Raman spectroscopy and X-ray photoelectron spectroscopy of the GNSs confirmed that the GO was efficiently reduced during the fabrication process. The resulting GNSs may open up new opportunities both for fundamental research and applications, and this method may be extended to the synthesis of other nanomaterials and the fabrication of related nanostructures. Open image in new window
Co-reporter:Bin Wu;Dechao Geng;Yunlong Guo;Liping Huang;Jianyi Chen;Yunzhou Xue
Nano Research 2011 Volume 4( Issue 10) pp:
Publication Date(Web):2011 October
DOI:10.1007/s12274-011-0149-2
Co-reporter:Weiping Wu, Yunqi Liu and Daoben Zhu
Chemical Society Reviews 2010 vol. 39(Issue 5) pp:1489-1502
Publication Date(Web):08 Dec 2009
DOI:10.1039/B813123F
π-Conjugated molecular materials with fused rings are the focus of considerable interest in the emerging area of organic electronics, since the combination of excellent charge carrier mobility and high stability may lead to their practical applications. This tutorial review discusses the synthesis, properties and applications of π-conjugated organic semiconducting materials, especially those with fused rings. The achievements to date, the remaining problems and challenges, and the key research that needs to be done in the near future are all discussed.
Co-reporter:Yugeng Wen
Advanced Materials 2010 Volume 22( Issue 12) pp:1331-1345
Publication Date(Web):
DOI:10.1002/adma.200901454

Abstract

Particular attention has been focused on n-channel organic thin-film transistors (OTFTs) during the last few years, and the potentially cost-effective circuitry-based applications in flexible electronics, such as flexible radiofrequency identity tags, smart labels, and simple displays, will benefit from this fast development. This article reviews recent progress in performance and molecular design of n-channel semiconductors in the past five years, and limitations and practicable solutions for n-channel OTFTs are dealt with from the viewpoint of OTFT constitution and geometry, molecular design, and thin-film growth conditions. Strategy methodology is especially highlighted with an aim to investigate basic issues in this field.

Co-reporter:Chong-an Di;Kun Lu;Lei Zhang;Yunlong Guo;Xiangnan Sun;Yugeng Wen;Gui Yu ;Daoben Zhu
Advanced Materials 2010 Volume 22( Issue 11) pp:1273-1277
Publication Date(Web):
DOI:10.1002/adma.200902813
Co-reporter:Dacheng Wei
Advanced Materials 2010 Volume 22( Issue 30) pp:3225-3241
Publication Date(Web):
DOI:10.1002/adma.200904144

Abstract

Graphene, a two-dimensional material, is regarded as one of the most promising candidates for future nanoelectronics due to its atomic thickness, excellent properties and widespread applications. As the first step to investigate its properties and finally to realize the practical applications, graphene must be synthesized in a controllable manner. Thus, controllable synthesis is of great significance, and received more and more attention recently. This Progress Report highlights recent advances in controllable synthesis of graphene, clarifies the problems, and prospects the future development in this field. The applications of the controllable synthesis are also discussed.

Co-reporter:Dacheng Wei
Advanced Materials 2010 Volume 22( Issue 30) pp:
Publication Date(Web):
DOI:10.1002/adma.201090099
Co-reporter:Shanghui Ye;Jianming Chen;Kun Lu;Weiping Wu;Chunyan Du;Ying Liu;Ti Wu;Zhigang Shuai;Gui Yu
Advanced Materials 2010 Volume 22( Issue 37) pp:4167-4171
Publication Date(Web):
DOI:10.1002/adma.201001392
Co-reporter:Yunlong Guo;Chunyan Du;Gui Yu;Chong-an Di;Shidong Jiang;Hongxia Xi;Jian Zheng;Shouke Yan;Cailan Yu;Wenping Hu
Advanced Functional Materials 2010 Volume 20( Issue 6) pp:1019-1024
Publication Date(Web):
DOI:10.1002/adfm.200901662

Abstract

Oligoarenes as an alternative group of promising semiconductors in organic optoelectronics have attracted much attention. However, high-performance and low-cost opto-electrical devices based on linear asymmetric oligoarenes with nano/microstructures are still rarely studied because of difficulties both in synthesis and high-quality nano/microstructure growth. Here, a novel linear asymmetric oligoarene 6-methyl-anthra[2,3-b]benzo[d]thiophene (Me-ABT) is synthesized and its high-quality microribbons are grown by a solution process. The solution of Me-ABT exhibits a moderate fluorescence quantum yield of 0.34, while the microribbons show a glaucous light emission. Phototransistors based on an individual Me-ABT microribbon prepared by a solution-phase self-assembly process showed a high mobility of 1.66 cm2 V−1 s−1, a large photoresponsivity of 12 000 A W−1, and a photocurrent/dark-current ratio of 6000 even under low light power conditions (30 µW cm−2). The measured photoresponsivity of the devices is much higher than that of inorganic single-crystal silicon thin film transistors. These studies should boost the development of the organic semiconductors with high-quality microstructures for potential application in organic optoelectronics.

Co-reporter:Shanghui Ye;Kun Lu;Weiping Wu;Chunyan Du;Ying Liu;Hongtao Liu;Ti Wu;Gui Yu
Advanced Functional Materials 2010 Volume 20( Issue 18) pp:3125-3135
Publication Date(Web):
DOI:10.1002/adfm.201000474

Abstract

A new series of full hydrocarbons, namely 4,4′-(9,9′-(1,3-phenylene)bis(9H-fluorene-9,9-diyl))bis(N,N-diphenylaniline) (DTPAFB), N,N′-(4,4′-(9,9′-(1,3-phenylene)bis(9H-fluorene-9,9-diyl))bis(4,1-phenylene))bis(N-phenylnaphthalen-1-amine) (DNPAFB), 1,3-bis(9-(4-(9H-carbazol-9-yl)phenyl)-9H-fluoren-9-yl)benzene, and 1,3-bis(9-(4-(3,6-di-tert-butyl-9H-carbazol-9-yl)phenyl)-9H-fluoren-9-yl)benzene, featuring a highly twisted tetrahedral conformation, are designed and synthesized. Organic light-emitting diodes (OLEDs) comprising DNPAFB and DTPAFB as hole transporting layers and tris(quinolin-8-yloxy)aluminum as an emitter are made either by vacuum deposition or by solution processing, and show much higher maximum efficiencies than the commonly used N,N′-di(naphthalen-1-yl)-N,N′-diphenylbiphenyl-4,4′-diamine device (3.6 cd A−1) of 7.0 cd A−1 and 6.9 cd A−1, respectively. In addition, the solution processed blue phosphorescent OLEDs employing the synthesized materials as hosts and iridium (III) bis[(4,6-di-fluorophenyl)-pyridinato-N, C2] picolinate (FIrpic) phosphor as an emitter present exciting results. For example, the DTPAFB device exhibits a brightness of 47 902 cd m−2, a maximum luminescent efficiency of 24.3 cd A−1, and a power efficiency of 13.0 lm W−1. These results show that the devices are among the best solution processable blue phosphorescent OLEDs based on small molecules. Moreover, a new approach to constructing solution processable small molecules is proposed based on rigid and bulky fluorene and carbazole moieties combined in a highly twisted configuration, resulting in excellent solubility as well as chemical miscibility, without the need to introduce any solubilizing group such as an alkyl or alkoxy chain.

Co-reporter:Dacheng Wei, Yunqi Liu, Lingchao Cao, Hongliang Zhang, Liping Huang and Gui Yu
Chemistry of Materials 2010 Volume 22(Issue 2) pp:288
Publication Date(Web):December 30, 2009
DOI:10.1021/cm900929h
One-dimensional (1D) nanostructures of the wide band gap semiconductors are promising building blocks for photoelectric nanodevices. However, some problems like strong 1D confinement largely hamper their applications. To avoid these problems, here, we provide another 1D configuration, in which an inner-wire coaxial Schottky junction exists, thus effectively avoiding the recombination of the photoexcited carriers. As an example, we produce ZnS/carbon nanotube nanocables with uniform morphologies by a two-step vapor deposition method and find that they have good conductance, obvious light response, and ohmic contacts with electrodes, avoiding the limitations of both the pristine nanomaterials. We believe that this configuration would be valuable for applying the 1D nanomaterials in photoelectronics.
Co-reporter:Lei Zhang, Chong-an Di, Gui Yu and Yunqi Liu
Journal of Materials Chemistry A 2010 vol. 20(Issue 34) pp:7059-7073
Publication Date(Web):03 Jun 2010
DOI:10.1039/C0JM00331J
Manufacturing organic circuits from solution provides an opportunity to realize low-cost fabrication of large-area flexible electronics, such as radio frequency identity tags, sensor arrays and flexible displays. Inspired by the potential applications, significant efforts have been devoted to develop organic field-effect transistors with solution processed components in the past decade. Herein, we summarize recent progresses in solution processable functional materials including organic semiconductors, electrode materials, and dielectric materials. Various solution manufacturing techniques, patterning techniques and related device engineering methods are also reviewed. Finally, all-solution processed logic circuits are discussed from the point of view of practical application. All these achievements represent a big step forward and promise the solution processed OFETs a bright future.
Co-reporter:Shanghui Ye, Jianming Chen, Chong-an Di, Yunqi Liu, Kun Lu, Weiping Wu, Chunyan Du, Ying Liu, Zhigang Shuai and Gui Yu
Journal of Materials Chemistry A 2010 vol. 20(Issue 16) pp:3186-3194
Publication Date(Web):01 Mar 2010
DOI:10.1039/B925418H
A new series of highly fluorescent blue-emitting materials based on fluorene and anthracene hybrids are designed and synthesized for organic light-emitting diodes (OLEDs). These materials feature a phenyl-substituted fluorene dimer as a bulky and rigid core and anthracene as a functional active group. The novel use of a phenyl-substituted fluorene dimer as building skeleton to design functional molecules is reported for the first time. The thermal, photophysical, electrochemical, and electroluminescent (EL) properties are presented, as well as combined density functional study of their geometry and electronic structure. These compounds show excellent thermal resistance with high glass transition temperature (Tg) in the range 159–257 °C, thermal decomposition temperature (Td) 441–495 °C, and high fluorescent quantum yield (ΦF = 0.61–0.96, relative to 9,10-diphenylanthracene) as well as good film-forming and morphological stability. Remarkably, high-performance blue OLEDs are also fabricated in a simple three-layer device architecture using these compounds as emissive layer with luminance efficiency of 2.2–5.1 cd A−1 as a non-doped blue emitter and even higher efficiency of up to 13.6 cd A−1 and maximum external quantum efficiency 4.8% is obtained when doped a blue fluorescent dye, 4,4′-(1E,1′E)-2,2′(biphenyl-4,4′diyl)bis(ethane-2,1-diyl)bis(N,N-dip-tolyaniline) (DPAVBi). Furthermore, we fabricate highly efficient fluorescent white OLEDs employing an interesting emission in the longer wavelength of one of our compound combined with DPAVBi emission to achieve stable white light emission in a binary blend single emissive layer with high efficiency of 14.8 cd A−1 (5.3 lm W−1) and maximum brightness of 50248 cd m−2.
Co-reporter:Xiangnan Sun, Chong-an Di and Yunqi Liu
Journal of Materials Chemistry A 2010 vol. 20(Issue 13) pp:2599-2611
Publication Date(Web):03 Feb 2010
DOI:10.1039/B921449F
With the advances of organic field-effect transistors (OFETs), the interface between semiconductors and dielectrics has received much attention due to its dramatic effects on the morphology and charge-transport of organic semiconductors in OFETs. The purpose of this review is to give an overview of the recent progress in the engineering of the dielectric–semiconductor interface in OFETs. The interface-dependent performances of OFETs are reviewed, and interfacial control methods are especially dealt with an aim to solve interfacial effects. Finally, novel applications of the dielectric–semiconductor interface for achieving multifunctions are summarized to offer a clear map of interface engineering in OFETs.
Co-reporter:Lingchao Cao, Shiyan Chen, Dacheng Wei, Yunqi Liu, Lei Fu, Gui Yu, Hongming Liu, Xinyu Liu and Dexing Wu
Journal of Materials Chemistry A 2010 vol. 20(Issue 12) pp:2305-2309
Publication Date(Web):20 Jan 2010
DOI:10.1039/B922958B
Molecular electronics are considered one of the most promising ways to meet the challenge of micro-electronics facing its scaling down pathway. Molecular devices, especially molecular scale field-effect transistors (MSFET), are key building blocks for molecular electronics. Three major hurdles to device fabrication are yet to be overcome: electrode pairs must be fabricated with a controllable gap size commensurate with the functional molecule size of interest; the molecules of interest must be arranged between the electrodes with precise location and orientation control; and stable, conducting contacts must be made between the molecules and the electrodes. We have combined “top-down” and “bottom-up” approaches to solve these problems. Using photolithography and molecular lithography with self-assembled mono/multiple molecule layer(s) as a resist, we fabricated electrode structures with a controllable molecular-scale gap between source and drain electrodes and a third terminal of a buried gate. For our device, we synthesized a thiolated phthalocyanine derivative molecule, {di-[1-(S-acetylthio)-4-ethynylphenyl]-di-(tert-butyl)phthalocyanato}copper(II), with acetylthio groups on both ends, conjugated with ethynylphenyl groups. The synthesized end-thiolated molecules were assembled between the tailored molecular gap of the as-fabricated FET electrode structures in solution via Au–S bonding, forming stable contacts between the electrodes and the molecules, and a 3 terminal MSFET device was formed. Electrical measurements show that the device has characteristics of a typical FET device. The field-effect mobility of the as-fabricated MS-FET is 0.16 cm2 V−1 s−1.
Co-reporter:Jian Zheng, Chong-an Di, Yunqi Liu, Hongtao Liu, Yunlong Guo, Chunyan Du, Ti Wu, Gui Yu and Daoben Zhu
Chemical Communications 2010 vol. 46(Issue 31) pp:5728-5730
Publication Date(Web):30 Jun 2010
DOI:10.1039/C0CC00954G
Large-flake graphene membranes up to 300 μm2 can be exfoliated from graphite by oleyl amine based on solvothermal conditions. The exfoliated graphene sheets are of high quality and have few defects. The graphene dispersion, predominantly composed of monolayer graphene, had a high concentration of 0.15 mg ml−1, and can be stabilized against re-aggregation.
Co-reporter:Chunyan Du, Shanghui Ye, Yunqi Liu, Yunlong Guo, Ti Wu, Hongtao Liu, Jian Zheng, Cheng Cheng, Minliang Zhu and Gui Yu
Chemical Communications 2010 vol. 46(Issue 45) pp:8573-8575
Publication Date(Web):25 Oct 2010
DOI:10.1039/C0CC04147E
A fused-seven-ring anthracene derivative with two sulfur bridges, benzobisthioxanthene (BTA), was synthesized, facilely. OLEDs employing BTA as the emitter exhibited bright (maximum 40752 cd m−2) and efficient red emission (CIE, x = 0.64, y = 0.36) with a luminous efficiency of 4.4 cd A−1.
Co-reporter:Shiming Zhang, Yunlong Guo, Yajie Zhang, Ruigang Liu, Qikai Li, Xiaowei Zhan, Yunqi Liu and Wenping Hu
Chemical Communications 2010 vol. 46(Issue 16) pp:2841-2843
Publication Date(Web):18 Mar 2010
DOI:10.1039/B927468E
A new thienoacene with a sulfur-rich fused-nine-ring core was synthesized; bulk quantities of nanoribbons with mobilities as high as 0.42 cm2 V−1 s−1 were obtained by a direct solution process under ambient conditions.
Co-reporter:Zhong'an Li;Zuoquan Jiang;Guofu Qiu;Wenbo Wu;Gui Yu;Jingui Qin;Zhen Li
Macromolecular Chemistry and Physics 2010 Volume 211( Issue 16) pp:1820-1825
Publication Date(Web):
DOI:10.1002/macp.201000019
Co-reporter:Ying Liu;Chong-an Di Dr.;Chunyan Du ;Kun Lu;Wenfeng Qiu Dr.;Gui Yu
Chemistry - A European Journal 2010 Volume 16( Issue 7) pp:2231-2239
Publication Date(Web):
DOI:10.1002/chem.200902755

Abstract

A series of fused thiophenes composed of fused α-oligothiophene units as building blocks, end-capped with either styrene or 1-pentyl-4-vinylbenzene groups, has been synthesized through Stille coupling reactions. The compounds have been fully characterized by means of 1H NMR spectrometry, high-resolution mass spectrometry, and elemental analysis. The molecules present a transtrans configuration between their double bonds, which has been verified and confirmed by Fourier-transform infrared spectroscopy and single-crystal X-ray diffraction analysis. The X-ray crystal structures showed π–π overlap and sulfur–sulfur interactions between the adjacent molecules. The decomposition temperatures were all found to be above 300 °C, indicating that compounds of this series possess excellent thermal stability. The fact that no phase transition occurs at low temperature indicates that they should be well-suited for application in devices. Moreover, they possess low HOMO energy levels, based on cyclic voltammetry measurements, and suitable energy gaps, as determined from their thin-film UV/Vis spectra. Thin-film X-ray diffraction analysis and atomic force microscopy revealed high crystallinity on supporting substrates. In addition, as the substrate temperature has a significant influence on the morphology and the degree of crystallinity, the device performance could be optimized by varying the substrate temperature. These materials were found to exhibit optimal field-effect performance, with a mobility of 0.17 cm2 V−1 s−1 and an on/off ratio of 105, at a substrate temperature of 70 °C.

Co-reporter:Yunlong Guo, Chong-an Di, Hongtao Liu, Jian Zheng, Lei Zhang, Gui Yu, and Yunqi Liu
ACS Nano 2010 Volume 4(Issue 10) pp:5749
Publication Date(Web):September 21, 2010
DOI:10.1021/nn101463j
A general route was demonstrated to realize the patterning of reduced graphene oxide sheets (RGOs) on a variety of substrates by a combination of modulating the solution wettability of the substrates and spin-coating process. By virtue of usual surface treatment technique or application of mixed solvent, the GO solution wettability can be controlled precisely. The wettability modulation combined with spin-coating and reducing process brings on patterning of RGOs. This simple but effective, general, and low-cost approach holds great promise for numerous potential applications in organic electronics, flexible transparent conducting thin films, and flexible semi-transparent sensors.Keywords: organic transistor; patterning graphene oxide; sensors; spin-coating; wettability
Co-reporter:Zhong’an Li, Shanghui Ye, Yunqi Liu, Gu Yu, Wenbo Wu, Jingui Qin and Zhen Li
The Journal of Physical Chemistry B 2010 Volume 114(Issue 28) pp:9101-9108
Publication Date(Web):June 30, 2010
DOI:10.1021/jp1014077
In this article, four “A3+B2+C2”-type hyperbranched conjugated polymers (P1−P4) containing hexaphenylbenzene as the core were synthesized successfully for the first time with high yields through one-pot Suzuki polymerization reaction. The copolymerization percent of 1,3,4-oxadiazole units was adjusted to investigate the effect of polymer composition on the physical, optical, and EL properties. All polymers were well-characterized and exhibited good solubility, film-forming ability, and thermal stability. Both the solution and the films of these hyperbranched polymers emitted pure and stable deep-blue light emission, and their PL spectra did not change after annealing at 150 °C for 0.5 h in air, indicating that the hyperbranched structure, coupled to the introduced hexaphenylbenzene moieties, effectively suppressed the formation of aggregation excimer and keto defects. Two-layer PLED devices were fabricated to investigate the electroluminescence properties of these hyperbranched polymers, and P3 demonstrated a maximum luminance efficiency of 0.72 cd/A and a maximum brightness of 549 cd/m2 at 16.5 V.
Co-reporter:Liping Huang, Hongliang Zhang, Bin Wu, Yunqi Liu, Dacheng Wei, Jianyi Chen, Yunzhou Xue, Gui Yu, Hisashi Kajiura and Yongming Li
The Journal of Physical Chemistry C 2010 Volume 114(Issue 28) pp:12095-12098
Publication Date(Web):June 28, 2010
DOI:10.1021/jp102316c
A general and useful method has been developed to evaluate the metallic-to-semiconducting (M/S) ratio for separated single-walled carbon nanotubes (SWNTs). By virtue of measuring UV−vis−NIR spectra of a variety of solutions with different ratios of metallic-rich to semiconducting-rich SWNTs, the commercial IsoNanotubes samples as well as metallic-rich HiPCO SWNTs (HiPCO-M) separated by an Agarose gel method have been evaluated. Values of 99.5% metallic contents for IsoNanotubes-M, 98.9% semiconducting contents for IsoNanotubes-S, and 1.24 for the absorption coefficient of IsoNanotubes, whereas 80.4% metallic contents for HiPCO-M and 1.05 for the absorption coefficient of HiPCO SWNTs were obtained. This method does not need pure metallic (M-) or semiconducting (S-) SWNTs as references. Furthermore, we found that this method can also be applied to evaluate the M/S ratio for any SWNT samples.
Co-reporter:Chunyan Du, Yunlong Guo, Jianming Chen, Hongtao Liu, Ying Liu, Shanghui Ye, Kun Lu, Jian Zheng, Ti Wu, Yunqi Liu, Zhigang Shuai and Gui Yu
The Journal of Physical Chemistry C 2010 Volume 114(Issue 23) pp:10565-10571
Publication Date(Web):May 18, 2010
DOI:10.1021/jp101135e
Asymmetrical heteroacene up to six fused rings, tetraceno[2,3-b]benzo[d]thiophene (TBT), was synthesized facilely and its physicochemical properties and device applications were investigated. Field-effect transistors (FETs) fabricated with TBT as semiconducting layers showed carrier mobility up to 0.13 cm2 V−1 s−1. The transistors also exhibited a photoeffect and a ratio of photocurrent to dark-current as high as 104 was achieved. Density functional theory and FET results demonstrated that, for bent heteroacenes, increasing a benzene ring in conjugation length would not result in higher field-effect mobility, and the FET performance is more influenced by the thin film morphology. All these results suggest that the introduction of heteroatoms provides an efficient route for exploring the chemistry of larger acenes.
Co-reporter:Ying Liu;Gui Yu
Science China Chemistry 2010 Volume 53( Issue 4) pp:779-791
Publication Date(Web):2010 April
DOI:10.1007/s11426-010-0130-z
Fused thiophenes refer to oligothienoacenes in which several thiophenes are coupled together via two- or multi-positions and their derivatives. The synthesized organic semiconductors based on fused thiophenes exhibit excellent field effect properties due to their efficient intermolecular S⋯S interactions and π-π stacking. The performances of organic field-effect transistors (OFETs) depend not only on the materials but also on the devices. Such factors which influence the device performances as device structures, fabrication technologies and interface engineering are extensively investigated based on the fused thiophenes. Searching for new organic semiconductors and improving the device fabrication technologies are two major issues in the development of OFETs.
Co-reporter:Ying Liu;Xiangnan Sun;Chong-an Di Dr. ;Chunyan Du;Kun Lu Dr.;Shanghui Ye;Gui Yu
Chemistry – An Asian Journal 2010 Volume 5( Issue 7) pp:1550-1554
Publication Date(Web):
DOI:10.1002/asia.201000001
Co-reporter:Chong-an Di, Yunqi Liu, Gui Yu and Daoben Zhu
Accounts of Chemical Research 2009 Volume 42(Issue 10) pp:1573
Publication Date(Web):July 31, 2009
DOI:10.1021/ar9000873
By virtue of their excellent solution processibility and flexibility, organic field-effect transistors (OFETs) are considered outstanding candidates for application in low-cost, flexible electronics. Not only does the performance of OFETs depend on the molecular properties of the organic semiconductors involved, but it is also dramatically affected by the nature of the interfaces present. Therefore, interface engineering, a novel approach towards high-performance OFETs, has attracted considerable attention. In this Account, we focus on recent advances in the study of OFET interfaces—including electrode/organic layer interfaces, dielectric/organic layer interfaces, and organic/organic layer interfaces—that have resulted in improved device performance, enhanced stability, and the realization of organic light-emitting transistors. The electrode/organic layer interface, one of the most important interfaces in OFETs, usually determines the carrier injection characteristics. Focusing on OFETs with copper and silver electrodes, we describe effective modification approaches of the electrode/organic layer interfaces. Furthermore, the influence of electrode morphology on device performance is demonstrated. These results provide novel approaches towards high-performance, low-cost OFETs. The dielectric/organic layer interface is a vital interface that dominates carrier transport; modification of this interface therefore offers a general way to improve carrier transport accordingly. The dielectric layer also affects the device stability of OFETs. For example, high-performance pentacene OFETs with excellent stability are obtained by the selection of a dielectric layer with an appropriate surface energy. The organic/organic layer interface is a newly investigated topic in OFETs. Introduction of organic/organic layer interfaces, such as heterojunctions, can improve device performance and afford ambipolar OFETs. By designing laterally arranged heterojunctions made of organic field-effect materials and light-emitting materials, we realized both light emission and field effects simultaneously in a single OFET. The preceding decade has seen great progress in OFETs. Interface engineering provides a simple but effective approach toward creating high-performance OFETs and will continue to make essential contributions in the development of useful OFET-based devices. The exploration of novel interface engineering applications also merits further attention; the design of gas sensors through a more complete understanding of interface phenomena serves as just one example.
Co-reporter:Yugeng Wen;Chong-an Di;Ying Wang;Xiangnan Sun;Yunlong Guo;Jian Zheng;Weiping Wu;Shanghui Ye;Gui Yu
Advanced Materials 2009 Volume 21( Issue 16) pp:1631-1635
Publication Date(Web):
DOI:10.1002/adma.200802934
Co-reporter:Dacheng Wei, Yunqi Liu, Yu Wang, Hongliang Zhang, Liping Huang and Gui Yu
Nano Letters 2009 Volume 9(Issue 5) pp:1752-1758
Publication Date(Web):March 27, 2009
DOI:10.1021/nl803279t
To realize graphene-based electronics, various types of graphene are required; thus, modulation of its electrical properties is of great importance. Theoretic studies show that intentional doping is a promising route for this goal, and the doped graphene might promise fascinating properties and widespread applications. However, there is no experimental example and electrical testing of the substitutionally doped graphene up to date. Here, we synthesize the N-doped graphene by a chemical vapor deposition (CVD) method. We find that most of them are few-layer graphene, although single-layer graphene can be occasionally detected. As doping accompanies with the recombination of carbon atoms into graphene in the CVD process, N atoms can be substitutionally doped into the graphene lattice, which is hard to realize by other synthetic methods. Electrical measurements show that the N-doped graphene exhibits an n-type behavior, indicating substitutional doping can effectively modulate the electrical properties of graphene. Our finding provides a new experimental instance of graphene and would promote the research and applications of graphene.
Co-reporter:Dacheng Wei ; Yunqi Liu ; Hongliang Zhang ; Liping Huang ; Bin Wu ; Jianyi Chen ;Gui Yu
Journal of the American Chemical Society 2009 Volume 131(Issue 31) pp:11147-11154
Publication Date(Web):July 20, 2009
DOI:10.1021/ja903092k
Controllable and scalable production is of great importance for the application of graphene; however, to date, it is still a great challenge and a major obstacle which hampers its practical applications. Here, we develop a template chemical vapor deposition method for scalable synthesis of few-layer graphene ribbons (FLGRs) with controlled morphologies. The FLGRs have a good conductivity and are ideal for use in nanoelectromechanics (NEM). As an application, we fabricate a reversible NEM switch and a logic gate by using the FLGRs. This work realizes both controllable and scalable synthesis of graphene, provides an application of graphene in NEM switches, and would be valuable for both the scientific studies and the practical applications of graphene.
Co-reporter:Ying Liu;Ying Wang;Weiping Wu;Hongxia Xi;Limin Wang;Wenfeng Qiu;Kun Lu;Chunyan Du;Gui Yu
Advanced Functional Materials 2009 Volume 19( Issue 5) pp:772-778
Publication Date(Web):
DOI:10.1002/adfm.200800829

Abstract

The synthesis, characterization, and field-effect transistor (FET) properties of a new class of thieno[3,2-b]thieno[2′,3′:4,5]thieno[2,3-d]thiophene derivatives are described. The optical spectra of their films show the presence of stronger interactions between molecules in the solid state. Thermal analyses reveal that the three materials are thermally stable and have no phase transitions at low temperature. The crystal structures are determined, and show π-stacked structures and intermolecular S···S contacts. These organic materials exhibit p-type FET behavior with hole mobilities as high as 0.14 cm2 V−1 s−1 and an on/off current ratio of 106. These results indicate that thieno[3,2-b]thieno [2′,3′:4,5]thieno[2,3-d]thiophene, as a linear π-conjugated system, is an effective building block for developing high-performance organic semiconductors.

Co-reporter:Zhong'an Li;Gui Yu;Yugeng Wen;Yunlong Guo;Li Ji;Jingui Qin;Zhen Li
Advanced Functional Materials 2009 Volume 19( Issue 16) pp:2677-2683
Publication Date(Web):
DOI:10.1002/adfm.200900513

Abstract

A new hyperbranched polymer (HB-car), constructed fully by carbazole moieties, is successfully synthesized through a one-pot Suzuki coupling reaction. The resultant polymer is well-characterized, and its hole-transporting ability is studied carefully. The device, in which HB-car is utilized as a hole-transporting layer and tris-(8-hydroxyquinoline) aluminum as an electron-emitting layer as well as electron-transporting layer, gives a much higher efficiency (3.05 cd A–1), than that of a poly(N-vinylcarbazole) based device (2.19 cd A–1) under similar experimental conditions. The remarkable performance is attributed to its low energy barrier and enhanced hole-drifting ability in the HB-car based device. In addition, for the first time, a field-effect transistor (FET) based on the hyperbranched polymer is fabricated, and the organic FET device shows that HB-car is a typical p-type FET material with a saturation mobility of 1 × 10–5 cm2 V–1 s–1, a threshold voltage of –47.1 V, and an on-to-off current ratio of 103.

Co-reporter:Dacheng Wei;Lingchao Cao;Hongliang Zhang;Liping Huang;Gui Yu;Hisashi Kajiura;Yongming Li
Advanced Functional Materials 2009 Volume 19( Issue 22) pp:3618-3624
Publication Date(Web):
DOI:10.1002/adfm.200900924

Abstract

Single-walled carbon nanotubes (SWNTs) are a promising material for future nanotechnology. However, their applications are still limited in success because of the co-existence of metallic SWNTs and semiconducting SWNTs produced samples. Here, electrochemical etching, which shows both diameter and electrical selectivity, is demonstrated to remove SWNTs. With the aid of a back-gate electric field, selective removal of metallic SWNTs is realized, resulting in high-performance SWNT field-effect transistors with pure semiconducting SWNT channels. Moreover, electrochemical etching is realized on a selective area. These findings would be valuable for research and the application of SWNTs in electrochemistry and in electronic devices.

Co-reporter:Zuoquan Jiang;Zhongyin Liu;Chuluo Yang;Cheng Zhong;Jingui Qin;Gui Yu
Advanced Functional Materials 2009 Volume 19( Issue 24) pp:3987-3995
Publication Date(Web):
DOI:10.1002/adfm.200901534

Abstract

A series of fluorene-based oligomers with novel spiro-annulated triarylamine structures, namely DFSTPA, TFSTPA, and TFSDTC, are synthesized by a Suzuki cross-coupling reaction. The spiro-configuration molecular structures lead to very high glass transition temperatures (197–253 °C) and weak intermolecular interactions, and consequently the structures retain good morphological stability and high fluorescence quantum efficiencies(0.69–0.98). This molecular design simultaneously solves the spectral stability problems and hole-injection and transport issues for fluorene-based blue-light-emitting materials. Simple double-layer electroluminescence (EL) devices with a configuration of ITO/TFSTPA (device A) or TFSDTC (device B)/ TPBI/LiF/Al, where TFSTPA and TFSDTC serve as hole-transporting blue-light-emitting materials, show a deep-blue emission with a peak around 432 nm, and CIE coordinates of (0.17, 0.12) for TFSTPA and (0.16, 0.07) for TFSDTC, respectively, which are very close to the National Television System Committee (NTSC) standard for blue (0.15, 0.07). The maximum current efficiency/external quantum efficiencies are 1.63 cd A−1/1.6% for device A and 1.91 cd A−1/2.7% for device B, respectively. In addition, a device with the structure ITO/DFSTPA/Alq3/LiF/Al, where DFSTPA acts as both the hole-injection and -transporting material, is shown to achieve a good performance, with a maximum luminance of 14 047 cd m−2, and a maximum current efficiency of 5.56 cd A−1. These values are significantly higher than those of devices based on commonly usedN,N′-di(1-naphthyl)-N,N′-diphenyl-[1,1′-biphenyl]-4,4′-diamine (NPB) as the hole-transporting layer (11 738 cd m−2 and 3.97 cd A−1) under identical device conditions.

Co-reporter:Shanghui Ye, Yunqi Liu, Chong-an Di, Hongxia Xi, Weiping Wu, Yugen Wen, Kun Lu, Chunyan Du, Ying Liu and Gui Yu
Chemistry of Materials 2009 Volume 21(Issue 7) pp:1333
Publication Date(Web):March 9, 2009
DOI:10.1021/cm8032302
Two novel wide-energy-gap molecules, 1,3-bis(9-phenyl-9H-fluoren-9-yl)benzene (mDPFB) and 1,4-bis(9-phenyl-9H-fluoren-9-yl)benzene (pDPFB), suitable for blue phosphorescent host materials, were designed and prepared. The thermal, photophysical, and electrochemical properties as well as electroluminescence characteristics were fully investigated. Both mDPFB and pDPFB possess high singlet (4.0 eV) and triplet (2.8 eV) energies, well energy-matched with the deep-blue phosphorescent dopant, iridium(III) bis(4′,6′-difluorophenylpyridinato)tetrakis(1-pyrazolyl)borate (FIr6). The single crystals of the newly synthesized compounds mDPFB and pDPFB were grown, and their crystal structures were determined by X-ray diffraction. Both molecules adopt a rigid twisted tetrahedral crystallographic conformation, and no facial to facial π−π stacking exists in the solid state. The substituents at the 1,4-positions of benzene enhance the twisted degree of the fluorenyl rings and have predominant influence on the thermal and morphological properties. Both molecules possess excellent thermal stability with decomposition temperatures (Td) of 354 and 386 °C in nitrogen, respectively. Blue phosphorescent organic light-emitting diodes (OLEDs) were fabricated using pDPFB or mDPFB as host materials and FIr6 as a blue phosphorescent dopant with the configuration of ITO/NPB/mCP/host:FIr6/BCP/Ca:Ag. Devices based on the pDPFB host showed a maximum luminous power efficiency of 18.9 lm/W, with CIE coordinates (x, y) of (0.18, 0.33), improved by a factor of over 10 compared with the reference devices based on N,N′-dicarbazolyl-3,5-benzene (mCP) host. We discussed the mechanism and demonstrated that highly efficient blue phosphorescent OLEDs can be achieved in designing host materials which possess matched energy levels with the phosphorescent dopant, with high miscibility to the dopant, and with excellent film-forming ability and thermal and morphological stability.
Co-reporter:Chong-an Di, Gui Yu, Yunqi Liu, Yunlong Guo, Xiangnan Sun, Jian Zheng, Yugeng Wen, Weiping Wu and Daoben Zhu
Chemistry of Materials 2009 Volume 21(Issue 20) pp:4873
Publication Date(Web):October 2, 2009
DOI:10.1021/cm902594y
The patterning of an organic layer, a big challenge for organic field-effect transistors (OFETs), have recently received considerable attention. By using copper tetracyanoquinodimethane (Cu-TCNQ) modified copper electrodes with nanostructure, selective polycrystalline growth of organic semiconductors is achieved. For different organic semiconductors, varied ways for crystal growth are observed. The OFETs based on selectively deposited tetracyanoquinodimethane (TCNQ), rubrene, and copper phthalocyanine crystals are fabricated and exhibit good device performance. Rubrene devices exhibit maximum field-effect mobility up to 4.6 cm2/(V·s) which is comparable to that of corresponding single crystal device. In addition, an organic inverter made of patterned rubrene and TCNQ exhibits a gain of 23. These results offer a general approach to the fabrication of high performance OFETs and organic circuits.
Co-reporter:Xuemei Wang, Yunlong Guo, Yi Xiao, Lei Zhang, Gui Yu and Yunqi Liu
Journal of Materials Chemistry A 2009 vol. 19(Issue 20) pp:3258-3262
Publication Date(Web):31 Mar 2009
DOI:10.1039/B823336E
Two novel C60fullerene derivatives containing one or two perfluorooctyl groups were designed and efficiently synthesized. Organic field-effect transistors based on the bisperfluorooctyl compound 1 show high mobility up to 6.7 × 10−2 cm2 V−1 s and high on/off ratio up to 5 × 107, which qualifies compound 1 as promising n-type conductor material.
Co-reporter:Zuoquan Jiang, Haiqing Yao, Zhongyin Liu, Chuluo Yang, Cheng Zhong, Jingui Qin, Gui Yu and Yunqi Liu
Organic Letters 2009 Volume 11(Issue 18) pp:4132-4135
Publication Date(Web):August 14, 2009
DOI:10.1021/ol901635v
A bent ladder-type hexaphenylene with a carbazole core and spiro-linkage is designed and synthesized by using the ortho-linked spirobifluorene. The design eliminates the possibility of forming a positional isomer. As a blue-emitter, the BLHPC shows good thermal and color stability. A simple light-emitting device fabricated from BLHPC exhibits a maximum current efficiency of 1.46 cd/A and a maximum luminance of 505 cd/m2.
Co-reporter:Kun Lu, Yunqi Liu, Chong-an Di, Chunyan Du, Shanghui Ye, Ti Wu, Hongtao Liu, Xudong Xu and Gui Yu
CrystEngComm 2009 vol. 11(Issue 11) pp:2288-2290
Publication Date(Web):14 Aug 2009
DOI:10.1039/B913254F
A new rigid cyclic thiophene molecule was synthesized and its unusual and interesting single-crystal tubular products on a millimeter scale were obtained unexpectedly by a simple self-assemble technique in a solution process under ambient conditions.
Co-reporter:Chong-an Di, Gui Yu, Yunqi Liu, Yunlong Guo, Xiangnan Sun, Jian Zheng, Yugeng Wen, Ying Wang, Weiping Wu and Daoben Zhu
Physical Chemistry Chemical Physics 2009 vol. 11(Issue 33) pp:7268-7273
Publication Date(Web):11 Jun 2009
DOI:10.1039/B902476J
We report stable organic field-effect transistors (OFETs) based on pentacene. It was found that device stability strongly depends on the dielectric layer. Pentacene thin-film transistors based on the bare or polystyrene-modified SiO2 gate dielectrics exhibit excellent electrical stabilities. In contrast, the devices with the octadecyltrichlorosilane (OTS)-treated SiO2 dielectric layer showed the worst stabilities. The effects of the different dielectrics on the device stabilities were investigated. We found that the surface energy of the gate dielectric plays a crucial role in determining the stability of the pentacene thin film, device performance and degradation of electrical properties. Pentacene aggregation, phase transfer and film morphology are also important factors that influence the device stability of pentacene devices. As a result of the surface energy mismatch between the dielectric layer and organic semiconductor, the electronic performance was degraded. Moreover, when pentacene was deposited on the OTS-treated SiO2 dielectric layer with very low surface energy, pentacene aggregation occurred and resulted in a dramatic decrease of device performance. These results demonstrated that the stable OFETs could be obtained by using pentacene as a semiconductor layer.
Co-reporter:Yingping Zou, Guangyi Sang, Weiping Wu, Yunqi Liu, Yongfang Li
Synthetic Metals 2009 Volume 159(3–4) pp:182-187
Publication Date(Web):February 2009
DOI:10.1016/j.synthmet.2008.08.010
A new polythiophene derivative with octyloxyl triphenylamine-vinylene (OTPAV) conjugated side chain, OTPAV-PT, was synthesized according to the Stille coupling method, and characterized by 1H NMR, elemental analysis, GPC, TGA, UV–vis absorption spectroscopy, photoluminescence spectroscopy, and cyclic voltammetry. The polymer possesses excellent solubility in common organic solvents and good thermal stability with 5% weight loss temperature of 413 °C. The weight-average molecular weight of OTPAV-PT was 1.04 × 104 with the polydispersity index of 1.45. Polymer solar cell with the configuration of ITO/PEDOT:PSS/OTPAV-PT:PCBM/Al was fabricated, and the power conversion efficiency of the device was 0.21% under the illumination of AM1.5, 100 mW/cm2. The field effect hole mobility of the polymer reached 1.6 × 10−4 cm2 V−1 s−1.
Co-reporter:John A. Mikroyannidis, Shanghui Ye, Yunqi Liu
Synthetic Metals 2009 Volume 159(5–6) pp:492-500
Publication Date(Web):March 2009
DOI:10.1016/j.synthmet.2008.11.009
Two new linear divinylenes FN and PN that contained fluorene and phenylene, respectively, as central unit and naphthalimide terminal groups were synthesized by Heck coupling. In addition, two new star-shaped trivinylenes TPA-P and TPP-P that contained triphenylamine and 2,4,6-triphenylpyridine, respectively, as central core, and terminal phthalimide groups were similarly synthesized. All molecules were very soluble in common organic solvents due to their high fraction of aliphatic moieties which were attached to the central unit and/or the terminal imides. Trivinylenes showed higher thermal stability and higher glass transition temperature (118–126 °C) than divinylenes. FN, PN and TPA-P emitted green-orange light with maximum at 518–586 nm, while TPP-P emitted blue light with maximum at 444–462 nm due to the kinked central core of 2,4,6-triphenylpyridine. The maximum luminance among the four molecules is 583 cd/m2 at current density of 186 mA/cm2 and applied voltage of 19.5 V based on TPA-P, with a luminance efficiency maximum (ηmax) of 1.7 cd/A.
Co-reporter:Shiming Zhang, Yunlong Guo, Hongxia Xi, Chong-an Di, Jian Yu, Kai Zheng, Ruigang Liu, Xiaowei Zhan, Yunqi Liu
Thin Solid Films 2009 Volume 517(Issue 9) pp:2968-2973
Publication Date(Web):2 March 2009
DOI:10.1016/j.tsf.2008.11.102
Dithienothiophene-phenylene cooligomers with n-hexyloxy or n-dodecyloxy substituents have been synthesized and compared to the previously reported unsubstituted parent compound. The effect of substituents on the thermal, electronic, optical, thin film structure and field-effect transistor (OFET) properties was investigated. Structural phase transitions from highly-ordered nanocrystalline to liquid crystalline were observed at 241 and 213 °C for n-hexyloxy- and n-dodecyloxy-substituted compounds respectively, different from the parent compound. For the alkoxy-substituted compounds, the absorption spectra in thin film blue shift 50 nm, while the fluorescence spectra in thin film red shift 88–100 nm compared to those in solution. The OFET devices based on the alkoxy-substituted compounds exhibit mobilities as high as ca 0.02 cm2V− 1s− 1 and their performance is sensitive to the alkoxy substituents and substrate temperatures.
Co-reporter:Shiming Zhang, Yunlong Guo, Ling Wang, Qikai Li, Kai Zheng, Xiaowei Zhan, Yunqi Liu, Ruigang Liu and Li-Jun Wan
The Journal of Physical Chemistry C 2009 Volume 113(Issue 36) pp:16232-16237
Publication Date(Web):August 17, 2009
DOI:10.1021/jp903905n
A new liquid crystalline dithienothiophene dimer cap-functionalized with 3,4,5-tris-n-dodecyloxyphenyl groups (1) has been synthesized. The absorption spectrum blue-shifts 7 nm, while the fluorescence spectrum red-shifts 95 nm in thin film with respect to that in solution, suggesting that H-aggregate formation may occur and the molecules are cofacially aligned in the solid state. Compound 1 self-organized into highly ordered, long-range 2-dimensional nanopatterns on highly oriented pyrolytic graphite; their structures were characterized by scanning tunneling microscopy. The liquid crystalline phase was formed upon heating or cooling and was investigated using differential scanning calorimetry and polarizing optical microscopy. Thermal annealing led to a 13 nm red shift of absorption spectra of 1 in the thin film, indicating liquid crystalline enhanced ordering. Solution-processed organic field-effect transistors based on 1 exhibited a mobility of 1.7 × 10−3 cm2 V−1 s−1 and an on/off ratio of 2 × 105.
Co-reporter:Yinhua Zhou, Jianing Pei, Qingfeng Dong, Xiaobo Sun, Yunqi Liu and Wenjing Tian
The Journal of Physical Chemistry C 2009 Volume 113(Issue 18) pp:7882-7886
Publication Date(Web):April 10, 2009
DOI:10.1021/jp811522p
We fabricated polymer-based bulk heterojunction (BHJ) solar cells using a donor−acceptor (D-A) molecule N-propyl-3,6-bis[2-(3-dicyanomethylene-5,5-dimethylcyclohex-1-enyl)vinyl]carbazole (PDHC) as the acceptor. The strong photoluminescence (PL) quenching of poly[2-methoxy-5-(2′-ethyl-hexyloxy)-1,4-phenylene vinylene] (MEH-PPV) when mixed with PDHC means that efficient charge transfer has happened between MEH-PPV and PDHC. We used MEH-PPV and poly (3-hexylthiophene) (P3HT) as the donors and PDHC as the acceptor to fabricate BHJ solar cells. The cells with the structure of ITO/PEDOT/polymer:PDHC/LiF/Al exhibited a power conversion efficiency (PCE) about 0.2% under 100 mW/cm2 white light illumination. The open-circuit voltages (Vocs) of 1.14 V of the cells based on MEH-PPV:PDHC and about 0.76 V of the cells based on P3HT:PDHC were achieved, which are higher than the Vocs of the corresponding solar cells with phenyl-C-butyric acid methyl ester (PCBM) as the acceptor. In comparison with the cells based on PCBM, the relatively lower PCE of solar cells based on PDHC is due to its low electron mobility of 1.15 × 10−5 cm2 V−1 S−1 estimated by the space charge limited current method.
Co-reporter:Kun Lu;Xiangnan Sun;Chongan Di;Hongxia Xi;Gui Yu;Xike Gao;Chunyan Du
Journal of Polymer Science Part A: Polymer Chemistry 2009 Volume 47( Issue 5) pp:1381-1392
Publication Date(Web):
DOI:10.1002/pola.23246

Abstract

A series of novel branched polythiophene derivatives bearing different densities of vinylene-bridges as linking chains were synthesized by a general synthetic strategy. The organic field-effect transistors, which were fabricated by spin-coating the polymer solutions onto octadecyltrichlorosilane-modified SiO2/Si substrates with top-contact configuration, afforded a high mobility of 8.0 × 10−3 cm2 V−1 s−1 with an on/off ratio greater than 104 and a threshold voltage of about −3 V in saturation regime. The devices based on these polymers possessed better performance than those of polymers without conjugated bridges and polymers with longer conjugated bridges. These results demonstrated that the combination of conjugated polythiophene backbones and vinylene-bridges would improve the carrier mobility. As an emerging class of conjugated materials, polymers with vinylene-bridges as linking chains would open up new opportunities in organic electronics, and their applications in organic electronics are promising. © 2009 Wiley Periodicals, Inc. J Polym Sci Part A: Polym Chem 47: 1381–1392, 2009

Co-reporter:Meixiu Wan;Weiping Wu;Guangyi Sang;Yingping Zou;Yongfang Li
Journal of Polymer Science Part A: Polymer Chemistry 2009 Volume 47( Issue 16) pp:4028-4036
Publication Date(Web):
DOI:10.1002/pola.23464

Abstract

A novel conjugated polymer, poly(thienylene-vinylene-thienylene) with cyano substituent (CN-PTVT) was synthesized via Stille coupling for the application in air stable field-effect transistor and polymer solar cell. The polymer was characterized by 1H NMR, elemental analysis, UV-vis absorption and photoluminescence spectroscopy, TGA, cyclic voltammetry and XRD analysis. CN-PTVT exhibits a good thermal stability with 5% weight loss at 306 °C. The FET hole mobility of the polymer reached 5.9 × 10−3 cm2 V−1 s−1 with Ion/Ioff ratio of 4.9 × 104, which is one of the highest performance among the air-stable amorphous polymers. The polymer solar cell based on CN-PTVT as donor and PCBM as acceptor shows a relatively high open-circuit voltage of 0.82 V and a power conversion efficiency of 0.3% under the illumination of AM1.5, 100 mW/cm2. © 2009 Wiley Periodicals, Inc. J Polym Sci Part A: Polym Chem 47: 4028–4036, 2009

Co-reporter:Youjun He;Weiping Wu;Yongfang Li
Journal of Polymer Science Part A: Polymer Chemistry 2009 Volume 47( Issue 20) pp:5304-5312
Publication Date(Web):
DOI:10.1002/pola.23579

Abstract

Poly(3-[2-(5-hexyl-2-thienyl) ethenyl]-2,2′-bithiophene) (P2, see Scheme 1) with conjugated thienylvinyl side chain was synthesized by copolymerization of the thiophene units with and without conjugated side chain with Pd-catalyzed Stille coupling method. For comparison, P1 with the hexyl side chain instead of conjugated side chain was also synthesized. P2 film shows broad absorption in the visible region with absorption edge at about 700 nm. The solution-processed polymer field-effect transistors were fabricated and characterized with bottom gate/top contact geometry. The organic field-effect transistors (OFET) based on P2 showed an average hole mobility of about 0.034 cm2/Vs (the highest value reached 0.061 cm2/Vs) upon annealing at about 180 °C for 30 min, with a threshold voltage of −1.15 V and an on/off ratio of 104 with n-octadecyltrichlorosilane (OTS) modified SiO2 substrate. In comparison, the OFET based on P1 displayed a hole mobility of 8.9 × 10–4 cm2/Vs and an on/off ratio of 104 with OTS modified SiO2 substrate. The results indicate that the polythiophene derivative with conjugated thienylvinyl side chain is a promising polymer for the application in polymer field-effect transistors. © 2009 Wiley Periodicals, Inc. J Polym Sci Part A: Polym Chem 47: 5304–5312, 2009

Co-reporter:Chunyan Du;Shanghui Ye;Jianming Chen;Yunlong Guo Dr.;Kun Lu;Ying Liu;Ting Qi Dr.;Xike Gao Dr.;Zhigang Shuai Dr.;Gui Yu Dr.
Chemistry - A European Journal 2009 Volume 15( Issue 33) pp:8275-8282
Publication Date(Web):
DOI:10.1002/chem.200900860

Abstract

A series of novel asymmetrical fused compounds containing the backbone of fluorene[2,3-b]benzo[d]thiophene (FBT) were effectively synthesized and fully characterized. Single-crystal X-ray studies demonstrated that the length of the substituent side chains greatly affects the solid-state packing of the obtained fused compounds. DFT, photophysical, and electrochemical studies all showed that the FBTs have large band gaps, low-lying HOMO energy levels, and therefore good stability toward oxidation. Moreover, the substituents strongly influence the fluorescence properties of the resulting FBT derivatives. The di-n-hexyl compound exhibits intense fluorescence in solution with the highest quantum yield of up to 91 %. Solution-processed green phosphorescent organic light-emitting diodes with the di-n-butyl derivative as the host material exhibited a maximum brightness of 14 185 cd m−2 and a luminescence efficiency of 12 cd A−1.

Co-reporter:Yu Wang;Liping Huang;Dacheng Wei;Hongliang Zhang
Nano Research 2009 Volume 2( Issue 11) pp:
Publication Date(Web):2009 November
DOI:10.1007/s12274-009-9087-7
A method for the non-destructive purification of single-walled carbon nanotubes (SWNTs) using classical coordination chemistry to remove the metal catalyst has been developed. In preliminary tests, the conductivity of films based on the resulting SWNTs was markedly better than that of films prepared from SWNTs purified by treatment with oxidizing acid solutions. The transparent and conducting SWNT films have potential applications in optoelectronic devices.
Co-reporter:Kun Lu, Yunlong Guo, Yunqi Liu, Chong-an Di, Tao Li, Zhongming Wei, Gui Yu, Chunyan Du and Shanghui Ye
Macromolecules 2009 Volume 42(Issue 9) pp:
Publication Date(Web):April 8, 2009
DOI:10.1021/ma900026u
Co-reporter:Ting Qi, Yunlong Guo, Yunqi Liu, Hongxia Xi, Hengjun Zhang, Xike Gao, Ying Liu, Kun Lu, Chunyan Du, Giu Yu and Daoben Zhu
Chemical Communications 2008 (Issue 46) pp:6227-6229
Publication Date(Web):14 Oct 2008
DOI:10.1039/B813683A
A novel type of anti and syn isomers of a pentacyclic compound consisting of two thiophene rings and one pyrrole ring were efficiently synthesized from benzo[b]thiophene, and the anti isomer exhibits better charge transport and OFET properties compared with the syn isomer and its N-hexyl substitution.
Co-reporter:Youjun He, Weiping Wu, Guangjing Zhao, Yunqi Liu and Yongfang Li
Macromolecules 2008 Volume 41(Issue 24) pp:9760-9766
Publication Date(Web):November 19, 2008
DOI:10.1021/ma801923c
Poly(3,6-dihexyl-thieno[3,2-b]thiophene vinylene) (DH-PTTV) was prepared by the Pd-catalyzed Stille-coupling method. Compared with poly(3-hexylthienylene vinylene) (P3HTV), strong photoluminescence was observed for DH-PTTV solution, whereas the maximum absorption of DH-PTTV was blue-shifted. The solution-processed organic field-effect transistors (OFETs) were fabricated with bottom gate/top contact geometry. The highest FET hole mobility of DH-PTTV after thermal annealing at 180 °C for 30 min reached 0.032 cm2/V·s with an on/off ratio of 105, which is a high value for the conjugated polymers. Polymer solar cells based on the polymers were fabricated, and the power conversion efficiency of the devices based on P3HTV and DH-PTTV was 0.19 and 0.28%, respectively, under the illumination of AM 1.5 and 100 mW/cm2. The efficiency of the device based on DH-PTTV is ca. 50% higher than that of the devices based on P3HTV, which could be benefited from the higher hole mobility of DH-PTTV.
Co-reporter:Xuebin Huang, Chunli Zhu, Shiming Zhang, Weiwei Li, Yunlong Guo, Xiaowei Zhan, Yunqi Liu and Zhishan Bo
Macromolecules 2008 Volume 41(Issue 19) pp:6895-6902
Publication Date(Web):September 11, 2008
DOI:10.1021/ma801407u
Soluble conjugated alternating porphyrin−dithienothiophene copolymers—single-bond linked (I) and triple-bond linked (IIa and IIb)—were synthesized by palladium(0)-catalyzed Stille and Sonagashira coupling reactions, respectively. The thermal, electrochemical, optical, charge transport, and photovoltaic properties of these copolymers were examined; the effect of the triple bond was studied. I exhibits onset decomposition temperature (Td) of 410 °C and glass-transition temperature (Tg) of 180 °C, higher than those of IIb (Td, 330 °C; Tg, 130 °C). The absorption spectrum of I in thin film exhibits a sharp Soret band at 450 nm and two weak Q-bands at 563−619 nm, while IIb exhibits a sharp Soret band at 491 nm and a strong Q-band at 760 nm. The emission maxima of I and IIb in solution are located at 642 and 722 nm respectively. IIb is electrochemically active in both the oxidation and reduction regions, while I shows only oxidation peak. The field-effect hole mobilities as high as 2.1 × 10−4 cm2 V−1 s−1 were obtained for these copolymers. Polymer solar cells (PSCs) were fabricated based on the blend of the polymers and methanofullerene [6,6]-phenyl C61-butyric acid methyl ester (PCBM). The power conversion efficiency (PCE) of 0.3% was achieved under AM 1.5, 100 mW/cm2 for the PSC using IIb:PCBM (1:3, w/w) as active layer. The PCE of the PSC based on IIb:PCBM (1:3, w/w) is double that based on I:PCBM (1:2, w/w), consistent with that IIb exhibits stronger Q-band absorption and higher mobility at room temperature.
Co-reporter:Yu Huang, Ying Wang, Guangyi Sang, Erjun Zhou, Lijun Huo, Yunqi Liu and Yongfang Li
The Journal of Physical Chemistry B 2008 Volume 112(Issue 43) pp:13476-13482
Publication Date(Web):October 8, 2008
DOI:10.1021/jp8055043
A polythiophene derivative with the simplest conjugated side chain, poly(3-hexy-1-enylthiophene) (P3HET), was synthesized by Stille self-coupling reaction. A comparative study of the newly synthesized polymer with poly(3-hexylthiophene) (P3HT), one of the most widely investigated optoelectronic materials, is presented. The effect of double bond (C═C) on the side chain toward thermal stability and optical and electronic properties was fully characterized by TGA, UV−vis absorption spectroscopy, photoluminescence spectroscopy, and cyclic voltammetry. The hole mobility of P3HET determined by the space−charge-limited current (SCLC) model is 6.7 × 10−3 cm2/V s, which is comparable to P3HT with similar molecular weight and regularity and 1 order of magnitude higher than most conjugated-side-chain polythiophene derivatives. Polymer solar cells (PSCs) and field effect transistors (FETs) were fabricated respectively to exploit its potential applications in optoelectronic devices.
Co-reporter:H. Li;L. Li;Q. Tang;X. Yang;Y. Song;W. Xu;Y. Liu;Z. Shuai;W. Hu;D. Zhu
Advanced Materials 2007 Volume 19(Issue 18) pp:2613-2617
Publication Date(Web):14 AUG 2007
DOI:10.1002/adma.200700682

High performance organic thin-film transistors were demonstrated based on a cheap, commercially available organic semiconductor, titanyl phthalocyanine (TiOPc), in its α-phase structure. The high performance is due to its ultra close π-stack and favorable edge-on molecular orientation in the films. The high performance, the remarkable stability, low price, nontoxicity, and commercial availability of TiOPc suggest promising prospects in OTFTs.

Co-reporter:Yabin Song, Chong-an Di, Wei Xu, Yunqi Liu, Deqing Zhang and Daoben Zhu
Journal of Materials Chemistry A 2007 vol. 17(Issue 42) pp:4483-4491
Publication Date(Web):30 Aug 2007
DOI:10.1039/B708887F
Two novel macrocycles based on triphenylamine (TPA) have been synthesized by McMurry coupling reactions. The cyclic compound 2 consisted of two triphenylamines linked with ethylene bridges bearing two n-butyl chains. The compound 3 was based on N,N,N′,N′-tetraphenylbenzidine (TPD) units with macrocyclic architecture. They were fully characterized by cyclic voltammetry, UV-vis absorption and self-assembly properties. The crystal structure of 2 was determined by X-ray analysis. Atomic force microscope and scanning electron microscope images showed that compound 3 could form interesting fiber-like nanostructures by self-assembly. Both of the compounds can be used as active layers for p-type OFETs. The OFET device based on 2 prepared via a vacuum-deposit method gave a mobility of 2.3 × 10–3 cm2 V–1 s–1 and a current on/off ratio of 105. High quality thin films of 3 were fabricated by spin coating from solution, and gave a mobility of 2.0 × 10–3 cm2 V–1 s–1 with a current on/off ratio of 2 × 105. The results showed that the TPA derivatives with cyclic structures might fit better for OFETs. They may provide promising new choices for organic semiconductors.
Co-reporter:Pingàn Hu, Yunqi Liu, Lei Fu, Lingchao Cao and Daoben Zhu
Chemical Communications 2004 (Issue 5) pp:556-557
Publication Date(Web):04 Feb 2004
DOI:10.1039/B312708G
By pyrolysis of CdS powder in inert gas, single-crystalline cadmium nanotubes growing in the form of a heap, were produced for the first time in high yield.
Co-reporter:Biao Wang, Xinyu Liu, Hongmin Liu, Dexin Wu, Huaping Wang, Jianming Jiang, Xianbao Wang, Ping-an Hu, Yunqi Liu and Daoben Zhu
Journal of Materials Chemistry A 2003 vol. 13(Issue 5) pp:1124-1126
Publication Date(Web):24 Mar 2003
DOI:10.1039/B301061A
Patterns and alignment of carbon nanotubes (CNTs) are particularly important for fabricating functional devices such as field emitters, scanning probes, sensors, and nanoelectronics. In this paper, the effects of various metal substrates on CNT growth are studied. Depending on the different growth mechanisms associated with the various substrate surfaces, two- or three-dimensional micropatterns of aligned carbon nanotubes have been prepared via pyrolysis of iron(II) phthalocyanine. Patterns created on silicon substrates were obtained by photolithographic techniques. The prepared CNT patterns have resolutions down to the micrometer scale. Possible growth mechanisms of aligned carbon nanotubes on different metal surfaces are also discussed.
Co-reporter:Ping'an Hu, Yunqi Liu, Xianbiao Wang, Lei Fu and Daoben Zhu
Chemical Communications 2003 (Issue 11) pp:1304-1305
Publication Date(Web):06 May 2003
DOI:10.1039/B302821F
The tower-like structure of ZnO nanocolumns grows normal to alumina substrates via pyrolysis and oxidation of ZnS, and is formed by stacking of ZnO nanocrystals layer upon layer.
Co-reporter:Zhiyuan Zhao, Zhihong Yin, Huajie Chen, Yunlong Guo, Qinxin Tang and Yunqi Liu
Journal of Materials Chemistry A 2017 - vol. 5(Issue 11) pp:NaN2898-2898
Publication Date(Web):2017/02/20
DOI:10.1039/C6TC05659H
A strongly electron-withdrawing benzo[c][1,2,5]oxadiazole (BOZ) unit, as the second electron acceptor segment, is incorporated into the naphthalenediimide (NDI) based polymer backbone for the first time. Therefore, a unipolar n-type polymer semiconductor (PNBO) with a regioregular A1–D–A2–D configuration is developed successfully. It is found that BOZ-containing polymer PNBO not only has a deep-lying LUMO energy level of ca. −4.0 eV, which facilitates electron-injection from an Au electrode into the active layer, but also possesses a deep enough low HOMO energy level of −5.9 eV for blocking hole-injection. The carrier transporting performance of PNBO is characterized by solution-processable polymeric field-effect transistors (PFETs). These results demonstrate that a smooth surface morphology and a compact solid stacking endow PNBO with excellent unipolar n-type electron-transporting characteristics; a highest electron mobility of up to 2.43 cm2 V−1 and an excellent shelf storage with a negligible decay in 70 days are achieved.
Co-reporter:Li Qiu, Chunmeng Yu, Na Zhao, Weichao Chen, Yunlong Guo, Xiaobo Wan, Renqiang Yang and Yunqi Liu
Chemical Communications 2012 - vol. 48(Issue 100) pp:NaN12227-12227
Publication Date(Web):2012/11/05
DOI:10.1039/C2CC36689D
Two linear fused heteroacenes bearing a pyrrolo[3,2-b]pyrrole core have been synthesized via a novel reductive ring closure methodology in three steps and in good overall yield. Preliminary OFET results showed that dinaphtho[2,3-b:2′,3′-f]pyrrolo[3,2-b]pyrrole (DNPP) is a potential candidate for organic electronics.
Co-reporter:Cheng Cheng, Chunmeng Yu, Yunlong Guo, Huajie Chen, Yu Fang, Gui Yu and Yunqi Liu
Chemical Communications 2013 - vol. 49(Issue 20) pp:NaN2000-2000
Publication Date(Web):2013/01/07
DOI:10.1039/C2CC38811A
A diketopyrrolopyrrole–thiazolothiazole copolymer with a short π–π stacking distance (3.52 Å), due to the introduction of heteroaromatic rings, exhibits a high charge mobility above 3.40 cm2 V−1 s−1 at a relatively gentle annealing temperature.
Co-reporter:Xiaotong Liu, Hongyan Zhang, Yongqiang Ma, Xiaoli Wu, Lixuan Meng, Yunlong Guo, Gui Yu and Yunqi Liu
Journal of Materials Chemistry A 2013 - vol. 1(Issue 5) pp:NaN1884-1884
Publication Date(Web):2012/11/20
DOI:10.1039/C2TA00173J
A new form of graphene-coated silica (GCS) has been prepared by mixing exfoliated graphene oxide with acid-treated silica and reducing it with hydrazine hydrate so that it coats the silica particles. This method is simple, convenient, and robust. The GCS composite particles have been characterized using optical photographs, Raman spectroscopy, Fourier transform infrared spectroscopy (FT-IR), X-ray diffraction (XRD), thermogravimetric analysis (TGA), Brunauer–Emmett–Teller (BET) analysis, and elemental analysis. These analyses show that the reaction effectively coats silica particles with graphene. The composite particles achieve higher levels of adsorption and are more widely applicable than five other sorbents (graphite carbons, activated carbon, pure graphene, C18 silica, and silica) for the eleven pesticides assayed. We discuss the adsorption mechanism and consider it to be dependent on the electron-donating abilities of the S, P, and N atoms and the strong π-bonding network of the benzene rings. This research demonstrates that graphene-based composite materials could be used to remove pesticide residues in aqueous environments.
Co-reporter:Lanchao Ma, Zhengran Yi, Shuai Wang, Yunqi Liu and Xiaowei Zhan
Journal of Materials Chemistry A 2015 - vol. 3(Issue 9) pp:NaN1948-1948
Publication Date(Web):2014/12/17
DOI:10.1039/C4TC02462A
A new copolymer (P(DPP4T-co-BDT)) was synthesized by Stille coupling polymerization of 3,6-bis(5′-bromo-[2,2′-bithiophen]-5-yl)-2,5-bis(2-octyldodecyl)pyrrolo-[3,4-c]-pyrrole-1,4(2H,5H)-dione and 2,6-bis(trimethyltin)-4,8-dimethoxybenzo[1,2-b:3,4-b′]dithiophene. P(DPP4T-co-BDT) showed good solution processability, good thermal stability with decomposition temperature of >330 °C, and strong and broad absorption in the range of 500–900 nm. Field-effect transistors based on P(DPP4T-co-BDT) thin films exhibited a hole mobility of up to 0.047 cm2 V−1 s−1, an on/off current ratio of 106, and a threshold voltage of −5 V after thermal annealing at 200 °C. Thin film phototransistors based on P(DPP4T-co-BDT) exhibited a photoresponsivity of up to 4.0 × 103 A W−1 and a photocurrent/dark-current ratio of 6.8 × 105 under white light irradiation with a low light intensity (9.7 μW cm−2).
Co-reporter:Xuemei Wang, Yunlong Guo, Yi Xiao, Lei Zhang, Gui Yu and Yunqi Liu
Journal of Materials Chemistry A 2009 - vol. 19(Issue 20) pp:NaN3262-3262
Publication Date(Web):2009/03/31
DOI:10.1039/B823336E
Two novel C60fullerene derivatives containing one or two perfluorooctyl groups were designed and efficiently synthesized. Organic field-effect transistors based on the bisperfluorooctyl compound 1 show high mobility up to 6.7 × 10−2 cm2 V−1 s and high on/off ratio up to 5 × 107, which qualifies compound 1 as promising n-type conductor material.
Co-reporter:Shanghui Ye, Jianming Chen, Chong-an Di, Yunqi Liu, Kun Lu, Weiping Wu, Chunyan Du, Ying Liu, Zhigang Shuai and Gui Yu
Journal of Materials Chemistry A 2010 - vol. 20(Issue 16) pp:NaN3194-3194
Publication Date(Web):2010/03/01
DOI:10.1039/B925418H
A new series of highly fluorescent blue-emitting materials based on fluorene and anthracene hybrids are designed and synthesized for organic light-emitting diodes (OLEDs). These materials feature a phenyl-substituted fluorene dimer as a bulky and rigid core and anthracene as a functional active group. The novel use of a phenyl-substituted fluorene dimer as building skeleton to design functional molecules is reported for the first time. The thermal, photophysical, electrochemical, and electroluminescent (EL) properties are presented, as well as combined density functional study of their geometry and electronic structure. These compounds show excellent thermal resistance with high glass transition temperature (Tg) in the range 159–257 °C, thermal decomposition temperature (Td) 441–495 °C, and high fluorescent quantum yield (ΦF = 0.61–0.96, relative to 9,10-diphenylanthracene) as well as good film-forming and morphological stability. Remarkably, high-performance blue OLEDs are also fabricated in a simple three-layer device architecture using these compounds as emissive layer with luminance efficiency of 2.2–5.1 cd A−1 as a non-doped blue emitter and even higher efficiency of up to 13.6 cd A−1 and maximum external quantum efficiency 4.8% is obtained when doped a blue fluorescent dye, 4,4′-(1E,1′E)-2,2′(biphenyl-4,4′diyl)bis(ethane-2,1-diyl)bis(N,N-dip-tolyaniline) (DPAVBi). Furthermore, we fabricate highly efficient fluorescent white OLEDs employing an interesting emission in the longer wavelength of one of our compound combined with DPAVBi emission to achieve stable white light emission in a binary blend single emissive layer with high efficiency of 14.8 cd A−1 (5.3 lm W−1) and maximum brightness of 50248 cd m−2.
Co-reporter:Yabin Song, Chong-an Di, Wei Xu, Yunqi Liu, Deqing Zhang and Daoben Zhu
Journal of Materials Chemistry A 2007 - vol. 17(Issue 42) pp:NaN4491-4491
Publication Date(Web):2007/08/30
DOI:10.1039/B708887F
Two novel macrocycles based on triphenylamine (TPA) have been synthesized by McMurry coupling reactions. The cyclic compound 2 consisted of two triphenylamines linked with ethylene bridges bearing two n-butyl chains. The compound 3 was based on N,N,N′,N′-tetraphenylbenzidine (TPD) units with macrocyclic architecture. They were fully characterized by cyclic voltammetry, UV-vis absorption and self-assembly properties. The crystal structure of 2 was determined by X-ray analysis. Atomic force microscope and scanning electron microscope images showed that compound 3 could form interesting fiber-like nanostructures by self-assembly. Both of the compounds can be used as active layers for p-type OFETs. The OFET device based on 2 prepared via a vacuum-deposit method gave a mobility of 2.3 × 10–3 cm2 V–1 s–1 and a current on/off ratio of 105. High quality thin films of 3 were fabricated by spin coating from solution, and gave a mobility of 2.0 × 10–3 cm2 V–1 s–1 with a current on/off ratio of 2 × 105. The results showed that the TPA derivatives with cyclic structures might fit better for OFETs. They may provide promising new choices for organic semiconductors.
Co-reporter:Lei Zhang, Chong-an Di, Gui Yu and Yunqi Liu
Journal of Materials Chemistry A 2010 - vol. 20(Issue 34) pp:NaN7073-7073
Publication Date(Web):2010/06/03
DOI:10.1039/C0JM00331J
Manufacturing organic circuits from solution provides an opportunity to realize low-cost fabrication of large-area flexible electronics, such as radio frequency identity tags, sensor arrays and flexible displays. Inspired by the potential applications, significant efforts have been devoted to develop organic field-effect transistors with solution processed components in the past decade. Herein, we summarize recent progresses in solution processable functional materials including organic semiconductors, electrode materials, and dielectric materials. Various solution manufacturing techniques, patterning techniques and related device engineering methods are also reviewed. Finally, all-solution processed logic circuits are discussed from the point of view of practical application. All these achievements represent a big step forward and promise the solution processed OFETs a bright future.
Co-reporter:Lingchao Cao, Shiyan Chen, Dacheng Wei, Yunqi Liu, Lei Fu, Gui Yu, Hongming Liu, Xinyu Liu and Dexing Wu
Journal of Materials Chemistry A 2010 - vol. 20(Issue 12) pp:NaN2309-2309
Publication Date(Web):2010/01/20
DOI:10.1039/B922958B
Molecular electronics are considered one of the most promising ways to meet the challenge of micro-electronics facing its scaling down pathway. Molecular devices, especially molecular scale field-effect transistors (MSFET), are key building blocks for molecular electronics. Three major hurdles to device fabrication are yet to be overcome: electrode pairs must be fabricated with a controllable gap size commensurate with the functional molecule size of interest; the molecules of interest must be arranged between the electrodes with precise location and orientation control; and stable, conducting contacts must be made between the molecules and the electrodes. We have combined “top-down” and “bottom-up” approaches to solve these problems. Using photolithography and molecular lithography with self-assembled mono/multiple molecule layer(s) as a resist, we fabricated electrode structures with a controllable molecular-scale gap between source and drain electrodes and a third terminal of a buried gate. For our device, we synthesized a thiolated phthalocyanine derivative molecule, {di-[1-(S-acetylthio)-4-ethynylphenyl]-di-(tert-butyl)phthalocyanato}copper(II), with acetylthio groups on both ends, conjugated with ethynylphenyl groups. The synthesized end-thiolated molecules were assembled between the tailored molecular gap of the as-fabricated FET electrode structures in solution via Au–S bonding, forming stable contacts between the electrodes and the molecules, and a 3 terminal MSFET device was formed. Electrical measurements show that the device has characteristics of a typical FET device. The field-effect mobility of the as-fabricated MS-FET is 0.16 cm2 V−1 s−1.
Co-reporter:Xiangnan Sun, Chong-an Di and Yunqi Liu
Journal of Materials Chemistry A 2010 - vol. 20(Issue 13) pp:NaN2611-2611
Publication Date(Web):2010/02/03
DOI:10.1039/B921449F
With the advances of organic field-effect transistors (OFETs), the interface between semiconductors and dielectrics has received much attention due to its dramatic effects on the morphology and charge-transport of organic semiconductors in OFETs. The purpose of this review is to give an overview of the recent progress in the engineering of the dielectric–semiconductor interface in OFETs. The interface-dependent performances of OFETs are reviewed, and interfacial control methods are especially dealt with an aim to solve interfacial effects. Finally, novel applications of the dielectric–semiconductor interface for achieving multifunctions are summarized to offer a clear map of interface engineering in OFETs.
Co-reporter:Zhong'an Li, Zuoquan Jiang, Shanghui Ye, Cathy K. W. Jim, Gui Yu, Yunqi Liu, Jingui Qin, Ben Zhong Tang and Zhen Li
Journal of Materials Chemistry A 2011 - vol. 21(Issue 38) pp:NaN14671-14671
Publication Date(Web):2011/08/15
DOI:10.1039/C1JM11176K
In this paper, four new π-conjugated dendrimers G1 and G2-1–G2-3, constructed by triphenylamine and carbazole moieties, have been successfully prepared via a simple synthetic route. This molecular design imparts the materials with good solution-processability, high thermal and morphological stabilities, and low oxidation potential, all of which are promising properties for optoelectronic materials. The double-layer OLEDs fabricated using these materials through solution processing demonstrate that they can exhibit dual functions, hole-transporting and light-emitting. Devices using G1 or G2-1 as the hole-transporting layer present good stability during the passage of current, with a maximum efficiency of 1.70 and 1.59 cd A−1, respectively. Moreover, devices using these dendrimers as the emitting layer show moderate performance, and the device of G2-2 gives a maximum luminance and efficiency of 1190 cd m−2 and 1.67 cd A−1, respectively, thanks to three-dimensional building of the dendritic system, which might suppress the inherent reductive or aggregation-caused quenching that usually happens for triphenylamine/carbazole derivatives to some degree. Also, the photo-cross-linking property of triple bonds enables ready fabrication of highly fluorescent photoresist patterns of these dendrimers.
Co-reporter:Hongtao Liu, Yunqi Liu and Daoben Zhu
Journal of Materials Chemistry A 2011 - vol. 21(Issue 10) pp:NaN3345-3345
Publication Date(Web):2010/11/24
DOI:10.1039/C0JM02922J
Recently, a lot of effort has been focused on improving the performance and exploring the electric properties of graphene. This article presents a summary of chemical doping of graphene aimed at tuning the electronic properties of graphene. p-Type and n-type doping of graphene achieved through surface transfer doping or substitutional doping and their applications based on doping are reviewed. Chemical doping for band gap tuning in graphene is also presented. It will be beneficial to designing high performance electronic devices based on chemically doped graphene.
Co-reporter:Liping Huang, Bin Wu, Gui Yu and Yunqi Liu
Journal of Materials Chemistry A 2011 - vol. 21(Issue 4) pp:NaN929-929
Publication Date(Web):2010/10/20
DOI:10.1039/C0JM02225J
As a new member of the carbon family, graphene has many fascinating properties and potential applications with the greatest degree of similarity to its “brother” carbon nanotubes (CNTs). Research on graphene has developed rapidly in the past 6 years, partially due to its similarity to carbon nanotubes which have been extensively studied for almost two decades. The adaptation of carbon nanotube research strategies for the development of graphene preparation, functionalization and applications as well as the conversion and hybrid structures of carbon nanotubes and graphene are reviewed in this feature article.
Co-reporter:Dugang Chen, Yan Zhao, Cheng Zhong, Siqi Gao, Gui Yu, Yunqi Liu and Jingui Qin
Journal of Materials Chemistry A 2012 - vol. 22(Issue 29) pp:NaN14644-14644
Publication Date(Web):2012/05/10
DOI:10.1039/C2JM31755A
Two donor–acceptor (D–A) alternating copolymers (P1 and P2) with phthalimide or thieno[3,4-c]pyrrole-4,6-dione as the electron acceptor and bithiophene as the electron donor have been synthesized by Stille polycondensation. Both polymers showed good thermal stability and a low HOMO level. Organic field-effect transistor (OFET) devices with common architectures were fabricated to evaluate and compare the FET properties of the two polymers. Though P2 exhibits better coplanarity than P1, the FET results revealed that both the hole mobility and current on–off ratio of P1 are more than one order of magnitude higher than P2. Theoretical calculations and AFM were conducted to analyze the reason for this very interesting result, and it was found that polymer chain conformation is another important factor (in addition to coplanarity) for polymers to obtain high FET performance.
Co-reporter:Hongtao Liu, Lei Zhang, Yunlong Guo, Cheng Cheng, Lianjiang Yang, Lang Jiang, Gui Yu, Wenping Hu, Yunqi Liu and Daoben Zhu
Journal of Materials Chemistry A 2013 - vol. 1(Issue 18) pp:NaN3109-3109
Publication Date(Web):2013/02/27
DOI:10.1039/C3TC00067B
A novel reducing reagent, Lawesson's reagent (LR), is used to directly reduce graphene oxide (GO) films and single GO sheets. The as-prepared reduced graphene oxide (GOLR) is fully characterized by XPS, Raman, FTIR, 13C NMR and XRD. Most of the oxygen-containing groups are efficiently removed by LR and the conjugated graphene networks are restored. Highly conductive GOLR films and sheets are obtained. As a proof of concept, thin film field-effect transistors based on pentacene using patterned GOLR films as electrodes are fabricated and show high performances. Common cotton threads coated with GOLR can be used as flexible connecting wires to illuminate commercial light-emitting diodes. After low temperature annealing, such as 300 °C, higher conductivity and mobility of GOLR are obtained due to the removal of additional oxygen groups and better ordering of graphene sheets.
Co-reporter:Wenbo Wu, Shanghui Ye, Lijin Huang, Li Xiao, Yingjie Fu, Qi Huang, Gui Yu, Yunqi Liu, Jingui Qin, Qianqian Li and Zhen Li
Journal of Materials Chemistry A 2012 - vol. 22(Issue 13) pp:NaN6382-6382
Publication Date(Web):2012/02/22
DOI:10.1039/C2JM16514G
In this paper, tetraphenylethylene (TPE) units, a well-known aggregation-induced emission (AIE) active group, are utilized to construct the hyperbranched polymer HP-TPE-Cz with carbazole moieties, a good hole-transporting and electroluminescent group, through an “A2 + B4” approach by using a one-pot Suzuki polycondensation reaction. For comparison, its analog linear polymer LP-TPE-Cz, also constructed from these two moieties, was prepared. These two polymers exhibit interesting aggregation-induced emission enhanced (AIEE) behavior and act as explosive chemosensors with high sensitivity both as nanoparticles and in solid state, due to the presence of TPE units. Also, the HP-TPE-Cz PLED device exhibited a remarkably enhanced current efficiency (2.13 cd A−1) and luminescence efficiency (5914 cd m−2), compared with its analog linear polymer LP-TPE-Cz (1.04 cd A−1, 1654 cd m−2).
Co-reporter:Huajie Chen;Chang He;Gui Yu;Yan Zhao;Jianyao Huang;Minliang Zhu;Hongtao Liu;Yunlong Guo;Yongfang Li
Journal of Materials Chemistry A 2012 - vol. 22(Issue 9) pp:
Publication Date(Web):2012/02/07
DOI:10.1039/C2JM16104D
A highly π-extended copolymer, PPTT, was developed based on 6H-phenanthro[1,10,9,8-cdefg]carbazole (PCZ) and thiazolo[5,4-d]thiazole derivative units, being the first PCZ-containing polymer, as well as its first applications in OTFTs and OPVs. This polymer exhibited an excellent solubility in several common organic solvents, a good film-forming ability, a reasonably high thermal stability, and a deep-lying HOMO energy level, meeting well the requirements of OTFTs and OPVs. The investigation of the field-effect and photovoltaic performances demonstrated that PPTT had a high hole mobility of 0.13 cm2 V−1 s−1 and good power conversion efficiency (PCE) of 3.20%, which were among the highest mobilities and PCEs for a single polymer material with dual transistor and OPV functions simultaneously.
Co-reporter:Weiping Wu, Yunqi Liu and Daoben Zhu
Chemical Society Reviews 2010 - vol. 39(Issue 5) pp:NaN1502-1502
Publication Date(Web):2009/12/08
DOI:10.1039/B813123F
π-Conjugated molecular materials with fused rings are the focus of considerable interest in the emerging area of organic electronics, since the combination of excellent charge carrier mobility and high stability may lead to their practical applications. This tutorial review discusses the synthesis, properties and applications of π-conjugated organic semiconducting materials, especially those with fused rings. The achievements to date, the remaining problems and challenges, and the key research that needs to be done in the near future are all discussed.
Co-reporter:Hongliang Zhang, Bin Wu, Wenping Hu and Yunqi Liu
Chemical Society Reviews 2011 - vol. 40(Issue 3) pp:NaN1336-1336
Publication Date(Web):2010/12/07
DOI:10.1039/B920457C
Single-walled carbon nanotubes (SWNTs) possess unique electronic properties that make them very promising materials for use in both nano-electronics and thin film devices. However, SWNTs are always produced as a mixture of metallic and semiconducting nanotubes, which is a major roadblock to their widespread application. This tutorial review provides a brief summary of ways of separating single-walled carbon nanotubes into metallic and semiconducting fractions. Various methods including selective growth, selective removal, selective adsorption and band structure modulation—all of which aim to produce pure SWNTs with well-defined electronic properties—are systematically discussed. The main problems in this field, the outlook for separation techniques and some views of future developments are presented.
Co-reporter:Xin Chen, Bin Wu and Yunqi Liu
Chemical Society Reviews 2016 - vol. 45(Issue 8) pp:NaN2074-2074
Publication Date(Web):2016/02/05
DOI:10.1039/C5CS00542F
Graphene, an amazing two-dimensional material with excellent physical properties, has attracted great attention in various disciplines. Both fundamental studies and applications require graphene samples with controlled parameters including their quality, size, crystallinity, layer number and so on. While graphene can be prepared by direct exfoliation from mother materials or growth on transition metals, the uncontrolled production or the additional complex transfer process has been challenging for graphene applications. Direct preparation on a desired dielectric substrate is an important research direction that potentially addresses these problems. Many advances have been made in the past few years, and this tutorial review provides a brief summary of ways of preparing graphene on dielectric substrates. Various methods including the annealing method, direct chemical vapor deposition graphene synthesis on conventional dielectric substrates and hexagonal boron nitride layers are systematically reviewed and discussed. The main problems and further directions in this field are also presented.
Co-reporter:Chunyan Du, Shanghui Ye, Yunqi Liu, Yunlong Guo, Ti Wu, Hongtao Liu, Jian Zheng, Cheng Cheng, Minliang Zhu and Gui Yu
Chemical Communications 2010 - vol. 46(Issue 45) pp:NaN8575-8575
Publication Date(Web):2010/10/25
DOI:10.1039/C0CC04147E
A fused-seven-ring anthracene derivative with two sulfur bridges, benzobisthioxanthene (BTA), was synthesized, facilely. OLEDs employing BTA as the emitter exhibited bright (maximum 40752 cd m−2) and efficient red emission (CIE, x = 0.64, y = 0.36) with a luminous efficiency of 4.4 cd A−1.
Co-reporter:Ting Qi, Yunlong Guo, Yunqi Liu, Hongxia Xi, Hengjun Zhang, Xike Gao, Ying Liu, Kun Lu, Chunyan Du, Giu Yu and Daoben Zhu
Chemical Communications 2008(Issue 46) pp:
Publication Date(Web):
DOI:10.1039/B813683A
Co-reporter:Jian Zheng, Chong-an Di, Yunqi Liu, Hongtao Liu, Yunlong Guo, Chunyan Du, Ti Wu, Gui Yu and Daoben Zhu
Chemical Communications 2010 - vol. 46(Issue 31) pp:NaN5730-5730
Publication Date(Web):2010/06/30
DOI:10.1039/C0CC00954G
Large-flake graphene membranes up to 300 μm2 can be exfoliated from graphite by oleyl amine based on solvothermal conditions. The exfoliated graphene sheets are of high quality and have few defects. The graphene dispersion, predominantly composed of monolayer graphene, had a high concentration of 0.15 mg ml−1, and can be stabilized against re-aggregation.
Co-reporter:Li Qu, Yunlong Guo, Hao Luo, Cheng Zhong, Gui Yu, Yunqi Liu and Jingui Qin
Chemical Communications 2012 - vol. 48(Issue 80) pp:NaN9967-9967
Publication Date(Web):2012/07/11
DOI:10.1039/C2CC33445C
A simple nickel bis(dithiolene) complex has been developed as an excellent n-type molecular semiconductor for FETs, with an electron mobility of 0.11 cm2 V−1 s−1 and an on/off ratio of 2 × 106 despite its small π-conjugated system. Good FET stability in ambient conditions has also been observed.
Co-reporter:Shiming Zhang, Yunlong Guo, Yajie Zhang, Ruigang Liu, Qikai Li, Xiaowei Zhan, Yunqi Liu and Wenping Hu
Chemical Communications 2010 - vol. 46(Issue 16) pp:NaN2843-2843
Publication Date(Web):2010/03/18
DOI:10.1039/B927468E
A new thienoacene with a sulfur-rich fused-nine-ring core was synthesized; bulk quantities of nanoribbons with mobilities as high as 0.42 cm2 V−1 s−1 were obtained by a direct solution process under ambient conditions.
Co-reporter:Chunmeng Yu, Yunlong Guo, Hongtao Liu, Ni Yan, Zhiyan Xu, Gui Yu, Yu Fang and Yunqi Liu
Chemical Communications 2013 - vol. 49(Issue 58) pp:NaN6494-6494
Publication Date(Web):2013/05/30
DOI:10.1039/C3CC42377H
Swift fabrication of a non-covalently modified reduced graphene oxide electronic sensor has been developed. An unparalleled detection limit is demonstrated for Hg2+, down to the picomolar range.
Co-reporter:Chong-an Di, Gui Yu, Yunqi Liu, Yunlong Guo, Xiangnan Sun, Jian Zheng, Yugeng Wen, Ying Wang, Weiping Wu and Daoben Zhu
Physical Chemistry Chemical Physics 2009 - vol. 11(Issue 33) pp:NaN7273-7273
Publication Date(Web):2009/06/11
DOI:10.1039/B902476J
We report stable organic field-effect transistors (OFETs) based on pentacene. It was found that device stability strongly depends on the dielectric layer. Pentacene thin-film transistors based on the bare or polystyrene-modified SiO2 gate dielectrics exhibit excellent electrical stabilities. In contrast, the devices with the octadecyltrichlorosilane (OTS)-treated SiO2 dielectric layer showed the worst stabilities. The effects of the different dielectrics on the device stabilities were investigated. We found that the surface energy of the gate dielectric plays a crucial role in determining the stability of the pentacene thin film, device performance and degradation of electrical properties. Pentacene aggregation, phase transfer and film morphology are also important factors that influence the device stability of pentacene devices. As a result of the surface energy mismatch between the dielectric layer and organic semiconductor, the electronic performance was degraded. Moreover, when pentacene was deposited on the OTS-treated SiO2 dielectric layer with very low surface energy, pentacene aggregation occurred and resulted in a dramatic decrease of device performance. These results demonstrated that the stable OFETs could be obtained by using pentacene as a semiconductor layer.
Co-reporter:Yunzhou Xue, Bin Wu, Hongtao Liu, Jiahui Tan, Wenping Hu and Yunqi Liu
Physical Chemistry Chemical Physics 2014 - vol. 16(Issue 38) pp:NaN20397-20397
Publication Date(Web):2014/08/01
DOI:10.1039/C4CP02935F
Large-area substitutional phosphorus–nitrogen co-doped monolayer graphene is directly synthesized on a Cu surface by chemical vapor deposition using molecules of phosphonitrilic chloride trimer as the phosphorus and nitrogen sources. The doping levels of both phosphorus and nitrogen atoms decrease as a function of the growth temperature. In contrast, the doping effect is enhanced with temperature because of the formation of more stable bond configurations for dopants at higher temperatures. Moreover, the doping amount of nitrogen atoms is always higher than that of phosphorus atoms at all used temperatures. The phosphorus and nitrogen co-doped graphene exhibits remarkable air-stable n-type characteristics. This work demonstrates the critical role of phosphorus atoms in achieving enhanced electron donation compared to nitrogen atom doping of graphene, and is important for various applications associated with the need for air-stable n-type graphene materials.
Co-reporter:Ying Liu, Zhiyang Liu, Hao Luo, Xiaodong Xie, Ling Ai, Ziyi Ge, Gui Yu and Yunqi Liu
Journal of Materials Chemistry A 2014 - vol. 2(Issue 41) pp:NaN8810-8810
Publication Date(Web):2014/08/22
DOI:10.1039/C4TC01688B
An efficient synthetic approach to a series of benzothieno[2,3-b]thiophene (BTT) derivatives used as an important core with different bridge spacers is described. Thermal properties of the present compounds are stable: neither phase transition nor thermal decomposition was observed up to 300 °C. The adjacent molecule crystal stackings are shifted affording a nearly 1/3 intermolecular π-overlap. The OFETs based on BTTB exhibit excellent field-effect performances with a mobility of 0.46 cm2 V−1 s−1 and on–off current ratios larger than 107 at room temperature. All the results demonstrate these benzothieno[2,3-b]thiophene derivatives as promising materials for optoelectronic devices.
Stannane, 1,1'-[4,8-bis[(2-butyloctyl)oxy]benzo[1,2-b:4,5-b']dithiophene-2,6-diyl]bis[1,1,1-trimethyl-
(+)-azonazine
Thieno[3,4-b]thiophene-2-carboxylic acid, 4,6-dibromo-3-fluoro-, 2-ethylhexyl ester
Thiophene, 2,2'-(2,5-dibromo-1,4-phenylene)bis-
