How free charge is generated at organic donor–acceptor interfaces is an important question, as the binding energy of the lowest energy (localized) charge transfer states should be too high for the electron and hole to escape each other. Recently, it has been proposed that delocalization of the electronic states participating in charge transfer is crucial, and aggregated or otherwise locally ordered structures of the donor or the acceptor are the precondition for this electronic characteristic. The effect of intermolecular aggregation of both the polymer donor and fullerene acceptor on charge separation is studied. In the first case, the dilute electron acceptor triethylsilylhydroxy-1,4,8,11,15,18,22,25-octabutoxyphthalocyaninatosilicon(IV) (SiPc) is used to eliminate the influence of acceptor aggregation, and control polymer order through side-chain regioregularity, comparing charge generation in 96% regioregular (RR-) poly(3-hexylthiophene) (P3HT) with its regiorandom (RRa-) counterpart. In the second case, ordered phases in the polymer are eliminated by using RRa-P3HT, and phenyl-C₆₁-butyric acid methyl ester (PC₆₁BM) is used as the acceptor, varying its concentration to control aggregation. Time-resolved microwave conductivity, time-resolved photoluminescence, and transient absorption spectroscopy measurements show that while ultrafast charge transfer occurs in all samples, long-lived charge carriers are only produced in films with intermolecular aggregates of either RR-P3HT or PC₆₁BM, and that polymer aggregates are just as effective in this regard as those of fullerenes.

The morphological origin of anisotropic charge transport in uniaxially strain aligned poly(3-hexylthiophene) (P3HT) films is investigated. The macroscale field effect mobility anisotropy is measured in an organic thin film transistor (OTFT) configuration and compared to the local aggregate P3HT mobility anisotropy determined using time-resolved microwave conductivity (TRMC) measurements. The field effect mobility anisotropy in highly aligned P3HT films is substantially higher than the local mobility anisotropy in the aggregate P3HT. This difference is attributed to preferentially aligned polymer tie-chains at grain boundaries that contribute to macroscale charge transport anisotropy but not the local anisotropy. The formation of sharp grains between oriented crystalline P3HT, through tie chain removal by thermal annealing the strained aligned films, results in an order of magnitude drop in the measured field effect mobility for charge transport parallel to the strain direction. The field effect mobility anisotropy is cut in half while the local mobility anisotropy remains relatively constant. The local mobility anisotropy is found to be surprisingly low in the aligned films, suggesting that the π−π stacking direction supports charge carrier mobility on the same order of magnitude as that in the intrachain direction, possibly due to poor intrachain mobility through chain torsion.

The microstructure of neat conjugated polymers is crucial in determining the ultimate morphology and photovoltaic performance of polymer/fullerene blends, yet until recently, little work has focused on controlling the former. Here, we demonstrate that both the long-range order along the (100)-direction and the lamellar crystal thickness along the (001)-direction in neat poly(3-hexylthiophene) (P3HT) and poly[(3,3″-didecyl[2,2′:5′,2″-terthiophene]-5,5″-diyl)] (PTTT-10) thin films can be manipulated by varying crystallization temperature. Changes in crystalline domain size impact the yield and dynamics of photogenerated charge carriers. Time-resolved microwave conductivity measurements show that neat polymer films composed of larger crystalline domains have longer photoconductance lifetimes and charge carrier yield decreases with increasing crystallite size for P3HT. Our results suggest that the classical polymer science description of temperature-dependent crystallization of polymers from solution can be used to understand thin-film formation in neat conjugated polymers, and hence, should be considered when discussing the structural evolution of organic bulk heterojunctions. © 2014 Wiley Periodicals, Inc. J. Polym. Sci., Part B: Polym. Phys. 2014, 52, 700–707

The influence of solid-state microstructure on the optoelectronic properties of conjugated polymers is widely recognized, but still poorly understood. Here, we show how the microstructure of conjugated polymers controls the yield and decay dynamics of long-lived photogenerated charge in neat films. Poly(3-hexylthiophene) was used as a model system. By varying the molecular weight, we drive a transition in the polymer microstructure from nonentangled, chain-extended, paraffinic-like to entangled, semicrystalline (M_W = 5.5–347 kg/mol). The molecular weight range at which this transition occurs (M_W = 40–50 kg/mol) can be deduced from the drastic change in elongation at break found in tensile tests. Linear absorption measurements of free-exciton bandwidth and time-resolved microwave conductivity (TRMC) measurements of transient photoconductance track the concomitant evolution in optoelectronic properties of the polymer as a function of M_W. TRMC measurements show that the yield of free photogenerated charge increases with increasing molecular weight in the paraffinic regime and saturates at the transition into the entangled, semicrystalline regime. This transition in carrier yield correlates with a sharp transition in free-exciton bandwidth and decay dynamics at a similar molecular weight. We propose that the transition in microstructure controls the yield and decay dynamics of long-lived photogenerated charge. The evolution of a semicrystalline structure with well-defined interfaces between amorphous and crystalline domains of the polymer is required for spatial separation of the electron and hole. This structural characteristic not only largely controls the yield of free charges, but also serves as a recombination center, where mobile holes encounter a bath of dark electrons resident in the amorphous phase and recombine with quasi first-order kinetics. © 2011 Wiley Periodicals, Inc. J Polym Sci Part B: Polym Phys, 2011
