Co-reporter:Edward P. Tomlinson, Sanjoy Mukherjee, Bryan W. Boudouris
Organic Electronics 2017 Volume 51(Volume 51) pp:
Publication Date(Web):1 December 2017
DOI:10.1016/j.orgel.2017.09.029
•Radical dopants increased the conductivity of poly(3-hexylthiophene) by > 100-fold.•Proper radical selection increased the poly(3-hexylthiophene) thermopower as well.•This provides for a charge neutral doping means that circumvents current limits.•This could lead to the design of next-generation polymer thermoelectric materials.Organic thermoelectric materials provide a means to reclaim, in part, potentially lost energy through a solid-state process that converts low-value thermal gradients (in the form of heat) to electricity; however, a new avenue towards improving the performance of these emerging thermoelectric materials must be brought to light before their widespread implementation becomes warranted. Here, we develop a blend of open-shell small molecules and closed-shell, conjugated polymers in order to evaluate how the chemical composition of the distinct open-shell, charge-neutral molecular dopants impacts the thermoelectric performance of a common hole-transporting (p-type) polymer semiconductor, poly(3-hexylthiophene) (P3HT). In doing so, we are able to increase the electrical conductivity of the P3HT composite both with and without affecting the oxidation state of the polymer. Specifically, the electrical conductivity of the conjugated polymer increases without changing the oxidation state of the P3HT when the preferentially-oxidized species 4-hydroxy-2,2,6,6-tetramethylpiperidin-1-oxyl (TEMPO) radical is incorporated into the hole-conducting thin film. Moreover, the inclusion of the preferentially-reduced galvinoxyl (GAV) radical also increases the electrical conductivity of the thin film; however, this small molecule dopant changes the oxidation state of the P3HT moiety. The ability to achieve the gains in the electrical conductivity of P3HT with the TEMPO radical in a manner that is independent of its oxidation state was confirmed using optical spectroscopy, cyclic voltammetry, and x-ray diffraction techniques. Importantly, this ability to enhance the electrical conductivity of P3HT in a manner that is independent of the oxidation state of the polymer provides a means to circumvent the oft-observed inverse relationship between the electrical conductivity and thermopower of the semiconducting polymer, and this combined effect allows for an ∼170-fold increase for the TEMPO-containing composites compared to a ∼70-fold increase for the GAV-containing composites. Thus, the described phenomena for charge-neutral radical dopants provides a set of critical design parameters for future polymer thermoelectric materials and composites, and it opens a new pathway towards high-performance organic thermoelectric devices.Download high-res image (359KB)Download full-size image
Co-reporter:Sanjoy Mukherjee
Molecular Systems Design & Engineering (2016-Present) 2017 vol. 2(Issue 2) pp:159-164
Publication Date(Web):2017/05/09
DOI:10.1039/C7ME00010C
Three distinctly different and stable colored states of phenylgalvinoxyl (i.e., neutral phenolic, radical, and anionic species) small molecule and macromolecular systems are evaluated as a function of the solution pH. A clear halochromic effect is readily observed in the design of the polymer, in a manner that is distinct from the more oft-studied small molecule analogs. This key design paradigm allows the chemical nature of the phenylgalvinoxyl moieties to be comparable to a standard AND logic function, which evolves based upon the structural constitution of the material. Moreover, this crucial change in behavior allows for the revelation that the formation of the radical polymer that bears a galvinoxyl pendant group occurs through base-promoted step-wise oxidation, and this, in turn, provides a critical handle by which to design future radical polymer archetypes and to build molecular logic systems based upon this emerging class of functional materials.
Co-reporter:Seung Hyun Sung, Nikhil Bajaj, Jeffrey F. Rhoads, George T. Chiu, Bryan W. Boudouris
Organic Electronics 2016 Volume 37() pp:148-154
Publication Date(Web):October 2016
DOI:10.1016/j.orgel.2016.06.020
•Radical polymer interlayers improve the performance of field-effect transistors.•The modification of the organic-metal interface reduced contact resistance.•This led to improved field-effect mobility values for pentacene-based devices.•The ON/OFF ratios of the devices were increased by 3 orders of magnitude.•The layer improved the electrochemical and morphological aspects at the interface.Modifying the organic-metal interface in organic field-effect transistors (OFETs) is a critical means by which to improve device performance; however, to date, all of the interfacial modifying layers utilized in these systems have been closed-shell in nature. Here, we introduce open-shell oxidation-reduction-active (redox-active) macromolecules, namely radical polymers, in order to serve as interfacial modifiers in pentacene-based OFETs. Through careful selection of the chemistry of the specific radical polymer, poly(2,2,6,6-tetramethylpiperidine-1-oxyl methacrylate) (PTMA), the charge transport energy level of the interfacial modifying layer was tuned to provide facile charge injection and extraction between the pentacene active layer and the gold source and drain electrodes of the OFET. The inclusion of this radical polymer interlayer, which was deposited in through straightforward inkjet printing, led to bottom-contact, bottom-gate OFETs with significantly increased mobility and ON/OFF current ratios relative to OFETs without the PTMA interlayer. The underlying mechanism for this improvement in device performance is explained in terms of the charge transport capability at the organic-metal interface and with respect to the pentacene grain growth on the radical polymer. Thus, this effort presents a new, open-shell-based class of materials for interfacial modifying materials, and describes the underlying physics behind the practical operation of these materials.
Co-reporter:Aditya G. Baradwaj;Lizbeth Rostro
Macromolecular Chemistry and Physics 2016 Volume 217( Issue 3) pp:477-484
Publication Date(Web):
DOI:10.1002/macp.201500272
Co-reporter:Jennifer S. Laster;Nicholas A. Deom;Stephen P. Beaudoin
Journal of Polymer Science Part B: Polymer Physics 2016 Volume 54( Issue 19) pp:1968-1974
Publication Date(Web):
DOI:10.1002/polb.24102
ABSTRACT
Efficient removal of particles from topologically-complex surfaces is of significant import for a range of applications (e.g., explosive residue removal in security arenas). Here, we synthesize next-generation polymeric particle removal swabs with tuned structural features to elucidate the influence of the polymer microstructure on the removal of trace particles from surfaces. Specifically, microstructured free-standing films of the conducting polymer polypyrrole (PPy) were synthesized through template-assisted electropolymerization techniques. The removal of polystyrene microspheres from representative aluminum surfaces of varying roughness was evaluated as a function of the PPy microstructure. PPy-based microstructured swabs displayed increased particle trapping properties relative to non-textured PPy-based swabs and current commercial swabs. This increased effectiveness occurred from the more intimate particle-swab contact, leading to increased van der Waals interactions for the microstructured swabs. Therefore, this effort provides critical design rules for the production of microstructured conducting polymer materials for their application toward advanced particle removal technologies. © 2016 Wiley Periodicals, Inc. J. Polym. Sci., Part B: Polym. Phys. 2016, 54, 1968–1974
Co-reporter:Adam J. Wingate
Journal of Polymer Science Part A: Polymer Chemistry 2016 Volume 54( Issue 13) pp:1875-1894
Publication Date(Web):
DOI:10.1002/pola.28088
ABSTRACT
Tailor-made polymers containing specific chemical functionalities have ushered in a number of emerging fields in polymer science. In most of these next-generation applications the focus of the community has centered upon closed-shell macromolecules. Conversely, macromolecules containing stable radical sites have been less studied despite the promise of this evolving class of polymers. In particular, radical-containing macromolecules have shown great potential in magnetic, energy storage, and biomedical applications. Here, the progress regarding the syntheses of open-shell containing polymers are reviewed in two distinct subclasses. In the first, the syntheses of radical polymers (i.e., materials composed of non-conjugated macromolecular backbones and with open-shell units present on the polymer pendant sites) are described. In the second, polyradical (i.e., macromolecules containing stabilized radical sites either within the macromolecular backbone or those containing radical sites that are stabilized through a large degree of conjugation) synthetic schemes are presented. Thus, the state-of-the-art in open-shell macromolecular syntheses will be reported and future means by which to advance the current archetype will be discussed. By detailing the synthetic pathways possible for, and the inherent synthetic limitations of, the creation of these functional polymers, the community will be able to extend the bounds of the radical-containing macromolecular paradigm. © 2016 Wiley Periodicals, Inc. J. Polym. Sci., Part A: Polym. Chem. 2016, 54, 1875–1894
Co-reporter:Aditya G. Baradwaj, Si Hui Wong, Jennifer S. Laster, Adam J. Wingate, Martha E. Hay, and Bryan W. Boudouris
Macromolecules 2016 Volume 49(Issue 13) pp:4784-4791
Publication Date(Web):June 22, 2016
DOI:10.1021/acs.macromol.6b00730
Radical polymers (i.e., macromolecules composed of a nonconjugated polymer backbone and with stable radical sites present on the side chains of the repeat units) can transport charge in the solid state through oxidation–reduction (redox) reactions that occur between the electronically localized open-shell pendant groups. As such, pristine (i.e., not doped) thin films of these functional macromolecules have electrical conductivity values on the same order of magnitude as some common electronically active conjugated polymers. However, unlike the heavily evaluated regime of conjugated polymer semiconductors, the impact of molecular dopants on the optical, electrochemical, and solid-state electronic properties of radical polymers has not been established. Here, we combine a model radical polymer, poly(2,2,6,6-tetramethylpiperidinyloxy methacrylate) (PTMA), with a small molecule redox-active salt, 4-acetamido-2,2,6,6-tetramethyl-1-oxopiperidinium tetrafluoroborate (TEMPOnium), in order to elucidate the effect of molecular doping on this emerging class of functional macromolecular thin films. Note that the TEMPOnium salt was specifically selected because the cation in the salt has a very similar molecular architecture to that of an oxidized repeat unit of the PTMA polymer. Importantly, we demonstrate that the addition of the TEMPOnium salt simultaneously alters the electrochemical environment of the thin film without quenching the number of open-shell sites present in the PTMA-based composite thin film. This environmental alteration changes the chemical signature of the PTMA thin films in a manner that modifies the electrical conductivity of the radical polymer-based composites. By decoupling the ionic and electronic contributions of the observed current passed through the PTMA-based thin films, we are able to establish how the presence of the redox-active TEMPOnium salts affects both the transient and steady-state transport abilities of doped radical polymer thin films. Additionally, at an optimal loading (i.e., doping density) of the redox-active salt, the electrical conductivity of PTMA increased by a factor of 5 relative to that of pristine PTMA. Therefore, these data establish an underlying mechanism of doping in electronically active radical polymers, and they provide a template by which to guide the design of next-generation radical polymer composites.
Co-reporter:Edward P. Tomlinson, Matthew J. Willmore, Xiaoqin Zhu, Stuart W. A. Hilsmier, and Bryan W. Boudouris
ACS Applied Materials & Interfaces 2015 Volume 7(Issue 33) pp:18195
Publication Date(Web):August 11, 2015
DOI:10.1021/acsami.5b05860
Polymer thermoelectric devices are emerging as promising platforms by which to convert thermal gradients into electricity directly, and poly(3,4-ethylene dioxythiophene) doped with poly(styrenesulfonate) (PEDOT:PSS) is a leading candidate in a number of these thermoelectric modules. Here, we implement the stable radical-bearing small molecule 4-hydroxy-2,2,6,6-tetramethylpiperidin-1-oxyl (TEMPO–OH) as an intermolecular dopant in order to tune the electrical conductivity, thermopower, and power factor of PEDOT:PSS thin films. Specifically, we demonstrate that, at moderate loadings (∼2%, by weight) of the open-shell TEMPO–OH molecule, the thermopower of PEDOT:PSS thin films is increased without a marked decline in the electrical conductivity of the material. This effect, in turn, allows for an optimization of the power factor in the composite organic materials, which is a factor of 2 greater than the pristine PEDOT:PSS thin films. Furthermore, because the loading of TEMPO–OH is relatively low, we observe that there is little change in either the crystalline nature or surface topography of the composite films relative to the pristine PEDOT:PSS films. Instead, we determine that the increase in the thermopower is due to the presence of stable radical sites within the PEDOT:PSS that persist despite the highly acidic environment that occurs due to the presence of the poly(styrenesulfonate) moiety. Additionally, the oxidation–reduction-active (redox-active) nature of the TEMPO–OH small molecules provides a means by which to filter charges of different energy values. Therefore, these results demonstrate that a synergistic combination of an open-shell species and a conjugated polymer allows for enhanced thermoelectric properties in macromolecular systems, and as such, it offers the promise of a new design pathway in polymer thermoelectric materials.Keywords: nitroxide radicals; open-shell molecular doping; poly(3,4-ethylene dioxythiophene) doped with poly(styrenesulfonate) (PEDOT:PSS); polymer thermoelectrics; stable radical species
Co-reporter:Johny Jaramillo, Bryan W. Boudouris, César A. Barrero, and Franklin Jaramillo
ACS Applied Materials & Interfaces 2015 Volume 7(Issue 45) pp:25061
Publication Date(Web):October 27, 2015
DOI:10.1021/acsami.5b09686
Controlling the nature and transfer of excited states in organic photovoltaic (OPV) devices is of critical concern due to the fact that exciton transport and separation can dictate the final performance of the system. One effective method to accomplish improved charge separation in organic electronic materials is to control the spin state of the photogenerated charge-carrying species. To this end, nanoparticles with unique iron oxide (Fe3O4) cores and zinc oxide (ZnO) shells were synthesized in a controlled manner. Then, the structural and magnetic properties of these core–shell nanoparticles (Fe3O4@ZnO) were tuned to ensure superior performance when they were incorporated into the active layers of OPV devices. Specifically, small loadings of the core–shell nanoparticles were blended with the previously well-characterized OPV active layer of poly(3-hexylthiophene) (P3HT) and [6,6]-phenyl-C61-butyric acid methyl ester (PCBM). Upon addition of the core–shell nanoparticles, the performance of the OPV devices was increased up to 25% relative to P3HT-PCBM active layer devices that contained no nanoparticles; this increase was a direct result of an increase in the short-circuit current densities of the devices. Furthermore, it was demonstrated that the increase in photocurrent was not due to enhanced absorption of the active layer due to the presence of the Fe3O4@ZnO core–shell nanoparticles. In fact, this increase in device performance occurred because of the presence of the superparamagnetic Fe3O4 in the core of the nanoparticles as incorporation of ZnO only nanoparticles did not alter the device performance. Importantly, however, the ZnO shell of the nanoparticles mitigated the negative optical effect of Fe3O4, which have been observed previously. This allowed the core–shell nanoparticles to outperform bare Fe3O4 nanoparticles when the single-layer nanoparticles were incorporated into the active layer of OPV devices. As such, the new materials described here present a tangible pathway toward the development of enhanced design schemes for inorganic nanoparticles such that magnetic and energy control pathways can be tailored for flexible electronic applications.Keywords: controlled nanoparticle synthesis; core−shell nanoparticles; inverted organic solar cells; nanostructural characterization; photocurrent enhancement; superparamagnetic cores
Co-reporter:Seung Hyun Sung and Bryan W. Boudouris
ACS Macro Letters 2015 Volume 4(Issue 3) pp:293
Publication Date(Web):February 16, 2015
DOI:10.1021/mz5007766
In polymer-based ferroelectric diodes, films are composed of a semiconducting polymer and a ferroelectric polymer blend sandwiched between two metal electrodes. In these thin films, the ferroelectric phase serves as the memory retention medium while the semiconducting phase serves as the pathway to read-out the memory in a nondestructive manner. As such, having distinct phases for the semiconducting and ferroelectric phases have proven critical to device performance. In order to evaluate this crucial structure–property relationship, we have fabricated ordered ferroelectric devices (OFeDs) through common lithographic techniques to establish systematically the impact of nanoscale structure on the macroscopic performance. In particular, we demonstrate that there is an optimal domain size (∼400 nm) for the interpenetrating networks, and we show that the ordered device, with semiconducting domains that span the entire length of the active layer film, provides a significant increase in the ON/OFF ratio relative to the blended film fabricated using standard solution blending and spin-coating techniques. This improved performance occurs due to a combination of the ordered nanostructure and the nature of the ferroelectric-semiconductor interface. As this is the first demonstration of macroscopic OFeDs, this work helps to elucidate the underlying physics of the device operation and establishes a new archetype in the design of polymer-based, nonvolatile memory devices.
Co-reporter:Yizhou Zhang;Jessica L. Sargent;William A. Phillip
Journal of Applied Polymer Science 2015 Volume 132( Issue 21) pp:
Publication Date(Web):
DOI:10.1002/app.41683
ABSTRACT
Nanoporous membranes based on self-assembled block polymer precursors are an emerging class of promising separation, purification, and sensing devices due to the ability of researchers to control the nanostructure and chemistry of these multifunctional materials and devices. In fact, modern polymer chemistry provides techniques for the facile, controlled synthesis of the block polymers that constitute these devices. These designer macromolecules, in turn, can then self-assemble into functional nanostructures depending upon the chemical identity of the synthesized block polymers and the thin film fabrication methods employed. After fabrication, these nanoporous membranes offer a highly tunable platform for applications that require high throughput, high surface area, homogeneous pore size, and varying material properties. And, with these readily tunable chemical and structural properties, block polymer membranes will allow for significant improvements in myriad applications. In this Review, we summarize the key advances, with a specific emphasis on the previous 5 years of work, that have allowed block polymer-based membranes to reach their current level of technology. Furthermore, we project how these state-of-art, self-assembled block polymer membrane technologies can be utilized in present-day and future application arenas. In this way, we aim to demonstrate that the rigorous work performed on block polymer-based membranes has laid a strong foundation that will allow these macromolecular systems to: (1) be major avenues of fundamental scientific research and (2) be parlayed into transferable technologies for the betterment of society in the imminent future. © 2014 Wiley Periodicals, Inc. J. Appl. Polym. Sci. 2015, 132, 41683.
Co-reporter:Ryan A. Mulvenna;Rafael A. Prato;William A. Phillip
Macromolecular Chemistry and Physics 2015 Volume 216( Issue 17) pp:1831-1840
Publication Date(Web):
DOI:10.1002/macp.201500201
Co-reporter:Holly Chan, Yucheng Wang, Bryan W. Boudouris
Thin Solid Films 2015 577() pp: 56-61
Publication Date(Web):
DOI:10.1016/j.tsf.2015.01.060
Co-reporter:Lizbeth Rostro;Lucio Galicia
Journal of Polymer Science Part B: Polymer Physics 2015 Volume 53( Issue 5) pp:311-316
Publication Date(Web):
DOI:10.1002/polb.23640
ABSTRACT
Developing stable, readily-synthesized, and solution-processable transparent conducting polymers for interfacial modifying layers in organic photovoltaic (OPV) devices has become of great importance. Here, the radical polymer, poly(2,2,6,6-tetramethylpiperidinyloxy methacrylate (PTMA), is shown to not affect the absorption of the well-studied poly(3-hexylthiophene) (P3HT) and [6,6]-phenyl-C61-butyric acid methyl ester (PCBM) active layer when incorporated into inverted OPV devices, as it is highly transparent in the visible spectrum due to the non-conjugated nature of the PTMA backbone. The inclusion of this radical polymer as an anode-modifying layer enhanced the open-circuit voltage and short-circuit current density values over devices that did not contain an anodic modifier. Importantly, devices fabricated with the PTMA interlayer had performance metrics that were time-independent over the entire course of multiples days of testing after exposing the OPV devices to ambient conditions. Furthermore, these high performance values were independent of the metal used as the top electrode contact in the inverted OPV devices. © 2014 Wiley Periodicals, Inc. J. Polym. Sci., Part B: Polym. Phys. 2015, 53, 311–316
Co-reporter:Ryan A. Mulvenna, Jacob L. Weidman, Benxin Jing, John A. Pople, Yingxi Zhu, Bryan W. Boudouris, William A. Phillip
Journal of Membrane Science 2014 470() pp: 246-256
Publication Date(Web):
DOI:10.1016/j.memsci.2014.07.021
Co-reporter:Lizbeth Rostro, Si Hui Wong, and Bryan W. Boudouris
Macromolecules 2014 Volume 47(Issue 11) pp:3713-3719
Publication Date(Web):May 30, 2014
DOI:10.1021/ma500626t
We establish the relationship between pendant group chemical identity and the ability of a specific radical polymer, poly(2,2,6,6-tetramethylpiperidinyloxy methacrylate) (PTMA), to transport charge in the solid state. Radical polymers (i.e., macromolecules with aliphatic carbon backbones and pendant groups containing stable radical moieties) have attracted much attention in organic electronic applications due to straightforward synthetic methods, easily tunable electronic properties, and relatively high-performance with respect to charge transport. Because charge transport can occur only through the pendant group of these completely amorphous radical polymers, controlling the precise chemical nature of these functional groups is of key import. Specifically, we have determined that the deprotection step, which converts the pendant group functionality through a simple oxidation reaction, can lead to four distinct chemical functionalities along the radical polymer, as monitored by a range of complementary spectroscopic techniques. Of these four functionalities, only two (i.e., the stable free radical and the corresponding oxoammonium cation) are able to contribute positively to the charge transport ability of the macromolecule. As such, manipulating the reaction conditions for this deprotection step, and monitoring closely the resultant chemical functionalities, is critical in tuning the electrical properties of radical polymers. However, if these parameters are controlled well, we are able to generate transparent, conducting thin films of pristine (i.e., not doped) nonconjugated radical polymers with electrical conductivities as high as (1.5 ± 0.3) × 10–5 S cm–1.
Co-reporter:Edward P. Tomlinson, Martha E. Hay, and Bryan W. Boudouris
Macromolecules 2014 Volume 47(Issue 18) pp:6145-6158
Publication Date(Web):September 15, 2014
DOI:10.1021/ma5014572
Macromolecules bearing stable radical groups have emerged as extremely useful active materials in organic electronic applications ranging from magnetic devices to flexible batteries. Critical to the success of these open-shell polymers has been the readily tunable nature of their molecular architectures; this important molecular structure–property–performance design paradigm has allowed for significant device performance metrics to be achieved. In this Perspective, the recent advancements regarding the design and device functionality of a common class of open-shell macromolecules, radical polymers, are discussed. Here, radical polymers are defined as macromolecules with nonconjugated carbon backbones, whose optoelectronic functionalities arise due to the presence of stable radical sites on the pendant groups of macromolecular chains. This class of materials provides a unique platform for the design of unique optical and electronic properties in soft materials; however, as with many organic electronic materials, transitioning these gains from the laboratory to the commercial scale remains a primary challenge. As such, we provide context for the significant accomplishments that have been made in the field, describe how these advances have been translated to high-performance devices, and discuss future areas of evaluation for these next-generation polymer electronic materials.
Co-reporter:Lizbeth Rostro, Aditya G. Baradwaj, and Bryan W. Boudouris
ACS Applied Materials & Interfaces 2013 Volume 5(Issue 20) pp:9896
Publication Date(Web):September 17, 2013
DOI:10.1021/am403223s
Macromolecules with aliphatic backbones that bear pendant stable radical groups (i.e., radical polymers) have attracted much attention in applications where a supporting electrolyte is capable of aiding charge transport in solution; however, the utilization of these materials in solid state applications has been limited. Here, we synthesize a model radical polymer, poly(2,2,6,6-tetramethylpiperidinyloxy methacrylate) (PTMA), through a controlled reversible addition–fragmentation chain transfer (RAFT) mediated polymerization mechanism to generate well-defined and easily-tunable functional polymers. These completely amorphous, electronically-active polymers demonstrate relatively high glass transition temperatures (Tg ∼170 °C) and, because of the aliphatic nature of the backbone of the radical polymers, are almost completely transparent in the visible region of the electromagnetic spectrum. Additionally, we quantify the conductivity of PTMA (∼1 × 10–6 S cm–1) and find it to be on par with pristine π-conjugated polymers such as poly(phenylene vinylenes) (PPVs) and poly(3-alkylthiophenes) (P3ATs). Furthermore, we demonstrate that the addition of small molecules bearing stable radical groups provides for more solid state charge hopping sites without altering the chemical nature of radical polymers; this, in turn, allows for an increase in the conductivity of PTMA relative to neat PTMA thin films while still retaining the same high degree of optical transparency and device stability. Because of the synthetic flexibility and easily-controlled doping mechanisms (that do not alter the PTMA chemistry), radical polymers present themselves as promising and tunable materials for transparent solid-state plastic electronic applications.Keywords: controlled radical polymerization; molecular doping; nonconjugated transparent conductors; radical polymers; solid-state charge transport;
Co-reporter:Bryan W Boudouris
Current Opinion in Chemical Engineering (August 2013) Volume 2(Issue 3) pp:294-301
Publication Date(Web):1 August 2013
DOI:10.1016/j.coche.2013.07.002
•Polymer-based devices are emerging as sustainable energy solutions.•Major strides occurred due to the tailored design of functional macromolecules.•Solution-processed plastic solar cells are approaching 11% in efficiency.•Thermoelectric devices based on polymers have ZT values over 0.4.The design and synthesis of semiconducting and conducting macromolecules has led to recent marked increases in the performance of polymer-based sustainable energy conversion devices. Specifically, the design of semiconducting copolymers has allowed for the fabrication of solution-deposited organic photovoltaic (OPV) devices with power conversion efficiencies approaching 11% to be realized on the laboratory scale. Furthermore, polymer-based thermoelectric (TE) devices with figure of merit (ZT) values of greater than 0.4 have been realized due to the refinement of conducting polymers and conducting polymer–inorganic nanoparticle composites. Here, we describe the macromolecular design strategies that have been implemented to achieve these impressive results, and we suggest future routes of investigation that could allow for the discovery of even higher performance materials and devices.Download full-size image
Co-reporter:Holly Chan, Yucheng Wang, Bryan W. Boudouris
Thin Solid Films (27 February 2015) Volume 577() pp:56-61
Publication Date(Web):27 February 2015
DOI:10.1016/j.tsf.2015.01.060
•Sulfonic acid groups are copolymerized within the backbone of radical polymer chain.•Addition of the sulfonic acid groups alters the pendant group oxidation state.•Exact oxidation states are monitored with a variety of spectroscopic techniques.•Oxidation states alter the solid-state charge transport ability of radical polymers.•Optimized intramolecular doping and oxidization reaction times are established.Radical polymers are an emerging class of non-conjugated, charge-conducting macromolecules that are capable of transporting charge through localized oxidation–reduction (redox) reactions that occur at the stable radical groups present as the pendant groups of the macromolecular chains. The chemical nature and oxidation state of these pendant radical groups are critical to the charge transporting abilities of radical polymers in the solid state. To date, however, the control of this chemistry has been limited to external oxidizing agents, and the concept of intramolecular dopants has not been explored fully. To this end, we have synthesized poly(2,2,6,6-tetramethylpiperidinyloxy methacrylate)-co-poly(vinylsulfonic acid sodium salt) (PTMA-co-PVS). Then, electron paramagnetic resonance spectroscopy and attenuated total reflectance-Fourier transform infrared spectroscopy are implemented to evaluate the exact chemical nature of the pendant groups as a function of the PVS intramolecular dopants and exposure of the materials to external oxidation reactions. We correlate these changes in pendant group chemistry to charge transport ability, and we establish that the inclusion of a moderate amount of PVS dopants can improve the solid-state hole mobility of the material. Conversely, a large amount of sulfonic acidic dopants can be detrimental to the transport of the polymer relative to the homopolymer PTMA. Therefore, refinement of pendant group chemistry and careful addition of intramolecular dopants can enhance the solid-state transport ability of a radical polymer system. These fundamental principles, in turn, provide a vital foothold by which to optimize the solid-state charge transporting ability of current and next-generation radical polymer designs.
