We report amperometric detection of formaldehyde (HCHO) using hydroxylamine hydrochloride and single-walled carbon nanotubes (SWCNTs). Hydroxylamine hydrochloride reacts with HCHO to emit HCl vapor, which injects a hole carrier into semiconducting SWCNTs. The increase of conductivity in SWCNTs is easily monitored using an ohmmeter. The debundling of SWCNTs with a metallo-supramolecular polymer (MSP) increased the active surface area in the SWCNTs network, leading to excellent sensitivity to HCHO with a limit of detection (LoD) of 0.016 ppm. The response of sensor is reversible, and the sensor is reusable. The selectivity to HCHO is 105–106 times higher than interferences with other volatiles such as water, methanol, and toluene. Moreover, false-positive responses caused by a significant variation of humidity and/or temperature are successfully discriminated from true-positive responses by using two sensors, one with and the other without hydroxylamine hydrochloride, in a referenced system.Keywords: carbon nanotubes; chemical sensors; chemiresistors; environmental monitoring; formaldehyde; gas sensors;

As-synthesized single-walled carbon nanotubes (SWCNTs) are a mixture of metallic and semiconducting tubes, and separation is essential to improve the performances of SWCNT-based electric devices. Our chemical sensor monitors the conductivity of an SWCNT network, wherein each tube is wrapped by an insulating metallosupramolecular polymer (MSP). Vapors of strong electrophiles such as diethyl chlorophosphate (DECP), a nerve agent simulant, can trigger the disassembly of MSPs, resulting in conductive SWCNT pathways. Herein, we report that separated SWCNTs have a large impact on the sensitivity and selectivity of chemical sensors. Semiconducting SWCNT (S-SWCNT) sensors are the most sensitive to DECP (up to 10000% increase in conductivity). By contrast, the responses of metallic SWCNT (M-SWCNT) sensors were smaller but less susceptible to interfering signals. For saturated water vapor, increasing and decreasing conductivities were observed for S- and M-SWCNT sensors, respectively. Mixtures of M- and S-SWCNTs revealed reduced responses to saturated water vapor as a result of canceling effects. Our results reveal that S- and M-SWCNTs compensate sensitivity and selectivity, and the combined use of separated SWCNTs, either in arrays or in single sensors, offers advantages in sensing systems.Keywords: carbon nanotubes; chemical warfare agents; chemiresistors; gas sensors; metal ligand complexes; semiconductors; supramolecular polymers;

The carbon cycle, by which carbon atoms circulate between atmosphere, oceans, lithosphere, and the biosphere of Earth, is a current hot research topic. The carbon cycle occurring in the lithosphere (e.g., sedimentary carbonates) is based on weathering and metamorphic events so that its processes are considered to occur on the geological time scale (i.e., over millions of years). In contrast, we have recently reported that carbonate anions intercalated within a hydrotalcite (Mg0.75Al0.25(OH)2(CO3)0.125·yH2O), a class of a layered double hydroxide (LDH), are dynamically exchanging on time scale of hours with atmospheric CO2 under ambient conditions. (Ishihara et al., J. Am. Chem. Soc. 2013, 135, 18040–18043). The use of 13C-labeling enabled monitoring by infrared spectroscopy of the dynamic exchange between the initially intercalated 13C-labeled carbonate anions and carbonate anions derived from atmospheric CO2. In this article, we report the significant influence of Mg/Al ratio of LDH on the carbonate anion exchange dynamics. Of three LDHs of various Mg/Al ratios of 2, 3, or 4, magnesium-rich LDH (i.e., Mg/Al ratio = 4) underwent extremely rapid exchange of carbonate anions, and most of the initially intercalated carbonate anions were replaced with carbonate anions derived from atmospheric CO2 within 30 min. Detailed investigations by using infrared spectroscopy, scanning electron microscopy, powder X-ray diffraction, elemental analysis, adsorption, thermogravimetric analysis, and solid-state NMR revealed that magnesium rich LDH has chemical and structural features that promote the exchange of carbonate anions. Our results indicate that the unique interactions between LDH and CO2 can be optimized simply by varying the chemical composition of LDH, implying that LDH is a promising material for CO2 storage and/or separation.Keywords: anion exchange; carbon dioxide; carbonate; clay mineral; isotope; layered double hydroxide

Porphyrins and related families of molecules are important organic modules as has been reflected in the award of the Nobel Prizes in Chemistry in 1915, 1930, 1961, 1962, 1965, and 1988 for work on porphyrin-related biological functionalities. The porphyrin core can be synthetically modified by introduction of various functional groups and other elements, allowing creation of numerous types of porphyrin derivatives. This feature makes porphyrins extremely useful molecules especially in combination with their other interesting photonic, electronic and magnetic properties, which in turn is reflected in their diverse signal input–output functionalities based on interactions with other molecules and external stimuli. Therefore, porphyrins and related macrocycles play a preeminent role in sensing applications involving chromophores. In this review, we discuss recent developments in porphyrin-based sensing applications in conjunction with the new advanced concept of nanoarchitectonics, which creates functional nanostructures based on a profound understanding of mutual interactions between the individual nanostructures and their arbitrary arrangements. Following a brief explanation of the basics of porphyrin chemistry and physics, recent examples in the corresponding fields are discussed according to a classification based on physical modes of detection including optical detection (absorption/photoluminescence spectroscopy and energy and electron transfer processes), other spectral modes (circular dichroism, plasmon and nuclear magnetic resonance), electronic and electrochemical modes, and other sensing modes.

The carbon cycle of carbonate solids (e.g., limestone) involves weathering and metamorphic events, which usually occur over millions of years. Here we show that carbonate anion intercalated layered double hydroxide (LDH), a class of hydrotalcite, undergoes an ultrarapid carbon cycle with uptake of atmospheric CO2 under ambient conditions. The use of 13C-labeling enabled monitoring by IR spectroscopy of the dynamic exchange between initially intercalated 13C-labeled carbonate anions and carbonate anions derived from atmospheric CO2. Exchange is promoted by conditions of low humidity with a half-life of exchange of ∼24 h. Since hydrotalcite-like clay minerals exist in Nature, our finding implies that the global carbon cycle involving exchange between lithosphere and atmosphere is much more dynamic than previously thought.

The use of hydrogen bonds permits a fluidic motion of differently sized alcohol molecules across the interlayer gap in LDH, which enables rapid and reversible tuning of interlayer spacing of the LDH at sub-Ångström precision by changing the mole ratio of the different alcohols.

Methanol is a highly toxic substance, but it is unfortunately very difficult to differentiate from other alcohols (especially ethanol) without performing chemical analyses. Here we report that a composite film prepared from oxoporphyrinogen (OxP) and a layered double hydroxide (LDH) undergoes a visible color change (from magenta to purple) when exposed to methanol, a change that does not occur upon exposure to ethanol. Interestingly, methanol-induced color variation of the OxP-LDH composite film is retained even after removal of methanol under reduced pressure, a condition that does not occur in the case of conventional solvatochromic dyes. The original state of the OxP-LDH composite film could be recovered by rinsing it with tetrahydrofuran (THF), enabling repeated usage of the composite film. The mechanism of color variation, based on solid-state 13C–CP/MAS NMR and solution-state 13C NMR studies, is proposed to be anion transfer from LDH to OxP triggered by methanol exposure.Keywords: alcohol; clay mineral; layered double hydroxide; organic−inorganic composite; porphyrinoid; sensor;

Aggregation of gold nanoparticles (AuNPs) can be utilized in chemical and biomolecular sensing as a sensitive and easy-to-visualize process. However, interpretation of experimental results requires a clear understanding of physicochemical processes that take place upon multiple interactions between an analyte and AuNPs. In this article, interactions between citrate-stabilized AuNPs and organic compounds bearing various functional groups in an aqueous medium were experimentally and theoretically studied using spectrophotometry of the localized surface plasmon resonance (LSPR), transmission electron microscopy (TEM), conductometry, zeta potential measurements, and finite-difference time-domain (FDTD) modeling. As a result, it has been found that organic compounds containing both thiol and amine groups strongly promote the aggregation of AuNPs due to their cooperative functionalities. FDTD modeling has enabled consideration of the light extinction (i.e., LSPR response) properties of nanoparticle aggregates involving single, chain-like, and globular structures. Taking one billion distributions of differently structured aggregates into account, the theoretical light extinction was fitted to that of the experimental result with a root-mean-square deviation of 7%.

The use of hydrogen bonds permits a fluidic motion of differently sized alcohol molecules across the interlayer gap in LDH, which enables rapid and reversible tuning of interlayer spacing of the LDH at sub-Ångström precision by changing the mole ratio of the different alcohols.

Porphyrins and related families of molecules are important organic modules as has been reflected in the award of the Nobel Prizes in Chemistry in 1915, 1930, 1961, 1962, 1965, and 1988 for work on porphyrin-related biological functionalities. The porphyrin core can be synthetically modified by introduction of various functional groups and other elements, allowing creation of numerous types of porphyrin derivatives. This feature makes porphyrins extremely useful molecules especially in combination with their other interesting photonic, electronic and magnetic properties, which in turn is reflected in their diverse signal input–output functionalities based on interactions with other molecules and external stimuli. Therefore, porphyrins and related macrocycles play a preeminent role in sensing applications involving chromophores. In this review, we discuss recent developments in porphyrin-based sensing applications in conjunction with the new advanced concept of nanoarchitectonics, which creates functional nanostructures based on a profound understanding of mutual interactions between the individual nanostructures and their arbitrary arrangements. Following a brief explanation of the basics of porphyrin chemistry and physics, recent examples in the corresponding fields are discussed according to a classification based on physical modes of detection including optical detection (absorption/photoluminescence spectroscopy and energy and electron transfer processes), other spectral modes (circular dichroism, plasmon and nuclear magnetic resonance), electronic and electrochemical modes, and other sensing modes.
