Co-reporter:Pingping Yu, Xin Zhao, Yingzhi Li, Qinghua Zhang
Applied Surface Science 2017 Volume 393() pp:37-45
Publication Date(Web):30 January 2017
DOI:10.1016/j.apsusc.2016.09.119
Highlights
- •
Hierarchical porous graphene foam prepared by templating and embossing method..
- •
Vertically PANI nanowires aligned on interconnected porous graphene sheets.
- •
The fRGO-F/PANI device exhibited 939 F g−1 at 1 A g−1.
- •
ED and PD of fRGO-F/PANI device was 20.9 Wh kg−1 and 103.2 kW kg−1.
Co-reporter:Chaoyi Chen, Xin Zhao, Hai-Bei Li, Feng Gan, Junxian Zhang, Jie Dong, Qinghua Zhang
Electrochimica Acta 2017 Volume 229(Volume 229) pp:
Publication Date(Web):1 March 2017
DOI:10.1016/j.electacta.2017.01.172
Two naphthalene-based polyimide derivatives are fabricated through a facile condensation polymerization by 1,4,5,8-naphthalenetetracarboxylic dianhydride (NT) with different two diamines, e.g., urea and ethylenediamine, respectively. Their structures with morphologies are studied and the electrochemical properties are investigated as cathode materials for rechargeable lithium-ion batteries (LIBs). By comparison to NT, the polymers with carbonyl functionalities as electroactive groups show improved stability in electrolyte. The obtained derivative (NOP) from NT and urea with more redox active sites exhibits a higher discharge capacity and better rate performance, which might be attributed to its relatively lower molecule weight of the framework and the introduction of additional carbonyl group inherited from urea unit. It displays an average reversible capacity of 174.5 mAh g−1 at 20 mA g−1 and a good rate performance with a high value of 133.5 mAh g−1 at 500 mA g−1. With an optimized polymerization conditions, its capacity could remain 153 mAh g−1 after 60 cycles of charge-discharge processes at 50 mA g−1, making it a potential material for greener and sustainable electrode for electrochemical storage devices.
Co-reporter:Junxian Zhang, Xin Zhao, Zilong Huang, Ting Xu, Qinghua Zhang
Carbon 2016 Volume 107() pp:844-851
Publication Date(Web):October 2016
DOI:10.1016/j.carbon.2016.06.064
Flexible solid-state fiber supercapacitors are fabricated by directly electrodepositing ultrathin manganese dioxide (MnO2) nanosheets on commercial carbon fiber yarns. The deposition process is well controlled and the composition of MnO2 in fiber electrodes is optimized to enable fiber SCs to possess high specific capacitance. Conductive carbon fibers concurrently serve as current collectors in fiber SCs and as flexible substrates for the deposition of MnO2. A single MnO2/CFs fiber electrode exhibits a specific volumetric capacitance of 58.7 F cm−3 with a specific gravimetric capacitance of 428 F g−1 based on the MnO2 mass. Two hybrid carbon fiber electrodes are assembled together in parallel with polyvinyl pyrrolidone/Na2SO4 gel, which is used as both an electrolyte and a separator. The assembled flexible device exhibits a high volumetric energy density of 3.8 mW h cm−3 at a power density of 89 mW cm−3 with a good flexibility (CV curves almost unchanged after 2000 bending times) and a superior long cycle stability (an 85.8% capacitance retention after 10000 cycles). Moreover, the integrated SCs could power a commercial light-emitting-diode (LED), demonstrating its strong potential for the practical applications of flexible energy storage devices.
